Lesson 19.4: Extracting config and C2
Almost every piece of malware that can be controlled remotely carries a bit of config, such as the address of the command-and-control (C2) server, the port, the encryption key, a campaign id, a mutex name, a list of commands. If you extract that config, you have a map of the attacker’s infrastructure. It’s one of the most useful things an analyst can produce for threat intel, and it uses the crypto skills from Part 16 directly.
Why it’s worth the effort
A C2 domain pulled from one sample doesn’t only help you block that sample. A rule that blocks the domain/IP protects the whole organization, not just one machine. It also lets you pivot. From one C2 you can trace other samples on the same infrastructure, the same campaign, the same group. It supports takedown, since you can report the domain/IP to the registrar or provider to get it removed. And it helps classify the malware family, because the config structure is often distinctive for each family (Emotet, AgentTesla, Cobalt Strike…), so recognizing the config means recognizing the family.
A hash identifies one file, a C2 identifies a whole campaign.
Where the config lives and why you can’t just read it
If malware left the C2 domain as a plain string in the binary, strings would pull it out, and so would every antivirus. So authors almost always hide it. Common ways are an encrypted blob in a data section (usually XOR, RC4, AES, see Part 16) that is decrypted at runtime right before use, and compression (zlib, LZ) before encryption. Others are stack strings built one character at a time with mov instructions so they don’t sit together as a string, and values computed at runtime by an algorithm (DGA, domain generation algorithm) instead of being stored.
In all cases the config on disk is a block of meaningless bytes, and it only becomes a readable string in memory, in the short moment before the malware uses it. Your job is to get it out, by the static or the dynamic route.
Three ways to extract
The static way: understand the algorithm and solve it yourself
This is the cleanest way and teaches you the most. First find the config blob. Signs are a data region with higher entropy than its surroundings, or one with a magic/marker, or one that an init function points to. Many families put a short marker before the blob (for example four identifying bytes).
Then find the decryption function by tracing the xrefs to that blob. The first function that touches it is usually the decryptor. Read it to identify the algorithm. A loop with a per-byte xor is XOR, a 256-byte array being swapped is RC4, an S-box is AES (identified as in Lessons 16.1 to 16.3). Next get the key, which may be a constant right in the code, or computed from a string, or sitting next to the blob. Finally rewrite it in Python by copying the algorithm and key and decrypting, like in Lessons 16.2 and 16.4. The result is a readable config.
The upside is that you don’t need to run the sample, so it’s completely safe, and the script is reusable for every sample in the same family. A good config extractor keeps paying off.
The dynamic way: let the malware decrypt it and grab it
When the algorithm is too tangled to solve statically (multiple layers, obfuscated), let the malware do the work itself. Run the sample in an isolated lab (Lesson 0.3), under a debugger. Set a breakpoint right after the decrypt function, or at a function that takes the decrypted config (for example a network connect function that takes the domain as a parameter). When it stops, read the memory region holding the decrypted config and dump it.
It’s fast, and you don’t need to fully understand the algorithm. The downside is that you have to run the real sample, so you need a sealed lab, and anti-debug/anti-VM (Part 15) can get in the way.
The automatic way: sandbox and config extractors
CAPE/CAPEv2 has ready-made config extractors for lots of common malware families. Feed the sample in, and it unpacks, decrypts and prints the config itself. Try it before doing it by hand. When you hit a family with no extractor yet, you write one (usually in Python, following the static route above) and contribute it back. That’s how the community expands CAPE.
Example workflow on an XOR then RC4 blob
Suppose you’ve reversed the decryptor and it works in two layers, which are RC4 with a string key, then a per-byte XOR with one byte. To decrypt, you undo the layers in the reverse of the author’s encryption order. In the accompanying lab, the 157-byte blob starts with the marker CFG0, then a 4-byte little-endian length, then the encrypted data. The Python extractor, actually run, gives:
1
2
3
4
5
6
7
8
[+] Extracted C2 config:
{
"c2": ["cdn.example-fake.test", "203.0.113.45"],
"port": 8443,
"campaign": "DEMO-2024-01",
"mutex": "Global\\FakeMwDemoMutex",
"sleep": 60
}
From a block of bytes 43 46 47 30 95 00 00 00 f3 56 96 16 ... to a complete set of IOCs. That’s what this lesson is about. (The config in the lab is made up and harmless, with domains from the non-routable TEST-NET range.)
Understand the C2 protocol too
Once you have the config, the next step is understanding how the malware talks to the C2, including data framing, encryption on the wire, commands and responses. This is protocol reversing from Lesson 18.7, applied to the malware’s network stream. Once you understand the protocol you can write network detections, impersonate the C2 to observe (sinkhole), or decrypt traffic you’ve captured.
Sharing IOCs responsibly
The IOCs you extract should be shared so the community can defend together, but do it properly. Post them to a threat intel platform (MISP, VirusTotal, abuse.ch) with clear context. Distinguish real C2s from legitimate domains being abused, since a lot of malware uses real cloud/CDN services as intermediaries, and blocking blindly means blocking a harmless service by mistake. And don’t publish information that tips the attacker off too early if there’s a coordinated takedown underway.
Same spirit as responsible disclosure in Lesson 0.2, where you share to protect, not to show off.
Lab
This lab practices extracting a C2 config from an encrypted blob using a fake and harmless sample. There is no real malware and no network connection, and the domains come from the non-routable TEST-NET range. There are two files. build_sample.py creates config_blob.bin, a fake C2 config blob that is XORed with one byte and then RC4-encrypted, packed with the marker CFG0 and a length. extractor.py is a reference config extractor that reverses it and prints the IOCs. You only need python3.
Run python3 -I build_sample.py to create config_blob.bin. Open it in a hex editor and find the CFG0 marker and the 4-byte little-endian length field right after it. Pretend you don’t know the algorithm yet. The blob has high entropy and no readable strings, which is the real situation when you meet malware. Then read build_sample.py as if it were what you just reversed out of the sample’s decryptor, with two layers (RC4 with a string key and then a one-byte XOR) plus the two keys.
Now rewrite the extractor from scratch (don’t copy extractor.py). Read the file, find CFG0, take the length, cut out the blob, undo the RC4 and then remove the XOR, parse the JSON and print the C2, port, mutex and campaign. Finally, compare your result with extractor.py.
Some questions to think about. Why must you do the RC4 first and only then remove the XOR, and not the other way around? If you can’t find the RC4 key in the code (for example the key is computed from another string at runtime), which route do you switch to? And why can a config extractor written once be used for many different samples of the same family?
Show solution
This is a real run:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
$ python3 -I build_sample.py
Created config_blob.bin, size: 157 bytes
Original plaintext (printed for comparison only, a real binary does NOT have this line):
{"c2":["cdn.example-fake.test","203.0.113.45"],"port":8443,"campaign":"DEMO-2024-01","mutex":"Global\\FakeMwDemoMutex","sleep":60,"rc4_marker":"cfg"}
XOR key 1 byte: 0x6b
RC4 key: s3cr3t_campaign_key
$ python3 -I extractor.py config_blob.bin
[+] Extracted C2 config:
{
"c2": [
"cdn.example-fake.test",
"203.0.113.45"
],
"port": 8443,
"campaign": "DEMO-2024-01",
"mutex": "Global\\FakeMwDemoMutex",
"sleep": 60,
"rc4_marker": "cfg"
}
[+] IOCs extracted:
C2: cdn.example-fake.test
C2: 203.0.113.45
Port: 8443
Mutex: Global\FakeMwDemoMutex
Campaign: DEMO-2024-01
The hexdump of the start of the blob (the marker CFG0 = 43 46 47 30, then the length 95 00 00 00 = 149 bytes of data):
1
2
00000000: 4346 4730 9500 0000 f356 9616 4a5d 73b5 CFG0.....V..J]s.
00000010: 4336 e770 031d 82c6 3b66 28c9 ad03 ff7e C6.p....;f(....~
To locate the blob, the marker CFG0 is what you find with strings or by searching for the bytes in a hex editor. Right after it come 4 little-endian bytes giving the length of the encrypted part (95 00 00 00 = 0x95 = 149). Cut exactly 149 bytes from offset marker+8.
On the order of decryption, the author encrypted in the order plaintext, then 1-byte XOR, then RC4. To recover it you must do the reverse, which is RC4 first (RC4 is symmetric, so running it again with the same key decrypts), and only then remove the outer XOR layer. The wrong order gives garbage. That answers the first question, since whichever layer was wrapped last gets peeled first.
For the keys, in the lab the XOR key 0x6B and the RC4 key s3cr3t_campaign_key are constants in the decryptor. With a real sample you read them from the code or from data next to the blob.
For parsing, once decrypted to JSON you just read the fields. With a real family the config may be a binary struct and not JSON, in which case you parse by offsets (using the skills from Lesson 18.7).
On the questions. You do RC4 first because it was applied last, so it has to be peeled off first. Always unwrap in the reverse order of the wrapping. If the key is computed at runtime, switch to the dynamic route. Set a breakpoint after the decryption function in an isolated lab and dump the decrypted config from memory, without needing to rebuild the key generation algorithm. And a config extractor written once works for many samples because samples of the same family use the same algorithm and the same config structure, differing only in the data and sometimes the keys. An extractor with the keys as parameters handles a whole batch of samples. That’s why CAPE has per-family extractors.
The whole config is made up and harmless, the domains belong to the documentation and TEST-NET ranges, and there is no network behavior at all.
Key takeaways
Config (C2, key, mutex, campaign) is the most valuable threat intel target, and one C2 identifies a whole campaign. It’s usually encrypted or compressed in the binary and only readable in memory at runtime.
There are three ways to get it, which are static (understand the algorithm and solve it in Python, clean and reusable), dynamic (dump after the malware decrypts it itself), and automatic (CAPE or write your own extractor). Identify the decryption algorithm following Part 16, get the key, and rewrite it in Python. Understand the C2 protocol per Lesson 18.7 to write network detections, and share IOCs responsibly, distinguishing real C2s from legitimate services being abused.
