Lesson 13.4: Lua and LuaJIT bytecode

A lot of games don’t write gameplay logic in C++ but in Lua, because Lua is light, easy to embed, and can be edited without rebuilding the whole engine. Roblox, Garry’s Mod, World of Warcraft (addons), and many mobile games all run Lua scripts. For a reverser that’s good news. Lua keeps almost all its information, and decompiling gets you something close to the source. The catches are that there are two different Lua lines (standard Lua and LuaJIT), the bytecode changes with the version, and games often encrypt scripts. This lesson goes through each piece.

Lua runs on bytecode, like Python

When you write a .lua file, the interpreter doesn’t run the text directly. It compiles to bytecode first and then runs it on the Lua VM (register-based, unlike stack-based CPython). Most of the time games embed the plain .lua text so you can read it right away, but when the author wants to hide it, they ship compiled bytecode (made with luac, the Lua compiler). Then you need a decompiler.

There are two completely different bytecode families. Standard Lua (lua.org) produces bytecode with luac, and you decompile it with unluac (Java, the best one right now) or luadec. LuaJIT is a separate implementation, faster, and its bytecode is not compatible with standard Lua. You need a dedicated decompiler, such as luajit-decompiler, ljd, or the luajit-decompiler-v2 version.

Pick the wrong one and the decompiler errors out from the first byte. So step one is always identification.

Identifying: read the magic and version

Open the bytecode file in a hex editor and look at the first few bytes.

Standard Lua starts with the magic 1B 4C 75 61, i.e. \x1bLua. The 5th byte is the version number in hex, where 51 = Lua 5.1, 52 = 5.2, 53 = 5.3, 54 = 5.4. This decides which decompiler you use, because the bytecode differs per version.

1B 4C 75 61 54 00 19 93 0D 0A 1A 0A ...
\x1b L  u  a  |  version 0x54 = Lua 5.4

LuaJIT starts with the magic 1B 4C 4A, i.e. \x1bLJ, then a bytecode version byte (01, 02…). If you see LJ, go to the ljd branch and don’t waste time on unluac.

If you see no magic and the file looks like high-entropy junk, the script has probably been encrypted (see the last section).

Decompiling standard Lua with unluac

A workflow once you know it’s standard Lua:

# compile (if you're making your own sample to learn)
luac -o script.luac script.lua

# decompile back
java -jar unluac.jar script.luac > script_decompiled.lua

unluac gives back code very close to the original. It keeps local variable names (if the bytecode hasn’t had its debug info stripped), function names, string constants, and the if/for/while structure. If the bytecode is stripped (luac -s), local variable names are lost and you get A0_1, L1_2…, but the logic is still complete and readable.

luadec is the older alternative, good with Lua 5.1 but it struggles with newer versions. If you hit Lua 5.1 and unluac misbehaves, try luadec.

Decompiling LuaJIT with ljd

LuaJIT is more stubborn. ljd (and its rewrite luajit-decompiler-v2) is the main tool:

python3 ljd/main.py -f script_ljbc.luac

Output quality is usually worse than unluac on standard Lua. Some complex control structures may come out unclean, and you have to read alongside the bytecode disassembly to understand them. For ordinary gameplay scripts it’s good enough.

Things to know when reading

A few Lua-specific things you’ll see in decompiled code. The table is Lua’s central data type, serving as array, dictionary, and object (through metatables), so t[1], t.field, t:method() all mean tables. Strings in Lua are interned and stored in the constant pool of each function prototype, so API function names, keys, and messages leak out a lot. Going from a string to where it’s used works here like everywhere else. And t:method(a) is just syntactic sugar for t.method(t, a), so self is a hidden first parameter, like this.

Finding Lua scripts in a game

Before decompiling, you have to get the bytecode out. In the game folder, look for .lua, .luac, .lc files, or a dedicated archive (.pak, .rbxl, asset bundle). Use strings and look for the magic \x1bLua / \x1bLJ to locate the bytecode block even when it’s embedded in a large file. It may also be embedded in a native binary, so grep for the magic in the exe/so itself. Otherwise, unpack the game’s archive with the matching tool and then scan.

When the script is encrypted

Many games don’t leave the bytecode bare but encrypt it (XOR, a custom cipher) and decrypt in memory right before loading into the Lua VM. Then decompiling the file on disk is useless.

One approach is to dump from runtime. Let the game decrypt it itself, then pull the decrypted bytecode out of memory. Hook the script loading function (for example luaL_loadbuffer, lua_load, luaL_loadbufferx) with Frida and print the buffer at the moment it’s clean bytecode. It’s the same dynamic unpacking idea as Part 14. The other case is when the key sits in the binary. If the cipher is simple, find the decryption function in the native code, get the key, and decrypt offline.

The principle is the same as for every kind of packer, which is to find where the data is in its cleanest form and grab it there, instead of working against the encryption layer.

Lab

LAB 13.4Download the source files for this lab

Download all (.zip) src/guard.lua

The goal is to go through the full text to bytecode to decompiled cycle yourself, recognize the magic bytes, and recover the logic straight from bytecode. You need lua and luac (Lua 5.3 or 5.4, installable on Ubuntu with apt install lua5.4, or a prebuilt Windows binary), unluac.jar (needs Java, downloadable from the unluac repo), and a hex editor such as HxD or ImHex, or just xxd.

The file to work with is guard.lua, a Lua script that checks a license key. The valid key gets transformed with (byte + position) % 256 and compared against an array called EXPECTED, so the key itself doesn’t sit plainly in the bytecode.

Compile it to bytecode both with and without debug info:

luac -o guard.luac guard.lua
luac -s -o guard_strip.luac guard.lua

Open guard.luac in a hex editor and confirm the magic bytes 1B 4C 75 61 (\x1bLua) and read the fifth byte, the version (53 or 54). Then decompile it:

java -jar unluac.jar guard.luac > guard_out.lua

Compare guard_out.lua with the original guard.lua. How much survives? Are the local variable names still there? Repeat the decompile on guard_strip.luac, the stripped build, and see what differs, and whether the logic is still readable. Finally, using only the EXPECTED array and the transform, work out the valid license key yourself by inverting the transform in a few lines of Python, then run lua guard.lua and type it in to confirm.

Two questions to think about. Why does stripping remove local variable names but not the logic? And if the file turned out to be LuaJIT (\x1bLJ instead), would unluac read it, and which tool would you need instead?

Show solution

Compiling and recognizing the magic. After luac -o guard.luac guard.lua, opening it with xxd guard.luac | head shows:

00000000: 1b4c 7561 5400 1993 0d0a 1a0a ...
          \x1b L u a |version byte 0x54 = Lua 5.4

1B 4C 75 61 is \x1bLua, confirming this is standard Lua and not LuaJIT (which would be \x1bLJ). The fifth byte, 54, means Lua 5.4 (it would be 53 with luac from Lua 5.3). This identification step matters because picking the wrong decompiler breaks everything right away.

Decompiling the unstripped build. Running java -jar unluac.jar guard.luac > guard_out.lua gives back code very close to the original. Because the unstripped bytecode still carries debug info, unluac recovers the local variable names (transform, EXPECTED, check, key), the string constants ("Enter license key: ", "Correct! Welcome.", "Nope."), and the loop and if structure. The array EXPECTED = {109, 119, 100, 99, 55, 54, 57, 60, 42} shows up intact in the constant pool.

Decompiling the stripped build. With guard_strip.luac (compiled with -s), the debug info is gone. unluac still decompiles it, but the local variable names are gone, replaced by generated names like A0_1, L1_2, L2_3, and local function names are gone too. The string constants and the EXPECTED array are still there, since they live in the constant pool rather than in debug info. The entire logic, the for loop, the (c + i) % 256 operation, the comparison, is still complete and readable. Stripping only removes labels meant for human readers, not instructions. The bytecode still has to contain every opcode needed to run, so the logic can always be recovered.

Computing the valid license key. The check is EXPECTED[i] == (byte(key[i]) + i) % 256, with i counting from 1. Inverting it gives byte(key[i]) = (EXPECTED[i] - i) % 256:

EXPECTED = [109, 119, 100, 99, 55, 54, 57, 60, 42]
key = ''.join(chr((EXPECTED[i] - (i + 1)) % 256) for i in range(len(EXPECTED)))
print(key)   # lua_2024!

The valid license key is lua_2024!. I checked this in Python both ways. Building EXPECTED from lua_2024! with the forward formula gives exactly the array in guard.lua, and inverting it gives exactly lua_2024! back. With lua installed, running lua guard.lua and typing lua_2024! prints Correct! Welcome.

On why stripping loses names but not logic, variable and function names are metadata for humans, while the Lua virtual machine runs on register indices. Removing names doesn’t affect execution, so the bytecode still has every instruction it needs and the logic can always be rebuilt.

On LuaJIT, the answer is no, unluac only understands standard Lua bytecode. A \x1bLJ file needs ljd or luajit-decompiler-v2 instead.

Key takeaways

Embedded Lua is usually plain text you can read directly, and only the bytecode form needs a decompiler. There are two different families, standard Lua (magic \x1bLua, use unluac/luadec) and LuaJIT (magic \x1bLJ, use ljd), so identify first. The version byte after the magic (51/52/53/54) decides the decompiler.

Stripped bytecode only loses local variable names, the logic is still there. For encrypted scripts, dump from runtime by hooking luaL_loadbuffer/lua_load with Frida to get the clean bytecode. Tables are central to Lua, and in t:method() self is the hidden first parameter.
