Lesson 11.3: WebAssembly
When a web page does heavy work (games, crypto, encryption, image processing) that plain JavaScript can’t handle, people move that part to WebAssembly (WASM). For reversers WASM is familiar and a bit strange. It’s familiar because it’s bytecode for a stack-based VM, like the JVM or CPython from Parts 6 and 7. It’s strange because it doesn’t keep variable names and often hides the important logic on purpose. This lesson covers opening a .wasm file and reading it.
What WASM is, from a reverse angle
WASM is a compact bytecode format that runs in a sandbox in the browser (or in a runtime like wasmtime or Node). Two things to remember. It’s stack-based, so instructions push and pop operands on a stack, like Python bytecode, with no registers like x86. And it comes in two forms, .wasm is the binary (what the browser downloads) and .wat is the equivalent text that humans can read. Your first job is almost always turning .wasm into .wat.
Unlike native code, WASM can’t access system memory arbitrarily. It has a linear memory region (a flat byte array, growing in 64KB pages), a table (an array of function references, used for indirect calls), and it talks to JavaScript through imports/exports. The exported functions are where you should start reading.
Getting the .wasm file from the web
If the target is a web page, open the browser’s DevTools. In the Network tab, filter by wasm or look for a request ending in .wasm, then right-click to save. In the Sources tab, Chrome lists the loaded WASM modules, and you can view and save from there. Once you’ve saved the .wasm file you can work offline, no web page needed.
The wabt toolkit
wabt (WebAssembly Binary Toolkit) is the main set of tools. The most used commands:
1
2
3
4
wasm2wat app.wasm -o app.wat # binary to readable text (first step)
wasm-objdump -x app.wasm # view headers: import, export, section, type
wasm-decompile app.wasm -o app.dcmp # generate pseudo-C, much easier to read than WAT
wasm2c app.wasm -o app.c # to C, to recompile or analyze deeper
wasm2wat shows every instruction exactly, while wasm-decompile gives you pseudo-C close to the high-level logic. I read both, the decompiled version to get the idea, and WAT when I need precision.
If you want heavier tools, Ghidra has a WASM plugin (loads .wasm as its own architecture, using the familiar decompiler), and there are tools like wasmdec. For most web and CTF challenges, wabt is enough.
Reading a piece of WAT
Say a web challenge checks a key using WASM. After wasm2wat, you see something like:
(module
(func $check (param $p0 i32) (result i32) ;; takes a pointer to the string, returns 0/1
(local $i i32)
...
local.get $p0
i32.load8_u ;; read 1 byte from linear memory at address $p0
i32.const 42
i32.xor ;; byte XOR 42
i32.const 0x5b
i32.eq ;; compare with 0x5b
...
)
(export "check" (func $check)) ;; this is the entry point
(memory (export "memory") 1)
)
It reads like the Python or Java bytecode you already know. local.get $p0 pushes the parameter onto the stack. i32.load8_u takes the address on top of the stack, reads 1 byte from linear memory there, and pushes the value. i32.const 42 then i32.xor XORs the byte just read with 42. i32.const 0x5b then i32.eq compares it with 0x5b and pushes the 0/1 result.
In plain terms, for each character, char ^ 42 == 0x5b, so char == 0x5b ^ 42 == 0x71 == 'q'. Reading the WASM and working out the right character at the same time is what reversing looks like. An XOR pattern in a loop is almost always a check or string decode routine, same as in Lesson 1.1.
When the logic lives in linear memory
Strings and constants are often not in the instructions but in the data section, preloaded into linear memory. wasm-objdump -x lists the data segments with their offsets. When the code does an i32.load at a fixed offset, look that offset up in the data section to see what it’s reading. Beginners often miss this step and get stuck.
Key takeaways
WASM is stack-based bytecode, read much like Python/JVM bytecode. The first step is wasm2wat to get text, then wasm-decompile to get pseudo-C, and you can get the .wasm from the DevTools Network or Sources tab. Start from the exported functions, since that’s the entry point.
Strings and constants are in the data section of linear memory, so look them up with wasm-objdump -x. An XOR pattern in a loop is usually a check or string decode.
Lab
In this lab you take a WASM module, turn it into a readable form, find the function that checks the key, and work out the correct key. The source is check.wat, the WAT text of a small keygenme. Its exported function check(ptr, len) returns 1 if the key at ptr (of length len) is valid.
You need wabt (the WebAssembly Binary Toolkit). Download a release from the wabt page, or use apt install wabt or brew install wabt, and check it with wasm2wat --version. First compile the WAT into a binary so you have a .wasm file like the real thing.
1
wat2wasm check.wat -o check.wasm
Then work backwards as if you only had the binary.
1
2
3
wasm2wat check.wasm -o out.wat
wasm-objdump -x check.wasm # see exports, memory, data section
wasm-decompile check.wasm -o out.dcmp
Find the exported function (the name is check) and read its logic in out.wat or out.dcmp. Find the target constant array in the data section (use wasm-objdump -x), placed at offset 256. Work out the transformation applied to each key byte and then reverse it to compute the correct key, which is 8 characters long. For an extra step, write a few lines of Python that rebuild the key from the target array.
Two questions to think about. Why start reading from the exported function rather than the first function? And if the target array isn’t in an instruction but in the data section, where do you look it up? Try it yourself before opening the solution.
Show solution
The algorithm in check.wat can be checked with Python, where encoding forward from the correct key gives exactly the target array, and reversing the target array gives back exactly the key. The wabt commands below (wasm2wat and wat2wasm) are the standard workflow and work on any machine with wabt installed.
Step one is getting a binary to work with.
1
wat2wasm check.wat -o check.wasm
In practice you’d get check.wasm from the Network or Sources tab of DevTools rather than building it yourself. Here we build it to simulate that.
Step two is bringing it to a readable form.
1
2
3
wasm2wat check.wasm -o out.wat
wasm-objdump -x check.wasm
wasm-decompile check.wasm -o out.dcmp
wasm-objdump -x shows an exported function named check, an exported memory, and a data segment that loads 8 bytes at offset 256.
Step three is reading the logic. Inside check, the function requires len == 8 and otherwise returns 0 immediately. Then a loop runs with i from 0 to 7. In each iteration c = memory[ptr + i] (byte i of the key) and want = memory[256 + i] (the target byte), and if ((c + i) ^ 0x1F) != want it returns 0. If it gets through the whole loop it returns 1. So the condition for each character is this.
1
(key[i] + i) ^ 0x1F == TARGET[i]
Step four is the target array. The data section at offset 256 holds 8 bytes.
1
48 7d 6a 6f 7c 48 74 62
Step five is reversing it into the key.
1
key[i] = (TARGET[i] ^ 0x1F) - i
As a script:
1
2
3
target = [0x48,0x7d,0x6a,0x6f,0x7c,0x48,0x74,0x62]
key = ''.join(chr(((t ^ 0x1F) - i) & 0xFF) for i, t in enumerate(target))
print(key) # Wasm_Rev
The correct key is Wasm_Rev. As a cross-check (run in Python), encoding Wasm_Rev forward gives exactly the array 48 7d 6a 6f 7c 48 74 62, and reversing that array gives back Wasm_Rev.
On the questions, you start from the exported function because it’s the entry point JavaScript calls into, so it’s the surface of the real logic, while the other internal functions are usually utilities generated by the compiler. The constant array isn’t in an instruction but in the data section of the linear memory. Look it up with wasm-objdump -x (which lists the data segments with their offsets), then map the offset used by the i32.load instruction to that piece of data.
