Lesson 10.3: Scripts packed into exes

Some exes aren’t worth dragging into IDA, because you’ll waste your whole evening. They’re scripts packed into an executable. Inside there’s no compiled C code, just an AutoIt or AutoHotkey script, or an NSIS installer, plus a stub whose only job is to unpack the script and run it. For these, don’t read the stub’s assembly, extract the original script. Often you get back nearly the exact source.

This matters in practice. Malware likes AutoIt and NSIS because they’re quick to pack, hard to catch with signatures, and look harmless. So you should know how to dig the script out.

General approach: identify first, extract after

Every type in this lesson follows the same routine. First identify the wrapper type with Detect It Easy (DIE) and strings, since each type leaves clear traces. Then use the right extraction tool for that type. Don’t open a disassembler before you’ve ruled out a packed script.

Quick tells in strings or DIE:

Type	Common traces
AutoIt	the strings AU3!, >>>AUTOIT SCRIPT<<<, AutoIt v3
AutoHotkey	an RCDATA resource named >AUTOHOTKEY SCRIPT<, the string AutoHotkey
NSIS	the strings Nullsoft Install System, NSIS
Inno Setup	the string Inno Setup, a JR. section in the resources
PyInstaller	the strings MEI, pyi (see Lesson 7.4 again)

AutoIt

AutoIt is an automation scripting language for Windows. When compiled, it embeds the script code (tokenized, not plain text) into an interpreter stub. Tokenizing isn’t strong encryption, so tools can reverse almost all of it.

The simplest tool is Exe2Aut, and you drag and drop the exe in and it unpacks the original .au3 file. It runs on Windows. There’s also AutoIt-Ripper (Python), which is cross-platform and extracts the script from the exe or from a memory dump.

For newer AutoIt variants with extra encryption, Exe2Aut sometimes has to run the file itself (dangerous if it’s malware) to catch the moment the script gets decoded in memory. When analyzing malicious samples, do it in an isolated VM following Lesson 0.3.

AutoHotkey

AutoHotkey (AHK) is even easier. The script is embedded almost verbatim in an RCDATA-type resource, usually named >AUTOHOTKEY SCRIPT<. You don’t need a special tool. Open the exe with Resource Hacker or CFF Explorer, find the RCDATA resource, export it and you have the .ahk script. For AHK v2 or compressed builds, you may need to decompress the resource first, but the approach is the same.

Since the script is text, running strings often already shows the content.

NSIS installer

NSIS (Nullsoft Scriptable Install System) is a very popular installer builder. Inside is an archive holding the files to be installed, plus the compiled install script.

7-Zip (the version that supports NSIS) opens an NSIS .exe directly as an archive, so you can view and extract the files inside. It’s the fastest way to get the payload the installer will drop. Newer 7-Zip versions dropped some support for viewing the .nsi script, but they can still extract the files. To read the script logic back, use specialized forks like nsisunbz or an older 7-Zip.

With malware, NSIS is often just a shell. Extract it and you’ll see the real payload (another exe/dll/script) to analyze next.

Inno Setup

Inno Setup is another popular installer builder. Its format differs from NSIS, so 7-Zip can’t open it properly.

The tool for it is innounp (Inno Setup Unpacker), on the command line, where innounp -x setup.exe extracts all the files and also the decompiled install_script.iss script. UniExtract2 bundles many extractors and auto-detects NSIS, Inno and a few other types, which is handy when you don’t want to remember which tool goes with which type.

Other wrappers

BAT to EXE (batch packed into an exe) can usually be extracted with a reverse Batch2Exe tool, or by dumping strings or temp files at runtime. For homemade script packers with no ready tool, what always works is to run it in a VM and catch the temp file or dump memory at the moment the script is decoded (use Procmon to see which files it writes to %TEMP%, see Lesson 2.8 again).

Try this route first

Say a malware sample is reported as “hard”. You drag it into IDA, see nothing but strange code, and it turns out to be just an AutoIt stub. Extracting the script lets you read the intent in a few minutes instead of wading through assembly all day. Before you complain that a binary is hard, rule out a packed script. DIE and strings answer that in ten seconds.

Lab

The goal is to build the habit of asking “is this just a packaged script?” and to extract the original source. You need Detect It Easy (the diec.exe command line tool and the GUI), Exe2Aut or AutoIt-Ripper for AutoIt, Resource Hacker or CFF Explorer for AutoHotkey, 7-Zip for NSIS, and innounp or UniExtract2 for Inno Setup. If the sample is malware, run everything inside an isolated VM (see Lesson 0.3).

Collect a few exes, either from your machine or made yourself. Install a small program packed with NSIS or Inno (a lot of free software uses them), write a short AutoHotkey script and compile it, and write an AutoIt script and compile it. For each file, run diec.exe <file> and open the DIE GUI, and note the identification traces, which are AU3, AUTOHOTKEY SCRIPT, Nullsoft Install System, Inno Setup. Compare them against the table in the lesson.

Then extract the script or payload with the right tool. For AutoIt use Exe2Aut or autoit-ripper <file> out/. For AutoHotkey, open Resource Hacker, find the RCDATA entry named >AUTOHOTKEY SCRIPT< and export it. For NSIS, open the file with 7-Zip and extract everything. For Inno, run innounp -x setup.exe. Compare the extracted script with the original you wrote (for AutoIt and AHK), and check whether it matches and whether anything is lost. For the NSIS and Inno files, list the payload files the installer will drop. If this were real malware, which payload would be worth analyzing next?

Two questions to think about. Why is extracting the script so much faster than reading the assembly of the stub? And when Exe2Aut can’t extract statically (an encrypted variant), what do you do next that is still safe?

Show solution

This writeup describes the standard procedure. The Exe2Aut and Resource Hacker steps need a Windows machine, while the identification with strings and DIE works on any platform.

For identification, run diec.exe or strings <file> | grep -i for each type. For AutoIt you see AU3!EA06 or AU3!EA05 (the marker for the start of the script block), along with >>>AUTOIT SCRIPT<<< and This is a third-party compiled AutoIt script, and DIE reports the AutoIt compiler. For AutoHotkey, strings exposes >AUTOHOTKEY SCRIPT< and many AHK commands as plain text (MsgBox, Gui, Send), and DIE recognizes AutoHotkey. For NSIS you see Nullsoft Install System v3.xx and DIE reports Installer: Nullsoft. For Inno Setup you see Inno Setup Setup Data (x.y.z), with resource sections whose names start with JR. or zlb. Once you see one of these strings, it’s almost certainly a packaged script or installer, and you don’t need to open IDA.

For extraction, with AutoIt and Exe2Aut you drag the exe into the window, it prints the .au3 in the right panel, and you save it. On the command line with AutoIt-Ripper:

python -m autoit_ripper -i target.exe -o out/

The result is an .au3 file holding the script almost verbatim (variable names, function names and strings are kept). For AutoHotkey with Resource Hacker, open the exe, go to the resource tree > RCDATA > >AUTOHOTKEY SCRIPT<, right-click and choose Save resource to file, and you get an .ahk file you can read right away. For NSIS with 7-Zip:

7z x installer.exe -oout_nsis/

The folder out_nsis/ holds every file the installer would install, plus [NSIS].nsi (if your 7-Zip version still supports exporting the script). For Inno Setup with innounp:

innounp -x setup.exe

This extracts the files and a decompiled install_script.iss that tells you what the installer does (writes the registry, runs commands, drops which files).

In the comparison, for AutoIt and AHK the extracted script is almost identical to the original, as variable and function names are kept, comments are usually lost (they aren’t embedded), and the strings and logic stay intact. So compiled scripts belong in the same “easy to reverse” group as managed code, not native C.

For the payload question, with NSIS and Inno the files worth analyzing next are usually another exe or dll in the extracted list (the real payload), or a script (bat, vbs, ps1, au3) that the installer runs after installing. Read install_script.iss or a Procmon log to learn which file gets run (Exec, Run), since that is the next target.

On the reflection questions, extraction is faster because the stub is just a fixed interpreter, so reading its assembly tells you nothing about behavior. The behavior lives in the script, and the script comes out at a high language level that reads like source. When static extraction fails, run the sample in an isolated VM and use Procmon to watch which files it writes to %TEMP% (scripts are often decoded to disk or loaded into memory), or dump the process memory at the moment the script has been decoded. Always do this in an isolated environment following Lesson 0.3.

Key takeaways

Many “exes” are really packed scripts (AutoIt/AHK) or installers (NSIS/Inno), so don’t read the stub’s assembly. Identify first with DIE and strings, since each type has clear traces. For AutoIt use Exe2Aut or AutoIt-Ripper, for AHK extract the RCDATA resource with Resource Hacker, for NSIS use 7-Zip, and for Inno use innounp (or UniExtract2, which handles both). Malware likes AutoIt and NSIS, so extracting the script or payload is a practical skill. When there’s no tool, run it in an isolated VM and catch the temp file or dump memory.
