Lesson 18.4: Binary diffing
Often the fastest way to learn what vulnerability a piece of software had is to read its patch. The vendor ships an update with a vague changelog line like “fixed some stability issues”, but where the binaries before and after the patch differ tells you where the bug was. Comparing two binaries to find what differs is called binary diffing, and when the two binaries are before/after a patch it’s called patch diffing.
This lesson shows the technique with an example that actually ran, using two versions of the same program, one with a bug, one patched, and how diffing points at the fixed function.
What it’s used for
There are three common situations. The first is patch diffing for vulnerability research, where you compare the old version and the patched one, find the fixed function, and understand the bug that was fixed. From there you can rebuild the vulnerability to write a detection signature, or verify that your own systems are safe. This is legitimate defensive work, and also how people research 1-days (a vulnerability that was just patched but many machines haven’t updated).
The second is comparing malware variants. Two malware samples from the same family share most of their code, and a diff shows what the attacker added or changed in the new variant, which helps update rules. The third is recovering already-known functions. You analyzed a binary thoroughly, and now you meet another binary that shares a library. A diff helps transfer function names and comments from the old one to the new one, so you don’t start over.
Tools
Diffing doesn’t compare byte by byte (almost every byte changes just because addresses shifted), it compares function structure, meaning control flow graph (CFG), number of blocks, number of calls, constants. Each pair of functions gets a similarity score from 0 to 1.
| Tool | Notes |
|---|---|
| BinDiff (Google, free) | The industry standard. Export the two analyzed binaries from IDA or Ghidra (in BinExport format) and compare them, and it shows a table of matched/unmatched functions with similarity. A function at 1.00 is identical, a function below 1.00 is worth a look. |
| Diaphora (open source, for IDA) | Also compares pseudocode, and imports results back into IDA to port names/comments. |
| ghidriff (Ghidra-based, command line) | Runs headless, outputs a markdown report, handy for automation and CI. |
| radiff2 (radare2) | Quick diff from the command line, radiff2 -A -C v1 v2 compares by function. |
A few concepts. A matched function is one where a corresponding pair was found between the two sides. An unmatched function exists only on one side, meaning a function that was added or removed. A matched function that differs is where a real change is. In patch diffing, go straight to the matched functions with similarity below 1.00.
A real example
Lab 18.4 has two versions of a small login program. The only difference in the source is in the copy_name function, where v1 copies the username with strcpy into a 16-byte buffer without checking the length (a classic stack buffer overflow), and v2 adds a length check before copying.
Build both with gcc -O1 and run objdump -d. This is copy_name from v1 (the vulnerable one):
<copy_name>:
push %rbx
sub $0x10,%rsp
mov %rdi,%rsi
mov %rsp,%rbx
mov $0x10,%edx
mov %rbx,%rdi
call __strcpy_chk ; copies directly, no length check
...
call __printf_chk
ret
And copy_name from v2 (the patched one):
<copy_name>:
push %rbp
push %rbx
sub $0x18,%rsp
mov %rdi,%rbx
call strlen ; NEW: measure the length first
cmp $0xf,%rax ; NEW: compare with 15
ja <copy_name+0x4c> ; NEW: too long, jump away to report an error
mov %rsp,%rbp
mov $0xf,%edx
mov %rbx,%rsi
mov %rbp,%rdi
call strncpy ; changed from strcpy to strncpy, limited to 15
movb $0x0,0xf(%rsp) ; NEW: manually set the NUL at the end
...
call __printf_chk
ret
; error branch "Name too long"
lea ...,%rdi
call puts
jmp ...
It’s obvious at a glance. The patched function has an extra strlen + cmp $0xf + ja group, and strcpy became a bounded strncpy. The new cmp is the bound check the old version lacked, so v1’s vulnerability is a buffer overflow when the name is longer than 15 characters. We found the bug without anyone telling us, only by comparing the two versions.
The other two functions, main and check_pin, are structurally identical between v1 and v2 (only the addresses are shifted). A diffing tool would score them at similarity close to 1.00 and skip them, while copy_name would stand out with a low similarity. That’s the one to read.
The patch diffing workflow
Start by getting two versions, before and after the patch (usually downloadable from the vendor, or extracted from the update package). Analyze each one in IDA/Ghidra and export in a diffable format (BinExport for BinDiff, or use Diaphora/ghidriff directly). Run the diff and sort the table by similarity ascending.
Skip the 1.00 functions, and focus on matched functions with low similarity and newly appeared unmatched functions. Read where the two functions differ. An added check, a dangerous API swapped for a safe one, a fixed size comparison, all of these show where a bug used to be. Finally, rebuild the scenario that triggers the bug in the old version to understand it and write a signature.
Common pitfalls
A compiler version or optimization flag change between the two builds drops similarity across the board even though the logic didn’t change, which creates noise, so compare two builds from the same toolchain when you can. A function inlined in one build and not in the other won’t match. In this lab I had to add __attribute__((noinline)) to keep copy_name a separate function, otherwise the compiler inlines it into main and the per-function diff isn’t clean anymore. And a big patch changes many functions at once, so filter for the ones related to the vulnerability and ignore the harmless changes.
Lab
The goal is to compare two versions of the same program, find the function that was changed and work out which vulnerability the patch fixed. There are two files. login_v1.c is the vulnerable version, with a stack buffer overflow in copy_name. login_v2.c is the patched version, which differs from v1 only in copy_name. Build both, keeping the functions separate so the per-function diff stays clean:
1
2
gcc -O1 -fno-stack-protector -o login_v1 login_v1.c
gcc -O1 -fno-stack-protector -o login_v2 login_v2.c
Use objdump -d login_v1 and objdump -d login_v2 to list the three functions main, copy_name and check_pin in each build. Compare main and check_pin between the two and decide whether they differ structurally, ignoring address shifts. Then compare copy_name, point out the instructions that appear only in v2 and say what that new group does. From the difference, work out what v1’s vulnerability is and which input triggers it. If you have the tools, run one of the following and compare, using radiff2 -A -C login_v1 login_v2, BinDiff (analyze both files in IDA or Ghidra, export BinExport and compare), or ghidriff login_v1 login_v2 and read the markdown report. To confirm the bug, run ./login_v1 AAAAAAAAAAAAAAAAAAAAAAAAAAAA 0000 (a name longer than 16 characters) and ./login_v2 with the same input and see which one crashes.
Some questions to think about. Why does diffing compare function structure better than raw bytes when only one function changed? If the patched version were built with a very different compiler from the old one, what would the diff look like and how would you reduce the noise? And in a real patch that changes 50 functions, how do you filter down to the ones related to the vulnerability?
Show solution
All the output below comes from a real run (gcc on Linux x86-64, -O1 -fno-stack-protector).
Both versions have main, copy_name and check_pin. check_pin is structurally identical in both (only the addresses differ):
; v1 (0x11a9) and v2 (0x11c9), identical content
cmp $0x1092,%edi ; 0x1092 = 4242
sete %al
movzbl %al,%eax
ret
main is structurally the same too, with the same cmp on argc, the call to copy_name, the call to strtol, the call to check_pin, and the same branches printing “PIN correct” and “PIN wrong”. A diffing tool would score main and check_pin at a similarity close to 1.00 and skip them.
copy_name in v1:
<copy_name>:
push %rbx
sub $0x10,%rsp
mov %rdi,%rsi
mov %rsp,%rbx
mov $0x10,%edx
mov %rbx,%rdi
call __strcpy_chk ; copies without limiting the source length
...
And in v2:
<copy_name>:
push %rbp
push %rbx
sub $0x18,%rsp
mov %rdi,%rbx
call strlen ; NEW
cmp $0xf,%rax ; NEW: compare the length with 15
ja <copy_name+0x4c> ; NEW: if longer, go report the error "Name too long"
mov %rsp,%rbp
mov $0xf,%edx
mov %rbx,%rsi
mov %rbp,%rdi
call strncpy ; strcpy became strncpy, limited to 15
movb $0x0,0xf(%rsp) ; NEW: set the terminating NUL by hand
...
The new group in v2 is strlen + cmp $0xf + ja. It measures the name length and, if it is 16 or more, jumps to the error branch instead of copying. And strcpy (really __strcpy_chk) became strncpy limited to 15 bytes, plus the manual NUL.
So v1’s vulnerability is that copy_name copies the user’s name into buf[16] on the stack without checking the length. Entering a name longer than 16 characters writes past the buffer, a stack buffer overflow. Any argv[1] of 16 characters or more triggers it, and the v2 patch adds a bound check to stop exactly that.
To confirm:
1
2
3
4
5
6
$ ./login_v1 AAAAAAAA...(40 A's) 0000
Aborted (exit code 134) # buffer overflow, caught/crash
$ ./login_v2 AAAAAAAA...(40 A's) 0000
Name too long # the new bound check stops it
exit 0
v1 crashes (exit 134 means SIGABRT, here because the fortified __strcpy_chk catches the overflow, and a raw build without fortify would instead corrupt the return address). v2 prints “Name too long” and exits cleanly. The diff pointed at the patched function, and the patched function showed the bug.
On the questions. Structural comparison beats byte comparison because inserting a function or a few instructions shifts every address after it, so nearly all the bytes change even when the logic doesn’t. Comparing the CFG (block count, call count, branch shape) isn’t affected by address shifts, so only the functions that really changed drop in similarity. With different compilers, similarity drops across the board because the same logic produces different assembly (instruction order, registers, different inlining). You reduce the noise by building both versions with the same toolchain when you can, or by diffing at a higher level (Diaphora compares pseudocode), and by looking at semantic changes and not just the similarity number. For a patch that changes 50 functions, you prioritize the functions that handle untrusted input (parsers, network, files), the ones that gained a bound or null check, and the ones that swapped a dangerous API for a safe one. Combine this with the changelog or CVE if there is one, and skip changes caused by refactoring or by changed display strings.
Key takeaways
Diffing compares function structure (CFG), not raw bytes, so shifted addresses don’t throw off the result. In patch diffing, matched functions with low similarity and new unmatched functions are what’s worth reading. A new bound check, or an API changed from strcpy to strncpy, is the classic sign of where a bug used to be.
BinDiff and Diaphora give a detailed GUI, while ghidriff and radiff2 are for command line and automation. Use the same toolchain for both builds to avoid similarity noise.
