Lesson 15.3: Anti-debug group 3, timing and traps
The previous two groups (API and PEB) ask the operating system whether a debugger is attached. This group doesn’t ask anyone. It works it out from two things a debugger can’t hide. One is time, since stepping in a debugger makes the program run thousands of times slower. The other is exceptions, since a debugger has to sit between the program and the exception handling mechanism, and that leaves a trace.
This group matters because there’s no neat API call to put a breakpoint on, so ScyllaHide can’t always handle everything either.
Timing: a debugger stretches time
The idea is simple. A normal chunk of code finishes in a few hundred CPU cycles. If you single-step through it in a debugger, each instruction costs millions of cycles (the debugger stops, updates the UI, waits for you to press a key). The program measures the time at two points and compares. If the difference is abnormally large, someone is watching.
RDTSC
The rdtsc instruction (Read Time-Stamp Counter) returns the number of CPU cycles since boot, with the result in the edx:eax pair (edx is the high 32 bits, eax the low 32 bits). The classic pattern:
rdtsc ; read timestamp 1
mov rsi, rax ; save it (eax = low part)
; ... the code being measured, usually short ...
rdtsc ; read timestamp 2
sub rax, rsi ; rax = cycle difference
cmp rax, 10000h ; compare against a threshold
ja debugger_found ; difference too large, being stepped
It measures how many cycles the middle part took and raises the alarm if it goes over the threshold. Two rdtsc instructions a short distance apart followed by sub and cmp are almost certainly a timing check.
API variants
Not everyone uses rdtsc. The same idea works with APIs, such as QueryPerformanceCounter for a high-resolution counter, GetTickCount / GetTickCount64 which count milliseconds since boot, and timeGetTime or C’s time() for a coarser reading.
The pattern is the same. Call to get a timestamp, run a chunk, call again, subtract, compare to a threshold. With these APIs you do have a place to set a breakpoint.
Getting past timing checks
A timing check is just a cmp followed by a jump. The cleanest fix is to patch the jump. Find ja debugger_found (or jg, jb depending on the build), then invert the condition or nop it out. You don’t care about the time value, you just need the flow to not go into the alarm branch.
You can also fake the return value by editing rax after the second rdtsc or GetTickCount call so the difference becomes small. ScyllaHide has options that handle some timing checks (for example normalizing rdtsc, hooking GetTickCount), but it doesn’t cover every homemade variant, so patching by hand is still what works reliably.
A practical tip is not to step through the part between the two timestamps. Put a breakpoint after the second measurement and run straight to it (F9). The middle part runs at real speed and the difference doesn’t get inflated.
Traps: throw an exception and see who catches it
The second group uses the way Windows (and debuggers) handle exceptions. Normally if a program causes an exception, the operating system hands it to the program’s handler (SEH/VEH, see Lesson 1.12). But when a debugger is attached, the debugger sees the exception first. If the debugger swallows the exception instead of passing it back to the program, the program knows someone is interfering.
INT 3
The byte 0xCC is the int 3 instruction, which is the software breakpoint every debugger uses. The program places an int 3 itself, along with its own exception handler.
; install a SEH/VEH pointing to our own handler earlier
int 3 ; deliberately trigger a breakpoint
; if execution gets HERE, the handler was NOT called
; -> the debugger swallowed the int 3 -> being debugged
jmp debugger_found
handler:
; no debugger: our own handler caught it
; -> carry on normally
The logic is the opposite of what you’d expect. If the program’s handler runs, it’s not being debugged, because the program caught its own breakpoint. If execution runs straight through int 3 and the handler is never called, the debugger took the breakpoint, so it’s being debugged.
INT 2D and ICEBP (0xF1)
Two less known relatives that get used a lot because they mess with debuggers. int 2d is a kind of kernel breakpoint. Under a debugger it shifts the instruction pointer by one byte in an unpredictable way, and the way the debugger handles it differs from free running. icebp (opcode 0xF1, also called int 1) generates a single-step exception, and many debuggers handle it wrong and give themselves away.
Odd opcodes like 0xCD 0x2D or 0xF1 in the middle of normal-looking code are probably an anti-debug trap and not real code.
Hardware breakpoint detection via DR0-DR7
Hardware breakpoints live in the debug registers DR0 through DR3 (addresses) and DR7 (enable/disable). The program can read them itself. It calls GetThreadContext with the CONTEXT_DEBUG_REGISTERS flag, then checks whether DR0-DR3 are nonzero or any bit of DR7 is set. If so, someone has set a hardware breakpoint.
; CONTEXT.Dr0 .. Dr3 nonzero or Dr7 != 0
; -> hardware breakpoint present -> being analyzed
Single-step detection via the trap flag
The trap flag (TF) in the flags register makes the CPU raise an exception after every instruction when it’s set (this is the single-step mechanism itself). Some tricks set TF themselves and check whether the exception arrives as expected, or push the flags onto the stack (pushfd) and inspect the TF bit.
Getting past the trap group
For INT 3 / INT 2D / ICEBP, configure x64dbg to pass the exception back to the program instead of swallowing it. Go to Options > Exceptions and add the relevant exception codes to the ignore list, so the program’s handler receives them as it would when running freely. Or just patch the trap instruction to nop.
For hardware breakpoint detection, use software breakpoints instead of hardware ones, or have ScyllaHide/TitanHide hide the DR registers from GetThreadContext. The trap flag check usually also comes down to patching the branch that compares the result.
For all of group 3, don’t defeat each measurement one by one. Find the final point where every check ends up in one jump that decides whether it’s being debugged, and neutralize that jump. A lot of layered measurements usually end in one or two branches.
Lab
The goal is to see a timing check (RDTSC) and a trap check (INT 3) detect a debugger, and then get past both. The program is timing_check.c. It’s harmless and only prints a verdict on whether it sees a debugger. Use it for learning.
On Windows both checks run. Build with MinGW or MSVC.
1
2
gcc -O0 timing_check.c -o timing_check.exe
cl /Od timing_check.c
On Linux only the RDTSC part is built, because the INT 3 check uses SEH and is left out when the target isn’t Windows.
1
gcc -O0 timing_check.c -o timing_check
First run it freely (double-click or from a terminal). You should see a small RDTSC delta, a few hundred cycles, and the verdict that no debugger was found. Then open it in x64dbg, set a breakpoint at main, and single-step (F7 or F8) through the part between the two rdtsc instructions. Continue and watch the delta jump into the millions and the program report “debugger detected”.
Now get past it without stepping. Put a breakpoint right after the second rdtsc and press F9 to run straight to it. The measured section runs at full speed, the delta is small again, and the check doesn’t fire. You can also patch it. Find the conditional jump after the cmp of the timing check and invert or nop it. For the INT 3 check, go to Options > Exceptions in x64dbg and configure it to pass the exception breakpoint (0x80000003) on to the program, then watch the program’s __except handler catch it just as it did when running freely.
Some questions to think about. Why does running straight through with F9 not trigger the timing check while single-stepping does? In the INT 3 check, why does “my own handler ran” mean you’re not being debugged? And if you patch the jump, do you still need to care about the delta value? Try it yourself before opening the solution.
Show solution
I verified it on Linux, built with gcc -O0 timing_check.c -o timing_check. That covers only the RDTSC part, since the INT 3 part is Windows SEH and is dropped on other systems. Running it freely gives this.
1
2
[timing] delta = 374 cycles
=> Verdict: no debugger found, running normally
The delta of 374 cycles when running freely is far below the threshold of 100000. This is a real number from the build machine. On Windows under x64dbg, when you single-step through the measured section, the delta jumps into the millions and the check fires.
The free run is the baseline, which is a small delta of a few hundred cycles, and the verdict that there’s no debugger.
Single-stepping gives the check away. In x64dbg, if you press F7 or F8 one instruction at a time through the for loop between the two rdtsc instructions, every pause in the debugger costs a lot of real cycles, so t2 - t1 balloons. Then cmp rax, 100000 and ja branch into the “detected” path.
The way past it without touching the code is to run straight through. Put a breakpoint right after the second rdtsc (or right before the cmp), then press F9 from before the first rdtsc. The CPU runs the middle part at full speed with no debugger interrupting each instruction, so the delta stays small. It’s the simplest way past a timing check, so never single-step the part between two measurement points.
For the patch approach, look for this pair.
cmp rax, 100000h ; or some other threshold value
ja detected
There are two ways. Change ja into a jmp that goes over to the safe path, or nop the ja instruction (fill it with 0x90) so execution always falls through to the “no debugger” path. After the patch the delta value no longer matters, because the flow never branches into the alarm path.
For the INT 3 trap, the code uses __debugbreak() (which emits int 3) inside a __try block. With no debugger, nobody swallows the exception, so it falls into the program’s own __except, handled = 1, and the function returns 0 (not being debugged). With a debugger that swallows the int 3, the __except block doesn’t run, handled stays 0, and the function returns 1 (being debugged). To get past it, go to Options > Exceptions in x64dbg and add 0x80000003 (STATUS_BREAKPOINT) to the list so the debugger passes it on to the program instead of handling it itself. Then __except catches it as in a free run, and the check doesn’t fire. Another way is to nop the int 3 instruction and the checking branch.
On the questions. First, F9 lets the CPU run the measured section continuously at hardware speed, and the debugger doesn’t step in between instructions, so it adds no time. Single-stepping makes the debugger stop after every instruction, and each stop costs a lot of real cycles that add up and inflate the delta. Second, the program places the int 3 itself and installs its own handler for it. With no debugger, the program’s handler catches its own breakpoint. With a debugger, the debugger takes the int 3 first and (in the default configuration) swallows it, so the program’s handler doesn’t run, and that’s the sign of being debugged. Third, no, since once the jump is neutralized, the flow always takes the “no debugger” path whatever the delta is. That’s why patching the branch is the most durable approach against every group 3 anti-debug technique.
Key takeaways
Group 3 doesn’t ask the OS, it works things out from time and exceptions, so it’s harder to hook than the API group. Two rdtsc a short distance apart followed by sub + cmp + jump is a timing check, and GetTickCount/QueryPerformanceCounter give the equivalent. To get past timing, don’t step through the measured part (run straight to after timestamp 2), or patch the jump, or fake the value.
Traps work by the program placing its own int 3 / int 2d / icebp and seeing whether the debugger swallows the exception. The logic is usually inverted, so the handler running means not being debugged. To get past them, configure the debugger to pass the exception back to the program, or nop the trap instruction.
Hardware breakpoints get detected via DR0-DR7, so switch to software breakpoints or use ScyllaHide/TitanHide to hide the debug registers. In general, find the final deciding jump and neutralize it instead of defeating every single measurement.
