Lesson 12.2: Swift reverse engineering
The previous lesson on Objective-C was the easy one. In ObjC every method goes through objc_msgSend, and the metadata keeps the names so class-dump gives back almost the whole interface. Swift is harder. It’s designed to run fast, so the compiler calls functions directly or through witness tables instead of dynamic dispatch, function names are heavily mangled, and ARC adds retain/release instructions everywhere. This lesson covers how to deal with each of those.
Recognizing a Swift binary
First make sure it’s Swift. A few signs you can spot quickly are that symbols start with $s or _$s (Swift 4.2 onward, older versions use _T), there are __swift5_types, __swift5_proto, __swift5_fieldmd sections in the Mach-O (see them with otool -l or in IDA/Ghidra), it links to libswiftCore.dylib, and there are scattered calls to swift_retain, swift_release, swift_allocObject.
If you see these, it’s Swift, not plain C or ObjC.
Name mangling
Swift encodes function names with a dense scheme so it can fit the namespace, parameter types, generics, and protocol conformances into one ASCII string. A name like this looks meaningless:
1
$s4Demo10ValidatorC5check6inputSbSS_tF
Don’t try to read it by eye. There’s a demangle tool:
1
2
3
swift demangle '$s4Demo10ValidatorC5check6inputSbSS_tF'
# or on a machine with Xcode:
xcrun swift-demangle '$s4Demo10ValidatorC5check6inputSbSS_tF'
The result is readable:
1
Demo.Validator.check(input: Swift.String) -> Swift.Bool
This is the check method of the class Validator in module Demo, taking a String and returning a Bool. Newer IDA and Ghidra also demangle Swift symbols on their own in the function window, but when you meet a stray string in a log or in strings, swift demangle is the fastest.
A few rules for a quick guess are that a trailing C on a name means class, V is struct, F is function, S S is Swift.String, S b is Swift.Bool, S i is Int. No need to memorize them, just recognize them so you don’t panic.
Why Swift is harder than Objective-C
In ObjC, every method call goes through objc_msgSend(receiver, selector, ...). You read the selector and know what’s called. It’s uniform and easy to trace. In pure Swift, the compiler knows the exact type at compile time, so it calls the function address directly (static dispatch), or for protocol methods it calls through a witness table, a table of function pointers like a C++ vtable. There’s no objc_msgSend call to anchor on and no string selector to read. You rely on demangled symbols and witness tables.
The exception is anything marked @objc or inheriting from NSObject, which still goes through objc_msgSend, so many Swift apps mix the two worlds. When you see objc_msgSend, that part is as easy as ObjC.
ARC noise
Swift manages memory with ARC (Automatic Reference Counting). The compiler inserts swift_retain and swift_release around each use of an object to count references. So the pseudocode of a simple Swift function can be packed with retain/release calls mixed in with the real logic.
I treat swift_retain, swift_release, swift_bridgeObjectRetain, swift_bridgeObjectRelease as background noise. Skip them and focus on the other calls and the comparisons. Many beginners think these calls are important logic and get lost there.
Reading String in Swift
Swift’s String is not a null-terminated C string. It’s a struct with a counter and flags. Short strings can be stored directly in the struct (small string optimization like std::string), and long strings point out to memory. When comparing strings, Swift calls swift_stringCompare or similar, not strcmp. If you see one of the $sSS... functions related to String, a string is being handled.
When Swift talks to ObjC APIs, strings are bridged to NSString, and you see _bridgeToObjectiveC. That’s a useful clue, because the bridge point is often the boundary between the author’s Swift code and Apple’s frameworks.
Tools
Hopper has long been the strongest for Mach-O, with good Swift demangling and tidy pseudocode. IDA (newer versions) works with a Swift metadata plugin, and Ghidra with community Swift scripts that parse __swift5_types to rebuild types. Keep swift demangle / swift-demangle ready in the terminal, and use otool -l / -o to list sections and ObjC/Swift metadata.
Workflow
First recognize it’s Swift ($s symbols, __swift5_* sections, links libswiftCore). Open it in Hopper or IDA and let it demangle the symbols, and demangle stray symbols manually with swift demangle. When reading a function, skip retain/release and focus on comparisons and named calls. When you hit objc_msgSend read it like ObjC (lesson 12.1), and when you hit a witness table follow the table of function pointers.
Lab
The aim of this lab is to get used to Swift name mangling, to use swift demangle, and to spot retain/release calls and witness tables in a Swift Mach-O. Ideally you have a Mac with Xcode, which gives you swift demangle and lets you build your own sample. Without a Mac you can still do the demangling part by reading the rules, and the analysis part with Hopper, IDA or Ghidra on a downloaded Swift Mach-O.
Start by demangling by hand and then with the tool. For each of the symbols below, guess the meaning first and then check it with swift demangle (or xcrun swift-demangle).
1
2
3
$s4Demo10ValidatorC5check6inputSbSS_tF
$s4Demo4UserV4nameSSvg
$ss27_finalizeUninitializedArrayySayxGABnlF
Then recognize a Swift binary. Take a Swift Mach-O (a Swift command-line app you built yourself, or a downloaded binary) and run the commands below, confirming that you see __swift5_* sections and a link to libswiftCore.
1
2
3
otool -l binary | grep -A2 swift5
otool -L binary | grep swift
nm binary | grep '\$s' | head
Next, filter out the ARC noise. Open the binary in Hopper, IDA or Ghidra, pick one of the author’s functions and count the calls to swift_retain and swift_release. Practice reading the function by skipping them and looking only at comparisons and named calls. After that, find a witness table. Look for a function that calls a method through a protocol. You’ll see an instruction that loads a table of pointers followed by call [reg+offset], just like a C++ vtable. Write down the offset and guess which method it corresponds to. If the binary also has an @objc part, look for objc_msgSend and compare, deciding which part is easier to read and why.
If you have Xcode, you can create a sample yourself.
1
2
3
4
5
6
7
8
9
cat > demo.swift <<'EOF'
class Validator {
func check(input: String) -> Bool { return input == "SwiftRev" }
}
let v = Validator()
print(v.check(input: CommandLine.arguments.count > 1 ? CommandLine.arguments[1] : ""))
EOF
swiftc -O demo.swift -o demo
nm demo | grep '\$s'
Then open demo in Hopper and find Validator.check. Try it yourself before opening the solution.
Show solution
The demangling below is based on Swift’s official mangling scheme. If you have a Mac, run swift demangle yourself to check, and the results will match.
For the first symbol, $s4Demo10ValidatorC5check6inputSbSS_tF demangles to Demo.Validator.check(input: Swift.String) -> Swift.Bool. Reading it piece by piece, 4Demo is the module Demo, 10Validator plus C is the class Validator, 5check is the method check, 6input is the parameter label input, SS is the type Swift.String, Sb is the return type Swift.Bool, and F means function.
The second, $s4Demo4UserV4nameSSvg, demangles to Demo.User.name.getter : Swift.String. Here 4UserV is the struct User (V = struct), 4name is the property name, SS is the type String, and vg is the getter of the property.
The third, $ss27_finalizeUninitializedArrayySayxGABnlF, demangles to Swift._finalizeUninitializedArray<A>(_: __owned Swift.Array<A>) -> Swift.Array<A>. It’s an internal stdlib function (module s = Swift), generic (l), related to array initialization. You meet this kind a lot when reading code with array literals, and you can treat it as stdlib boilerplate.
For reading these, C = class, V = struct, O = enum, F = function, vg and vs = getter and setter, SS = String, Sb = Bool, Si = Int.
To recognize a Swift binary, otool -l shows the sections __swift5_types, __swift5_proto and __swift5_fieldmd. otool -L shows /usr/lib/swift/libswiftCore.dylib. nm shows a lot of $s... symbols. If you only see __objc_* and no __swift5_*, it’s pure ObjC and you should go back to Lesson 12.1.
For filtering ARC, a small decompiled Swift function often interleaves things like this.
1
2
3
4
swift_retain(x)
... a few instructions of logic ...
swift_release(x)
swift_bridgeObjectRelease(y)
Mentally grey out every swift_retain, swift_release and swift_bridgeObject* line. What remains is the logic. For the check function in the example, after removing ARC you’re left with one string comparison call and one branch returning a Bool.
For witness tables, when a method is called through a protocol (for example someProtocol.doWork()), the code loads the protocol witness table and then calls indirectly.
1
2
mov rax, [rbx+0x8] ; load the witness table pointer
call [rax+0x10] ; call the 3rd slot in the table
It’s like the C++ vtable in Lesson 4.2, with call [reg+offset] and the offset telling you the slot. Rebuild the table by looking at the function pointers the witness table points to (IDA and Ghidra have often already named them if they could read __swift5_proto).
Compared with ObjC, the @objc part goes through objc_msgSend(receiver, selector, ...), and by reading the selector (the second parameter, usually a pointer to a string in __objc_methname) you know which method is being called, as in Lesson 12.1. Pure Swift has no such reference point, so you rely on the demangled symbols and witness tables. With a hybrid app, work on the @objc part first, because it’s cheaper.
Swift adds a demangling step and ARC noise, but once demangled, the function names tell you almost everything. The best anchors are still the demangled symbols, the strings (including panic and assert messages), and the bridge boundary into ObjC.
Key takeaways
A Swift binary shows $s/_$s symbols, __swift5_* sections, and a link to libswiftCore.dylib. Always demangle with swift demangle or let IDA/Ghidra/Hopper do it. Pure Swift calls statically or through witness tables, with no objc_msgSend reference point like ObjC, so it’s harder. Anything marked @objc or inheriting NSObject still goes through objc_msgSend and that part is easy.
ARC adds retain/release everywhere, so treat it as noise and skip it. Swift String isn’t null-terminated, and comparison goes through its own functions, not strcmp.
