Lesson 16.2: XOR, RC4 and custom Base64
These are the three data transformations I run into most when taking apart crackmes and malware, which are XOR, RC4, and Base64 with a shuffled alphabet. They cover most of the cases where a string looks like garbage. All three can be recognized by eye and reversed with a few lines of Python. This lesson shows how to spot them and write the decoder.
XOR
XOR is everywhere because it reverses itself. A ^ key ^ key == A. Encryption and decryption use one function, one line of code, no library. Malware authors are lazy and XOR suits that.
In assembly, an XOR loop looks like this:
loop:
mov al, [rsi+rcx] ; take one byte of ciphertext
xor al, dl ; XOR with the key (here dl holds a 1-byte key)
mov [rdi+rcx], al ; write out the decoded byte
inc rcx
cmp rcx, rbx ; reached the length yet
jl loop
A loop that walks through a buffer and XORs each byte with a constant or a value from a key array is almost certainly a string encryption or decryption routine. There are three variants. With a single-byte key, every byte is XORed with the same value. That’s the easiest, and you can brute-force all 256 possibilities. With a multi-byte (rolling) key, each byte is XORed with key[i % len(key)], the key repeating in a cycle, which is very common. In a running XOR, the next byte depends on the previous one (for example XOR with the byte just decoded), which is less common.
Finding the key: known plaintext
The best trick with XOR is the known-plaintext attack. If you can guess part of the plaintext (for example the flag always starts with flag{, or a config JSON always opens with {"), XOR that part of the ciphertext with the known plaintext and you get the key:
1
key[i] = ciphertext[i] ^ plaintext[i]
Do the first few bytes and the key shows up. If the key is short and repeats, you see the period right away. The lab at the end of this lesson does exactly this.
RC4
RC4 is a stream cipher often seen in malware because it’s compact and needs no library. It has no distinctive constants like AES or SHA, so findcrypt can’t catch it. You recognize it by its structure, which is easy to spot once you know it.
First, a 256-byte array (S-box) is initialized with 0, 1, 2, …, 255. A loop doing S[i] = i 256 times is the first sign. Second comes the KSA loop (Key Scheduling), a 256-iteration loop that permutes S based on the key, written as j = (j + S[i] + key[i % keylen]) & 0xFF; swap(S[i], S[j]). Third is the PRGA loop (keystream generation), written as i = (i+1) & 0xFF; j = (j + S[i]) & 0xFF; swap; k = S[(S[i]+S[j]) & 0xFF] and then XOR k with the data.
A sequentially initialized 256 array, then swaps with AND 0xFF (mod 256) all over, is RC4. RC4 is symmetric, so you only need the key to decrypt (usually near the KSA section, or a hardcoded string in the binary). Copy the algorithm into Python, pass in the key, run it.
Custom Base64
Standard Base64 uses the 64-character alphabet A-Za-z0-9+/. Many programs change the order of this alphabet, so the encoded string looks like Base64 but decodes to garbage with a standard tool. Beginners see a Base64-shaped string (letters, digits, sometimes = at the end), throw it into CyberChef, get garbage and give up.
What you need is the 64-character alphabet table in the binary. It usually sits in .rdata as a string of 64 consecutive characters, for example ZYXWVUTSRQPO.... Once you have the custom table, decoding is just mapping back to the standard table and decoding normally:
1
2
trans = bytes.maketrans(CUSTOM_ALPHABET, STANDARD_ALPHABET)
plaintext = base64.b64decode(ciphertext.translate(trans))
Suspect custom Base64 when the string only has 64 distinct characters, the length is a multiple of 4 (with = padding), and standard base64 gives garbage but the length fits. Then go look for the alphabet table.
Copy the algorithm, don’t rerun the binary
For all three, the fastest approach is not to debug byte by byte in the binary. Read enough to understand the algorithm and rewrite it in Python. Python has base64 built in, arbitrary-size integers and compact bitwise syntax. An encryption routine that takes a whole session to trace in a debugger is usually ten lines of Python once you understand it.
Lab
Here are three ciphertexts, each produced with a different technique. Recognize which is which and write Python to decrypt them before you open the solution. The data comes from make_data.py and was actually run:
1
2
3
XOR ciphertext (hex): 34295353293d5d460d2c416b373357462b325a5120204f
RC4 ciphertext (hex): ff0e15f7a4b880dcaef6bffa2e815a19c83db06649fea703c7b292b03442d2
Custom-Base64: AncsA6gqwCM9y78uBnUaAGB9C7UhxTssBnE9uJ==
A few hints. All three plaintexts have the form flag{...}, which is known plaintext you can use. The third string looks like Base64 (64-character alphabet, == padding) but standard base64 decodes it to garbage, so look for a shuffled alphabet (it’s in make_data.py). For RC4 the key is s3cr3t, assuming you pulled it out of the KSA part of a binary.
For the XOR sample, use flag{ as known plaintext, find the key and decrypt the whole string. For RC4, copy the algorithm into Python, pass in the key and decrypt. For the custom Base64, take the custom alphabet, map it back to the standard one and decode. You can rerun everything with:
1
2
python3 -I make_data.py # regenerate the three ciphertexts
python3 -I solve.py # the reference solution
Show solution
Everything was actually run with Python 3.11.9, and the full script is solve.py.
For the multi-byte XOR, the ciphertext begins with 34 29 53 53 29 and the plaintext is known to begin with flag{ (66 6c 61 67 7b). XORing the two together gives:
1
0x34^0x66=0x52='R' 0x29^0x6c=0x45='E' 0x53^0x61=0x32='2' 0x53^0x67=0x34='4' 0x29^0x7b=0x52='R'
The key characters that appear are R E 2 4 R ..., repeating after 4 characters, so the real key is RE24 (length 4). Decrypting the whole string:
1
[XOR] key = b'RE24' -> plaintext = flag{xor_is_everywhere}
For RC4, the key s3cr3t comes from the KSA code. Copy the KSA and PRGA exactly into Python and XOR the keystream with the ciphertext:
1
[RC4] plaintext = flag{rc4_has_no_magic_constant}
There’s no constant for findcrypt to catch. You recognize RC4 only by the 256-entry array initialized to 0..255 and the two swapping loops with & 0xFF.
For the custom Base64, the alphabet is ZYXWVUTSRQPONMLKJIHGFEDCBAzyxwvutsrqponmlkjihgfedcba9876543210+/, which reverses the letter and digit parts relative to the standard one. Map the custom alphabet back to the standard one and then call base64.b64decode:
1
[B64] plaintext = flag{custom_base64_alphabet}
Known plaintext is the most effective attack on XOR, since you only need to guess the first few bytes right. RC4 is recognized by structure and not by constants. And a Base64 that decodes to garbage is usually a shuffled alphabet.
Key takeaways
A loop that XORs a buffer with a constant or key array is a string encryption routine, and known plaintext gets you the key. RC4 has no magic constant. You recognize it by the 256 array initialized 0..255 and the two permutation loops with mod 256, and finding the key is enough to decrypt because it’s symmetric.
For custom Base64, find the 64-character alphabet table in the binary, map it back to the standard table, then decode. Overall the fastest way is to understand the algorithm and rewrite it in Python rather than trace byte by byte.
