Lesson 12.1: Objective-C and objc_msgSend
Open a macOS or iOS app written in Objective-C in IDA for the first time and it looks strange because there are almost no direct function calls. Instead there’s call objc_msgSend repeated thousands of times. If you don’t know what’s going on, you’d think the whole program calls a single function. This lesson explains the mechanism and why it actually helps the reverser.
Objective-C sends messages
In C or C++, calling a function is a call straight to its address. Objective-C works differently, because every method call is translated into a message sent through a single function called objc_msgSend.
A familiar line of Objective-C:
1
[account checkPassword:input];
is turned by the compiler into:
1
objc_msgSend(account, @selector(checkPassword:), input);
It means “send the object account a message named checkPassword:, with the parameter input”. Only at runtime does the Objective-C runtime look up whether the class of account has a method named checkPassword: and jump to it. This is dynamic dispatch, and it’s why you see objc_msgSend everywhere.
Reading objc_msgSend in assembly
Since everything goes through objc_msgSend, you need to read its first two parameters. Following the macOS/iOS calling convention (System V on x64, or AAPCS on ARM64), the parameters sit in the registers you already know from Lesson 1.3. The first parameter (rdi on x64, x0 on ARM64) is the receiver, the object receiving the message. The second (rsi on x64, x1 on ARM64) is the selector, the method name as a string. From the third onward (rdx/x2…) come the real parameters of the method.
A typical x64 snippet looks like this:
lea rsi, selRef_checkPassword_ ; rsi = selector "checkPassword:"
mov rdi, rbx ; rdi = receiver (the account object)
mov rdx, r14 ; rdx = input parameter
call objc_msgSend
Look at rsi (or x1) to know which method is being called. IDA and Ghidra usually annotate the selector next to the call themselves, so you read objc_msgSend(account, "checkPassword:", input) almost as readable as a line of the original code. When the tool doesn’t, you trace rsi back to the __objc_selrefs region yourself to get the name.
ARM64 is the same, just with different registers:
adrp x1, selRef_checkPassword_@PAGE
...
mov x0, x19 ; receiver
bl _objc_msgSend
The metadata keeps the names
Objective-C is much easier to reverse than C++ because the runtime needs class names, method names and parameter types to dispatch at runtime, so the compiler embeds all of that information into the Mach-O file. Going back to Lesson 1.8 on Mach-O, you’ll see dedicated sections. __objc_classlist holds the list of classes in the binary, __objc_methname the names of all methods (as selectors), __objc_classname the class names, and __objc_selrefs the selector references that the code uses.
So names like checkPassword:, AccountManager, validateLicense are still sitting in the binary, not mangled like C++ and not stripped like native C. You almost get a table of contents for the program.
class-dump: getting the whole interface back
Since the metadata is intact, there’s a tool that rebuilds the header files almost completely, class-dump (and class-dump-swift for Swift support). Run it on an ObjC Mach-O:
1
class-dump /path/to/MyApp.app/Contents/MacOS/MyApp
The result is full @interface declarations, covering every class, its list of methods, properties and instance variables. It’s like having the program’s .h files back. From there you know which classes matter (for example LicenseManager) and which methods are the targets (-isValidLicense:), and only then open IDA/Ghidra to read the bodies.
The practical workflow
First identify the file, because a Mach-O with __objc_* sections that imports objc_msgSend is an Objective-C app. Run class-dump to get the interface and read it to narrow down the classes and methods of interest. Then open IDA/Ghidra and jump to the target method (IDA names methods like -[AccountManager checkPassword:]).
Read the method body, and at each objc_msgSend look at the selector in rsi/x1 to see what it calls. Follow the chain of messages to understand the logic, and rename variables as you go, like the habit from Lesson 0.4.
A few pitfalls
objc_msgSend has relatives, objc_msgSendSuper (calls up to the superclass), objc_msgSend_stret (method returns a struct), and objc_msgSend_fpret (returns a float). When you meet a variant, you read the selector the same way. A selector is just a name, not an address, so two different classes can have the same init selector and you have to look at the receiver too to know which method actually runs.
An app can also call methods through dynamic strings (NSSelectorFromString), in which case the selector doesn’t show up statically and you have to watch it at runtime. Obfuscated code may rename selectors to nonsense, but in most ordinary commercial apps the names are still very clear.
Lab
The task is to practice extracting the interface with class-dump and reading method calls through objc_msgSend in Ghidra or IDA. You need a macOS machine (or any Objective-C Mach-O you are allowed to analyze, which can be a small system binary in /usr/bin or a simple ObjC app you build with clang), class-dump (or class-dump-swift) from the official source or through Homebrew, and Ghidra or IDA with a Mach-O loader. If you build your own sample on macOS, write a small class with a password-checking method as the target, in a file such as accountdemo.m, and build it with:
1
clang -framework Foundation -o accountdemo accountdemo.m
First confirm that the file is a Mach-O and is Objective-C, using file, then otool -l to find the sections __objc_classlist and __objc_methname, which ties back to Lesson 1.8. Run class-dump <binary> and read the output, listing the classes and methods and picking out which class looks related to the main logic (for example one with “verify”, “license” or “password” in a name). Then open the binary in Ghidra or IDA, find the import objc_msgSend, and see how many places call it. Choose a target method from the class-dump output and jump to its body. For each objc_msgSend, read the selector at rsi (x64) or x1 (ARM64) and rewrite the original line of code in the form [receiver selector:arg]. Follow the chain of messages to understand what the method does.
Two questions to think about. Why is reversing Objective-C usually easier than C++ even though both are native code? And if the app calls a method through NSSelectorFromString(someString), does the static reading above still work, and what would you have to do differently? Do it yourself before opening the solution.
Show solution
The procedure below describes the standard way of working on macOS, and the exact output will differ from binary to binary.
Task 1: confirming Objective-C
1
2
3
4
5
file accountdemo
# accountdemo: Mach-O 64-bit executable arm64 (or x86_64)
otool -l accountdemo | grep -A2 __objc
# you see the sections: __objc_classlist, __objc_methname, __objc_classname, __objc_selrefs
The __objc_* sections mean the binary contains Objective-C metadata. That is the data source for class-dump and for IDA and Ghidra’s automatic annotation.
Task 2: class-dump
1
class-dump accountdemo
Sample output (the shape of it):
1
2
3
4
5
6
7
@interface AccountManager : NSObject
{
NSString *_storedHash;
}
- (BOOL)checkPassword:(NSString *)arg1;
- (void)reset;
@end
The class AccountManager with a checkPassword: method returning BOOL is an obvious target. The method names and types are intact because ObjC metadata is not mangled.
Task 3: finding objc_msgSend
In Ghidra, go to Symbol Tree > Imports > _objc_msgSend, right-click > Show References. In IDA, jump to objc_msgSend and look at the xrefs. A medium-sized app has hundreds to thousands of calls, which is normal because every method call goes through here.
Task 4: reading selectors
IDA usually names functions like -[AccountManager checkPassword:] for you. Inside the body, a typical x64 excerpt:
lea rsi, selRef_length ; selector "length"
mov rdi, r14 ; receiver = the input string
call objc_msgSend ; = [input length]
mov r15, rax ; save the length
...
lea rsi, selRef_isEqualToString_ ; selector "isEqualToString:"
mov rdi, rbx ; receiver = _storedHash
mov rdx, r14 ; arg = input (processed)
call objc_msgSend ; = [_storedHash isEqualToString:input]
test al, al
Rewritten as the original code:
1
2
3
NSUInteger len = [input length];
...
if ([_storedHash isEqualToString:input]) { ... }
On ARM64 you read it the same way, with the selector in x1 and the receiver in x0.
Task 5: understanding the logic
The chain of messages shows that the method takes the length of the input, may hash or transform it, and then compares it against _storedHash with isEqualToString:. So this is a string comparison, and to find the correct value you would next trace where _storedHash is assigned (usually in init or a setup method).
Answers to the questions
It’s easier than C++ because the ObjC runtime forces the compiler to keep class names, method names and selectors in the binary for dispatch at run time. C++ mangles the names and resolves most things at compile time, so it has no need to keep them. As for dynamic selectors, no, because if the selector is built from a dynamic string through NSSelectorFromString, the name does not appear next to the static call. You have to run it dynamically (a debugger, or a Frida hook on objc_msgSend) to catch the actual selector at run time.
Key takeaways
Objective-C dispatches via objc_msgSend(receiver, selector, args), not a direct call. Read the selector at rsi (x64) or x1 (ARM64) to know which method is called, with the receiver in rdi/x0.
The ObjC metadata embedded in the Mach-O (__objc_classlist, __objc_methname…) keeps the class and method names, and class-dump extracts the whole @interface from it, like getting the header files back. The workflow is class-dump to narrow down, then read method bodies in IDA/Ghidra by selector.
