Lesson 18.1: Scripting the decompiler

Some jobs in reverse engineering repeat until they’re boring, such as decrypting the same kind of string encryption for three hundred strings, mass-renaming functions by some rule, marking every call to an API. Doing it by hand is slow and error-prone. Write a script and let the decompiler do it.

All three big platforms have an API. IDA has IDAPython, Ghidra has Java/Python scripting, Binary Ninja has a Python API. The idea is the same, only the syntax differs. This lesson focuses on IDAPython because it’s the most common, then touches on the other two.

When it’s worth writing a script

Don’t script everything. My rule is that if you’re about to do something more than a dozen times the same way, or apply a transformation at many locations, you script it. Typical cases are decrypting encrypted strings in bulk and putting a comment next to each, renaming functions by pattern (for example every function that calls print_error with a fixed error code), finding all the places that call a suspicious API and listing the parameters, marking crypto constants, bulk patching, and extracting data tables.

If you only do it once or twice, doing it by hand is faster.

IDAPython: three groups of functions

IDAPython is split into a few modules. The three used most are idautils, which has convenient iterators (Functions() walks every function, XrefsTo(ea) lists xrefs), idc, which has the old script-style functions (read/write bytes, set comments, rename) and is easy to use, and idaapi / ida_*, which is the full low-level API.

A few basic operations:

import idautils, idc, ida_bytes, ida_name

# walk every function and print its name
for ea in idautils.Functions():
    print(hex(ea), idc.get_func_name(ea))

# read n bytes at an address
data = ida_bytes.get_bytes(ea, n)

# set a repeatable comment at an address
idc.set_cmt(ea, "decrypted string: hello", 1)

# rename an address
ida_name.set_name(ea, "decrypt_string", ida_name.SN_CHECK)

# find every place that calls a function
for xref in idautils.XrefsTo(target_ea):
    print(hex(xref.frm))

That’s a lot of function names, but you only need to remember a few, which are walk, read bytes, set comment, rename, get xrefs. Look up the rest when needed.

Example: bulk XOR string decryption

Suppose you’ve reversed a binary that encrypts all its strings with a one-byte XOR key 0x5A, and the encrypted strings sit in a data section. Doing three hundred strings by hand would make you quit. A script takes thirty seconds:

import idautils, idc, ida_bytes

KEY = 0x5A

def xor_decrypt(data, key):
    return bytes(b ^ key for b in data)

# suppose each encrypted string is referenced through a call decrypt_string(ptr, len)
# we find every xref to decrypt_string and then read the arguments
decrypt_ea = idc.get_name_ea_simple("decrypt_string")

for xref in idautils.XrefsTo(decrypt_ea):
    call_ea = xref.frm
    # (depends on the binary) trace back up to get the pointer and length passed in
    # for illustration here: assume ptr and length are already known
    ptr = idc.get_operand_value(idc.prev_head(call_ea), 1)
    length = 16
    enc = ida_bytes.get_bytes(ptr, length)
    if enc:
        dec = xor_decrypt(enc, KEY).split(b"\x00")[0].decode("latin1")
        # put the comment right at the call site, so the pseudocode shows it directly
        idc.set_cmt(call_ea, f"str: {dec}", 1)
        print(hex(call_ea), dec)

The specific code changes with every binary. What carries over is the pattern, which is to find an anchor (the decrypt function, a constant, a byte pattern), walk every location, apply the transformation, write the result back as a comment or a name. After running it, open the pseudocode again and every call has its real string annotated, and you read it like source code.

Finding byte patterns

Often you need to find a byte sequence (for example the prologue of a type of function, or a crypto constant):

import ida_search, ida_bytes

# find the byte string "48 8B 05" starting from the start of the program
ea = ida_bytes.find_bytes("48 8B 05", idc.get_inf_attr(idc.INF_MIN_EA))
while ea != idc.BADADDR:
    print(hex(ea))
    ea = ida_bytes.find_bytes("48 8B 05", ea + 1)

Ghidra scripting

Ghidra lets you write scripts in Java or Python (Jython). The central API is FlatProgramAPI (the functions getFunctionManager, getInstructionAt, setComment, createLabel). A Python example in Ghidra:

# Ghidra Python (Jython)
fm = currentProgram.getFunctionManager()
for func in fm.getFunctions(True):
    print(func.getName(), func.getEntryPoint())

For automation, Ghidra’s headless analyzer is the useful part. It runs the analysis and scripts from the command line, without opening the GUI, which is good for processing binaries in bulk:

analyzeHeadless /path/to/project MyProject -import target.exe -postScript MyScript.py

Use headless when you have a hundred malware samples and need to extract the same thing from each (for example config, IOCs). Write one script, run it as a batch.

Binary Ninja API

Binary Ninja has a Python API that many people find the cleanest, and it can access the IL layers (BNIL, which covers LLIL, MLIL, HLIL). Example:

# Binary Ninja
import binaryninja as bn
with bn.load("target.exe") as bv:
    for func in bv.functions:
        print(func.name, hex(func.start))

Working on the IL instead of raw assembly lets you write architecture-independent analyses (the same script runs for both x86 and ARM), which is good for automatic deobfuscation.

Which one to choose

It depends. If you live in IDA, use IDAPython. If you need something free that does batches, use Ghidra headless. If you want architecture-independent analysis on IL, use Binary Ninja. They don’t exclude each other, and many people use all three depending on the job.

Lab

LAB 18.1Download the source files for this lab

Download all (.zip) src/decrypt_strings_ghidra.py src/decrypt_strings_ida.py src/strcrypt_demo.c

The task is to write a script that makes the decompiler decrypt a batch of encrypted strings automatically instead of by hand. Three files go with it. strcrypt_demo.c is a sample program with 3 strings XORed with a single byte (key 0x5A) and decrypted at run time, which you build into a real binary to dissect. decrypt_strings_ida.py is a sample IDAPython script that decrypts the XOR and sets a comment at each call, and decrypt_strings_ghidra.py is the sample Ghidra (Jython) script. Build and run the program:

gcc -O0 -o strcrypt_demo strcrypt_demo.c
./strcrypt_demo        # prints the 3 decrypted strings

Open strcrypt_demo in IDA or Ghidra and find the decrypt function and the arrays enc_1, enc_2 and enc_3. Work out the XOR key and the structure of the encrypted strings, in particular which byte terminates them. Then write (or adapt from the samples) a script that decrypts every string and puts the result as a comment right next to where it’s used, and reopen the pseudocode to check that the string comments appear. For a harder variant, change the key to a multi-byte one and generalize the script.

One hint is that every real binary differs in how it passes the pointer into the decryption function, so the part of the sample script that fetches ptr needs adjusting to your binary. The approach stays the same, which is to find an anchor, walk the locations, apply the transform, write the comment. Try it yourself before opening the solution.

Show solution

Observing the binary

strcrypt_demo contains a function decrypt(enc, out) with a loop that XORs each byte with 0x5A and stops when it meets the byte 0x5A (because the original terminating byte 0x00 becomes 0x5A after XOR with 0x5A). The three arrays enc_1, enc_2 and enc_3 are the encrypted strings. The key is 0x5A, and the terminator in encrypted form is 0x5A.

Quick decryption in Python (no IDA needed)

KEY = 0x5A
def dec(e):
    out = ""
    for b in e:
        if b == KEY: break
        out += chr(b ^ KEY)
    return out

Real result (built and run)

Running ./strcrypt_demo prints:

Hello, reverser!
secret_flag_42
api: VirtualAlloc

These three strings are also exactly what you get by applying XOR 0x5A to the three enc_* arrays. The string-decryption scripts (IDAPython and Ghidra) reproduce them and then set a comment at each decrypt call, so when you reopen the pseudocode you see the real strings immediately without chasing them by hand.

The string api: VirtualAlloc is a typical example of malware hiding API names with XOR to avoid being caught through Imports or strings, and a string-decryption script is a fast way to expose it. The same template repeats in every binary, which is to determine the key and the terminator, walk every string or call location, apply the XOR, and write the comment. With a multi-byte key, you only need to change b ^ KEY to b ^ KEY[i % len(KEY)].

The C part (strcrypt_demo.c) builds with gcc and gives exactly the three strings above. The IDAPython and Ghidra scripts are reference samples meant to be run in the matching tool, so run them there. The XOR decryption logic gives the correct result when checked independently in Python.

Key takeaways

Script when an operation repeats more than a dozen times or applies to many locations, and otherwise do it by hand. In IDAPython, five operations are enough, namely walk functions, read bytes, set comment, rename, get xrefs. For automatic deobfuscation, find an anchor, walk every location, apply the transformation, and write the result back.

Ghidra headless processes binaries in bulk without opening the GUI, and the Binary Ninja API works on BNIL so scripts are architecture-independent.

---
