Lesson 1.3: x86/x64 Assembly (1), registers and common instructions

Many people are scared of assembly because they think they have to memorize hundreds of instructions. You don’t. Most of the time you only run into about twenty of them over and over. Learn those and you can read most code. This lesson covers them.

Registers

The CPU doesn’t compute directly on RAM. It copies data into small, very fast memory cells inside itself called registers, works on it there, then writes it back. So understanding registers is half of assembly.

On x64 there are 16 general purpose registers, each 64 bits:

rax rbx rcx rdx rsi rdi rbp rsp
r8  r9  r10 r11 r12 r13 r14 r15

One thing that confuses beginners is that the same register has several names depending on the size you use. Take rax as an example:

rax  = 64 bit (the whole thing)
eax  = low 32 bits of rax
ax   = low 16 bits
al   = lowest 8 bits

So if you see eax and rax in the same function, it’s one register, just a different number of bits. Same for rbx/ebx/bx/bl, rcx/ecx/cx/cl, and so on. For r8 to r15 it’s r8/r8d/r8w/r8b.

A few registers have conventional roles. Remember them, reading code gets a lot faster:

Register	Usual role
rax	A function’s return value lives here. After a call, look at rax to see what the function returned
rsp	The top of the stack pointer (stack pointer). Don’t overwrite it carelessly
rbp	The base pointer of the stack frame, used to reference local variables
rip	The instruction pointer, points to the next instruction to run. Can’t be assigned directly
rcx rdx r8 r9	First 4 function parameters on Windows x64
rdi rsi rdx rcx r8 r9	First 6 parameters on Linux/macOS x64

Parameter passing is covered in lesson 1.4. For now just know that the return value is in rax and the parameters are in the registers above.

There’s also the flags register (RFLAGS). You don’t read it directly, you see it through the jump instructions. The important flags are ZF (zero flag, set when the result is 0), SF (sign flag, negative), CF (carry) and OF (overflow).

Syntax: Intel vs AT&T

There are two ways to write assembly and you can tell them apart quickly. Intel (IDA, x64dbg, Windows) writes mov eax, 5 to mean eax = 5, destination first. AT&T (GDB default, Linux) writes mov $5, %eax, with % before registers, $ before numbers, and the destination last.

This series uses Intel because it’s close to the Windows tools we use a lot. In GDB, type set disassembly-flavor intel to switch and save yourself a headache.

The instructions you must know

mov, lea: moving data

mov eax, 5          ; eax = 5
mov eax, ebx        ; eax = ebx
mov eax, [rbx]      ; eax = the value at address rbx (square brackets = memory access)
mov [rbx], eax      ; write eax to address rbx

The square brackets [...] matter. With brackets it’s a memory access at that address, without brackets it’s the value itself. If you mix these up you’ll misread the whole function.

lea (load effective address) also confuses beginners:

lea rax, [rbx+rcx*4+8]   ; rax = rbx + rcx*4 + 8, does NOT access memory

lea computes an address and puts it in a register, but it doesn’t read memory there. Compilers also use lea for plain math (multiply, add) because it’s compact. So when you see lea, don’t assume it’s an address, often it’s just arithmetic.

add, sub, inc, dec: arithmetic

add eax, 10     ; eax += 10
sub eax, ebx    ; eax -= ebx
inc eax         ; eax++
dec eax         ; eax--
imul eax, 3     ; eax *= 3 (signed)

xor, and, or, shl, shr: bits

xor eax, eax    ; eax = 0  (classic trick: xor with itself = 0, shorter than mov eax,0)
and eax, 0xFF   ; keep the lowest byte
or  eax, 1      ; set bit 0
shl eax, 2      ; shift left 2 = multiply by 4
shr eax, 1      ; shift right 1 = divide by 2

xor eax, eax just means “set to 0”. You’ll see it at the start of functions all the time. If you don’t recognize it, you might think something is being encrypted.

cmp, test, and the jumps: this is if/else

This group matters most for reading logic. The CPU has no “if” instruction. It does two steps. First it compares and sets flags. cmp a, b computes a minus b only to set the flags (the result is not stored), so if a == b then ZF is set. test a, b ANDs a with b and sets the flags, and test eax, eax is how you check “is eax equal to 0”. Second, it does a conditional jump based on the flags:

cmp eax, 10
je  somewhere      ; jump if eax == 10 (jump if equal)
jne somewhere      ; jump if eax != 10
jg  somewhere      ; jump if eax > 10 (signed)
jl  somewhere      ; jump if eax < 10 (signed)
ja  / jb           ; above / below (unsigned)

Remember that a cmp/test pair plus the j* right after it is one if statement in the source. Wherever you find the pair, you’ve found a branch. In a crackme, the cmp right before “Wrong password” gets printed is usually where the serial is compared.

jmp (unconditional) always jumps, like goto.

call, ret: calling functions

call 0x401500   ; call the function at 0x401500
ret             ; return to the caller

call pushes the return address onto the stack and then jumps to the function. ret pops that address and goes back. After call, the return value is in rax.

nop: does nothing

nop (no operation) does nothing at all. It sounds useless, but it’s the first tool for patching. When you want to “delete” an annoying check without shifting other addresses, you overwrite it with nop. Lesson 17.1 uses it a lot.

Reading a real snippet

Here’s a simple check function, the kind you’d see in a crackme:

check_password:
    push rbp
    mov  rbp, rsp
    mov  eax, [rbp-4]      ; load a local variable (the length of the input string) into eax
    cmp  eax, 8            ; compare with 8
    jne  fail             ; if not 8, jump to fail
    mov  eax, 1            ; eax = 1 (correct)
    jmp  done
fail:
    xor  eax, eax         ; eax = 0 (wrong)
done:
    pop  rbp
    ret

Translating it back to C in your head:

int check_password() {
    int len = ...;       // local variable at [rbp-4]
    if (len != 8)        // cmp + jne
        return 0;        // the fail branch
    return 1;
}

This function only checks whether the input string is exactly 8 characters. You just read assembly and turned it into logic. That’s reversing. Get used to the cmp/jne pair and remember that rax is the return value, and that’s most of it.

Key takeaways

One register has several names by size, and rax(64)/eax(32)/ax(16)/al(8) are the same thing. rax is the return value and rsp is the top of the stack, with the first parameters in rcx rdx r8 r9 on Windows and rdi rsi rdx rcx r8 r9 on Linux. [...] means memory access while no brackets means the value itself, and lea computes an address or does arithmetic without reading memory. xor eax, eax means set to 0. A cmp/test pair plus j* is one if statement, which is how you read logic.
