Lesson 2.2: IDA for beginners
IDA is the name you hear most when you first get into this field, and it also scares off a lot of people in the first ten minutes. A screen full of windows, strange shortcuts, many sub_401000 names that tell you nothing. IDA isn’t really hard, it’s just big. This lesson covers what I use 90% of the time and skips the rest until you need it.
The series uses IDA Free as the baseline because it’s free and enough to learn x86/x64. The Pro version adds the Hex-Rays decompiler (the F5 key) and more architectures, but the basic operations are identical.
Opening a file for the first time
Drag a file into IDA and it shows a dialog asking for the file type and architecture. For a normal PE or ELF, leave the defaults and click OK, IDA detects it itself. Then it runs auto-analysis, where it scans the whole file, finds functions, separates code from data, and marks strings. Wait for the progress indicator at the bottom to finish (the text “AU: idle”) before you start working. Don’t click around while it’s still analyzing.
The windows you’ll use
IDA has a huge number of windows, but a day of work uses about five. If you close one by accident, reopen it through View > Open subviews.
The IDA View (disassembly) is where you read assembly. It has two modes, graph view (blocks connected by arrows, easy to see the flow) and text view (a linear listing), and Space switches between them. Beginners should use graph view to see the branches clearly. The Functions window, on the left, lists every function IDA found, and you double-click to jump to one. It shows the functions in a list.
The Strings window lists every string in the file and opens with Shift+F12. It’s the most useful window for beginners and I cover it below. Imports shows the API functions the program calls from external DLLs, and from that list you can guess what the program does (touches files, registry, network…). Pseudocode is the Hex-Rays output, C-like code, which you open with F5 when the cursor is inside a function (Pro version only).
Moving around
Reversing means constantly jumping between functions. A few operations are enough. G lets you type an address or name to jump straight to it. Double-clicking a function or variable name jumps to its definition, and double-clicking a string or constant jumps to where it’s defined. Esc goes back to where you just were, and Ctrl+Enter goes forward. You’ll press these two constantly.
Navigate IDA the way you navigate a web browser. Click a link (a function name), read, then Esc to go back. Once back/forward feels natural, you’re halfway there.
Three habits
This is the most useful part of the lesson. IDA doesn’t understand code by itself. What it does well is let you record your understanding on top of the code, and the more you record, the easier the next function is to read.
Rename (the N key)
Put the cursor on a function sub_401500, a variable v3, or a label, press N, and type a meaningful name. Just figured out that sub_401500 compares two strings? Rename it compare_password. Next time you see where it’s called, you read the meaning right away instead of opening it again.
Cross-reference (the X key)
Put the cursor on a function, a global variable, or a string and press X, and IDA lists every place that references it. See the string “Wrong password”? Press X on it and IDA shows which function uses it. That function is almost certainly where the password check is. Going backwards from data to code is the fastest way to locate things when you’re starting out.
Comment (the colon key)
Press : to add a comment to a line, ; for a repeatable comment (shown at every place that references it). As soon as you understand what a section does, write it down. Three days later your own comment saves you from reading it all again.
Start from strings
For most crackmes and small programs, the fastest way to find the interesting spot isn’t to read from main, it’s to go backwards from strings. Open the Strings window (Shift+F12) and look for a string that hints at logic, such as “Correct!”, “Wrong password”, “Access granted”, “Invalid license”. Double-click it to jump to where the string is defined in data, then press X to see which function uses it. Jump into that function and you’re standing in the middle of the checking logic.
It works because the program has to print a message to the user, so the message string always sits next to the code that decides what to print.
Decompile with F5
If you have the Pro version with Hex-Rays, put the cursor in a function and press F5, and IDA rebuilds C-like pseudocode. It’s much easier to read than assembly. But it’s a guess, not the original source, so it can translate slightly off, especially with heavily optimized or obfuscated code. You can still rename (N) and set types (Y) right in the pseudocode window, and the changes carry over to the assembly. When the pseudocode looks nonsensical, drop down to assembly to verify. I keep both windows open.
No F5? You can still do RE, you just read assembly more slowly. Ghidra (Lesson 2.3) gives you a free decompiler if you need one.
Lab
Here’s a small crackme to practice the workflow above, crackme01.c. It’s harmless and fine to run on a normal machine. The aim is to drill the IDA routine, which is to start from strings, use xrefs, rename, read the logic. Build it first. On Windows with the MSVC Developer Command Prompt:
1
cl /Fe:crackme01.exe crackme01.c
On Windows with MinGW:
1
x86_64-w64-mingw32-gcc crackme01.c -o crackme01.exe
On Linux:
1
gcc crackme01.c -o crackme01
Don’t open crackme01.c to read it. The whole exercise is finding the password without the source.
Run the program, type a random password and see what it prints. Then open the built file in IDA and wait for auto-analysis to finish (AU: idle). Open the Strings window (Shift+F12) and look for a message about a right or wrong password. Double-click it to land in the data, then press X to see which function references it. Jump into that function and find the sub-function that does the real checking, and rename it (N) to check_password. Inside it, find the secret string the input is compared against, rename variables so they read well and add comments (:). If you have Hex-Rays, press F5 to read the pseudocode and compare it with the assembly. Finally work out the correct password, run the program again and type it in to confirm you see “Correct!”.
A few questions to think about afterwards. Why is going from strings faster than reading from main? What does the program check before comparing the strings (a hint is to look at a length comparison)? And if there were no Strings window, how else could you locate the check function (a hint is to look at Imports, and functions like strcmp)?
Show solution
Don’t read this if you haven’t tried it yet. The correct password is:
1
R3v3rs3_M3
Type it into the program and you’ll see “Correct!”.
In the Strings window (Shift+F12) you see a few interesting strings, including Enter password: , Correct! Congratulations, you solved the crackme., Wrong password. Try again., and one that looks like a password, R3v3rs3_M3. It sits oddly among the messages. That’s the secret, because the programmer embedded the comparison string straight into the binary. Hardcoding a secret string in native code protects nothing, since it shows up in Strings immediately.
To confirm that R3v3rs3_M3 really is the password, double-click it and press X. IDA shows it being loaded inside one function, right before a call to strcmp (or strlen and then strcmp). Rename that function to check_password. The pseudocode (F5) of the check function looks roughly like this:
1
2
3
4
5
6
7
8
9
int check_password(const char *input)
{
const char *secret = "R3v3rs3_M3";
if (strlen(input) != strlen(secret)) // check the length first
return 0;
if (strcmp(input, secret) == 0) // then compare character by character
return 1;
return 0;
}
Two things to notice. The program compares lengths first (a cmp/jne pair in the assembly), a small optimization that avoids comparing strings when the lengths already differ. Then strcmp compares everything and returns 1 on a match. Back in main, the return value of check_password decides whether to print “Correct!” or “Wrong password”, following the usual cmp/test plus j* pattern from Lesson 1.3.
If you don’t use Strings, there’s another route. Open Imports, find strcmp and strlen, and press X on strcmp to go to where it’s called, which also lands you in the check function. Starting from an API is the second way in after starting from strings.
To take away, hardcoded strings are the first weakness of every beginner crackme, and the two fastest ways to locate logic are from strings (Shift+F12 then X) and from imports (strcmp, strcpy and so on, then X). Renaming a function as soon as you understand it makes main read much more clearly.
Common pitfalls
A common mistake is starting to read from the entry point and getting lost in the runtime’s init code, when going from strings or imports is much faster. Another is forgetting to rename, leaving sub_xxx and v1 v2 v3 as they are, and half an hour later not remembering which function is which. Some people click around before auto-analysis is done, see wrong results, and panic. And it’s easy to mix up the static address in IDA with the real address at runtime in the debugger (ASLR, see Lesson 1.2).
Key takeaways
Wait for auto-analysis to finish (AU: idle) before working. The five main windows are IDA View, Functions, Strings (Shift+F12), Imports, and Pseudocode (F5). Space switches graph/text, G jumps to an address, and Esc/Ctrl+Enter are back/forward.
The three habits are rename (N), xref (X), and comment (:), and you should record your understanding as soon as you have it. Going backwards from strings through X is the fastest way to locate logic. The full shortcut table is in the cheatsheet.
