Lesson 1.8: ELF and Mach-O
Last lesson cut open the Windows PE. Reversing doesn’t only happen on Windows though. Servers run Linux, Android is Linux at the core, and Macs and iPhones use their own format. PE is the format for Windows files, ELF is Linux’s and Mach-O is Apple’s. Know these three and you can read the header of almost every binary you’ll meet.
All three solve the same problem, which is packaging code, data, and the info on how to load it into memory. Learn one and the other two come fast. This lesson focuses on ELF because you’ll meet it most, then skims Mach-O and compares.
ELF
ELF (Executable and Linkable Format) is used for everything that runs on Linux, including executables, .so libraries, .o object files, even core dumps. It’s easy to recognize. The first 4 bytes are always 7F 45 4C 46, that is 0x7F followed by the ASCII characters “ELF”. Open any file in /bin with a hex editor and you’ll see it.
The header
The ELF header sits at the start of the file. The magic (7F 45 4C 46) confirms it’s ELF. The class says 32-bit (ELFCLASS32) or 64-bit (ELFCLASS64), and the endianness says little or big endian. The type is ET_EXEC (fixed-address executable), ET_DYN (shared object or PIE, can run at any address), or ET_REL (object file). The machine field gives the CPU architecture, such as x86-64, ARM, MIPS, RISC-V and so on. The entry point (e_entry) is the virtual address where code starts running, the same idea as PE’s AddressOfEntryPoint. The header also records the location of the program header table and the section header table.
Commands to read it:
1
2
readelf -h ./a.out # read the ELF header
file ./a.out # one-line summary: type, bits, dynamic/static, stripped or not
Two header tables
This is where ELF differs from PE and trips up a lot of people. ELF has two description tables for two different purposes.
The program header table tells the loader (the OS) how to load the file into memory at runtime. Its unit is the segment, a block mapped into memory with permissions (R/W/X). The section header table tells the linker and analysis tools which sections the file is divided into (.text, .data…). At runtime the loader doesn’t need it.
So segments are for running and sections are for analysis. A segment usually bundles several sections. The code segment, for example, contains both .text and .rodata. When a file is stripped the section headers may be trimmed, but the program headers can’t be missing, because the file couldn’t run.
1
2
readelf -l ./a.out # program headers (segments) + which sections belong to which segment
readelf -S ./a.out # section headers
Common sections
Many are like PE, just named a bit differently. .text is code with R-X permissions. .data holds initialized globals, RW. .bss holds globals equal to 0 and takes no space on disk. .rodata is read-only data, constants and strings, and your “Access denied” string is here. .plt and .got handle dynamic linking, covered below. .symtab and .strtab are the symbol and name tables, which is what gets cut when you strip. .dynsym and .dynstr hold symbols for dynamic linking. They don’t get stripped because they’re needed at runtime.
PLT and GOT
When a program calls printf from libc, at compile time it doesn’t know the address of printf, because libc is placed randomly by ASLR on each run. Linux solves this with the PLT/GOT pair. You’ll see these two names all the time in Linux reversing, so get them straight now.
The GOT (Global Offset Table) is a table of pointers. Each slot holds the real address of an external function, filled in at runtime. The PLT (Procedure Linkage Table) is a set of small code stubs in between. Your code doesn’t call printf directly, it calls printf@plt.
Lazy binding means the address is resolved only on the first call. On the first call to printf@plt, it jumps through the GOT to the dynamic linker’s resolver, finds the real address of printf, writes it into the GOT slot, and then makes the call. After that, printf@plt jumps straight through the GOT to the saved address.
Remember that call printf@plt means an external function is being called, and to see its real address at runtime you look at the matching GOT slot in the debugger. The GOT is also a classic attack target (GOT overwrite), but that’s the exploit side.
Stripped or not
Like PE, an ELF binary can keep or drop symbol info. If it’s not stripped, .symtab is still there and function and variable names show up in Ghidra/IDA, which makes life easy. If it’s stripped, .symtab is cut and only .dynsym remains. Imported library functions still show names, but the author’s own functions become sub_xxxx. Most real software and malware is stripped.
1
2
nm ./a.out # list symbols (says "no symbols" if stripped)
strip ./a.out # strip it yourself to see the difference
Mach-O
macOS and iOS use Mach-O. The way of thinking is like ELF but the names and a few details differ.
The magic is 0xFEEDFACE (32-bit) or 0xFEEDFACF (64-bit). Apple made it spell “feed face” on purpose. A Mach-O can also be a fat binary (universal binary), one file bundling several architectures, for example x86-64 and ARM64 for Intel and Apple Silicon machines. The magic of a fat file is 0xCAFEBABE. When reversing, you usually extract the architecture you need with lipo.
Load commands replace ELF’s program headers. They’re a list of instructions for the loader, covering which segment maps where, which libraries are needed, where the entry point is, what the code signature looks like. Mach-O also has segments, named in uppercase with two underscores, such as __TEXT (code, read-only) and __DATA (writable data). Inside each segment there are sections like __text and __cstring.
Tools on a Mac:
1
2
3
4
5
otool -hv binary # header and load commands
otool -l binary # list all load commands in full
lipo -info binary # see which architectures the file contains
lipo binary -thin arm64 -output binary_arm64 # extract one architecture
nm binary # symbols
Objective-C and Swift also have their own metadata sections for the runtime, but that’s for Part 12. Here you only need to get used to the Mach-O layout.
Comparing the three formats
| Concept | PE (Windows) | ELF (Linux) | Mach-O (Apple) |
|---|---|---|---|
| Magic | MZ then PE\0\0 | 7F 45 4C 46 | FEEDFACE/FACF, fat CAFEBABE |
| Memory loading description | Section table | Program header (segment) | Load commands (segment) |
| Code | .text | .text | __TEXT/__text |
| Read-only data | .rdata | .rodata | __TEXT/__cstring |
| Importing external functions | IAT | PLT/GOT | stubs / __la_symbol_ptr |
| Entry point | AddressOfEntryPoint | e_entry | LC_MAIN |
| Multiple architectures in one file | No | No | Yes (fat binary) |
All three tell the same story with different vocabulary. Learn ELF well and reading PE and Mach-O is mostly looking up names.
Lab
In this lab you dissect an ELF binary by hand with readelf, objdump, nm and file. You identify the file, find the entry point, list the segments and look at the PLT/GOT, then compare a stripped and a non-stripped build. You need a Linux environment. On Windows, WSL (wsl --install) or a light Linux VM is enough.
The sample program is hello.c. It calls a couple of library functions (printf and strlen) so you can see the PLT/GOT at work, and it has one internal function so the stripped and non-stripped builds differ in something visible. Build a normal copy and a stripped copy. If you can’t build, a system binary such as /bin/ls answers most of the questions.
1
2
3
gcc -O0 -o hello hello.c # normal build, symbols kept
gcc -O0 -o hello_stripped hello.c
strip hello_stripped # stripped build
Start with identification. Run file hello and read off the bit width, whether it’s dynamically or statically linked, and whether it’s stripped. Repeat with hello_stripped and compare. Next read the header with readelf -h hello and note the four magic bytes, the entry point (e_entry), and whether the type is ET_EXEC or ET_DYN. Modern gcc builds PIE by default, so it’s usually ET_DYN.
Then compare segments and sections. readelf -l hello shows the program headers (segments) and, at the bottom, the “Section to Segment mapping”. Find which loadable segment holds .text and what permissions it has (R E). readelf -S hello shows the section headers, where you should locate .text, .rodata, .data, .bss, .plt and .got. The string “Hello, ELF!” sits in one of them, and you can check with readelf -p .rodata hello.
For the PLT/GOT, use objdump -d -j .plt hello to see the PLT stubs. Then run objdump -d hello | grep -A3 '<main>:' and look for the calls to printf@plt and strlen@plt. Notice that main doesn’t call libc directly but goes through @plt. readelf -r hello prints the relocation table, which is the list of GOT slots that get filled with real addresses at run time.
For symbols, run nm hello and find main and secret_len. Then see what nm hello_stripped reports now, whether secret_len is still visible, and what happens to printf (try nm -D hello_stripped for the dynamic symbols). Finally, go back to the PE lesson (Lesson 1.7) and match things up by asking which PE field corresponds to the ELF entry point, and which PE mechanism corresponds to the PLT/GOT? Answer everything yourself before opening the solution.
Show solution
The output below comes from a gcc build on x86-64 Linux. Your addresses will differ, but the meaning is the same.
For identification, the two files look like this.
1
2
3
4
5
6
7
$ file hello
hello: ELF 64-bit LSB pie executable, x86-64, version 1 (SYSV),
dynamically linked, interpreter /lib64/ld-linux-x86-64.so.2,
... not stripped
$ file hello_stripped
hello_stripped: ELF 64-bit LSB pie executable, x86-64, ... stripped
It’s a 64-bit, little-endian (LSB) ELF, built as PIE (hence “pie executable”), dynamically linked to libc through the ld-linux interpreter. One copy is “not stripped” and the other is “stripped”, and the only difference between the two files is the symbol table.
The header looks like this.
1
2
3
4
5
6
7
$ readelf -h hello
Magic: 7f 45 4c 46 02 01 01 00 ...
Class: ELF64
Data: 2's complement, little endian
Type: DYN (Position-Independent Executable file)
Machine: Advanced Micro Devices X86-64
Entry point address: 0x1060
The magic is 7f 45 4c 46, that is 0x7F followed by “ELF”. The entry point 0x1060 isn’t main. It’s _start from the C runtime, which does its initialization and only then calls main, much like the CRT code that runs before main in a PE. The type is DYN rather than EXEC because it’s a PIE. A PIE can run at a random base (ASLR), so the addresses in the file are offsets from the base rather than absolute addresses.
For segments versus sections:
1
2
3
4
5
6
7
8
9
10
11
$ readelf -l hello
Program Headers:
Type Offset VirtAddr Flags Align
LOAD 0x001000 0x0000000000001000 R E 0x1000
LOAD 0x002000 0x0000000000002000 R 0x1000
LOAD 0x002xxx 0x0000000000003xxx RW 0x1000
...
Section to Segment mapping:
Segment ... .text ... <- inside the LOAD with flags R E
Segment ... .rodata ... <- LOAD with flags R
Segment ... .data .bss ... <- LOAD with flags RW
.text lives in a loadable segment with flags R E (read and execute, not write), while .data and .bss live in an RW segment. A segment groups several sections with the same permissions so the loader can map them in one go. Segments are for running and sections are for analysis.
1
2
3
$ readelf -p .rodata hello
[ 8] Hello, ELF!
[ 14] string length is %d
As expected, the constant strings are in .rodata.
For the PLT/GOT:
1
2
3
4
5
$ objdump -d hello | grep -A12 '<main>:'
0000000000001169 <main>:
... lea rax,[rip+0xe8c] # load the address of the "Hello, ELF!" string
... call 1050 <puts@plt> # printf("%s\n", msg) optimized into puts
... call 1060 ... # or strlen@plt depending on the build
main doesn’t call libc directly. It calls puts@plt or strlen@plt, which are stubs in the PLT. gcc often replaces printf("%s\n", x) with puts(x) when optimizing, so don’t be surprised to see puts.
1
2
3
4
5
$ readelf -r hello
Relocation section '.rela.plt' ...
Offset Info Type Sym. Name
0000000000003fc8 ... R_X86_64_JUMP_SLOT puts@GLIBC
0000000000003fd0 ... R_X86_64_JUMP_SLOT strlen@GLIBC
Each JUMP_SLOT line is a GOT slot (at offsets 0x3fc8, 0x3fd0 and so on) that the dynamic linker fills with the real address of puts or strlen the first time they’re called (lazy binding). Before the first call the GOT slot points back at the resolver, and afterwards it points straight at the function in libc.
For symbols:
1
2
3
4
5
6
7
8
9
10
$ nm hello | grep -E 'main|secret_len'
0000000000001169 T main
0000000000001145 t secret_len <- lowercase 't': local symbol
$ nm hello_stripped
nm: hello_stripped: no symbols
$ nm -D hello_stripped
U puts@GLIBC_2.2.5
U strlen@GLIBC_2.2.5
After stripping, nm sees nothing because .symtab has been cut, so secret_len and main lose their names. But nm -D (dynamic symbols, read from .dynsym) still lists puts and strlen, because imported functions need their names at run time for the linker to resolve them. Strip removes internal function names, not the names of imported library functions.
Finally, the comparison with PE. The ELF e_entry corresponds to the PE AddressOfEntryPoint. The PLT/GOT corresponds to the IAT (Import Address Table). .rodata corresponds to .rdata. A LOAD segment corresponds to a section mapped according to its characteristics, and the ld-linux interpreter corresponds to the Windows loader plus ntdll. Same structure, different names, so moving between Windows and Linux reversing is mostly translating vocabulary.
Key takeaways
The ELF magic is 7F 'E' 'L' 'F', Mach-O is FEEDFACE/FACF, and a fat binary is CAFEBABE. ELF has two tables, the program header (segments, for the loader to run) and the section header (sections, for analysis).
PLT/GOT is how Linux calls library functions, with lazy binding filling the real address into the GOT on the first call. Stripping cuts .symtab (internal functions become sub_xxx) but .dynsym stays, so imported function names are still visible. Mach-O can be a fat binary containing multiple architectures, and you use lipo to extract one. PE, ELF and Mach-O share the same ideas, only the names differ.
