Lesson 15.9: Bypassing anti-debug

The previous four lessons (15.1 to 15.4) showed all kinds of anti-debug, including asking an API, reading the PEB, measuring time, setting traps, hiding in a TLS callback. If you had to patch each one by hand, a malware sample with twenty checks would eat your whole afternoon. Luckily most of that work is already packaged into plugins, and you just turn them on. When a plugin isn’t enough, there are a few manual techniques to fill in.

Almost every anti-debug check boils down to one question, “am I being watched”, answered by reading a flag, a value, or a system behavior. Bypassing it doesn’t mean deleting the question. You answer falsely, so every source of information says there’s no debugger. The tools below all do that lying, at different layers.

ScyllaHide: user-mode

ScyllaHide is a plugin for x64dbg (and IDA, OllyDbg too). It hooks the functions in ntdll inside the process you’re debugging, then adjusts return values and flags so every user-mode check misses. Turn it on once and it handles a whole batch of things you’ve already learned.

It forces IsDebuggerPresent and PEB.BeingDebugged to 0, and clears the flags in PEB.NtGlobalFlag and the heap flags that expose the debugger (lesson 15.2). For NtQueryInformationProcess with ProcessDebugPort/DebugFlags/DebugObjectHandle it returns the values of a clean process (lesson 15.1). It swallows NtSetInformationThread with ThreadHideFromDebugger so your thread doesn’t hide itself (lesson 15.4). It also covers NtQueryObject, NtClose (the CloseHandle check), OutputDebugString, and timing via NtQuerySystemTime/GetTickCount.

To use it in x64dbg, install the plugin in the plugins folder, open the ScyllaHide menu, pick a profile (I start with the default “x64dbg” profile, which already has most options on), apply, then run again. Most ordinary crackmes and malware stop yelling “debugger detected” right here.

Don’t blindly turn on every option. A few rarely change the program’s behavior, but others can. If you turn everything on and the app crashes, turn off the groups you’re unsure about, then turn them back on one group at a time until it both gets past the check and runs fine.

TitanHide: the kernel

ScyllaHide lives in user-mode, so it can only fix what goes through that process’s ntdll. Some checks look deeper, for example calling straight down into the kernel or checking debug state at the OS object level, which user-mode hooks don’t reach. For those you need TitanHide.

TitanHide is a kernel-mode driver. It intercepts system services (like NtQueryInformationProcess) inside the kernel, before the result gets back up to user-mode, so it gets past even the checks ScyllaHide can’t. Because it’s a driver, it needs admin rights and needs Driver Signature Enforcement turned off or handled (I usually run it in a test VM with test-signing on). The two tools complement each other. I turn on ScyllaHide first and only pull out TitanHide when I meet a stubborn check.

HyperHide: the hypervisor

When even the driver gets detected (some protectors check for the presence of TitanHide), HyperHide moves the lying down to the hypervisor level, using hardware virtualization so that neither the process nor the kernel sees the usual hook traces. You rarely need this, only against a hard commercial protector. Just know it exists for when ScyllaHide and TitanHide both lose.

There’s also SharpOD, another anti-anti-debug plugin that used to be popular for OllyDbg and x64dbg, with the same principle as ScyllaHide. Keep it as plan B.

Four levels

Don’t jump straight to the hypervisor for a crackme. A reasonable ladder:

Level	Tool	Use when
User-mode	ScyllaHide, SharpOD	Default, try first, gets past most
Kernel-mode	TitanHide	The check calls straight into the kernel or ScyllaHide doesn’t get past it
Hypervisor	HyperHide	The protector detects even the driver
Manual	x64dbg script, hardware BP	A weird check no tool covers, or you want to understand it properly

Manual techniques

Plugins cover the common checks. For a strange home-made check you handle it yourself, and these three tips are enough for most situations.

The first is a conditional breakpoint that fixes the value itself. Instead of stopping and fixing by hand each time, set a conditional breakpoint with a command in x64dbg. For example, to make IsDebuggerPresent always return 0, set a breakpoint right after the call and have it set rax = 0 and continue by itself, with no stop. In the Command box or the Breakpoints tab, x64dbg lets you attach an expression that runs on every hit, like:

bp IsDebuggerPresent
SetBreakpointCommand IsDebuggerPresent, "ret; mov rax,0"

(the exact syntax depends on the version, but the idea is that on a hit you fix the return value yourself and continue). This makes an annoying check disappear without patching the file.

The second is using hardware breakpoints instead of software breakpoints. A debugger’s software breakpoint works by overwriting the first byte of the instruction with 0xCC (INT 3). Anti-debug code can scan the code section for stray 0xCC bytes to detect that you set a breakpoint (lesson 15.3). A hardware breakpoint uses the CPU’s debug registers DR0 to DR3 and modifies no code bytes, so a 0xCC scan sees nothing. The downsides are that there are only 4 slots, and there’s a separate check that reads DR through GetThreadContext (ScyllaHide can fake this part too). When you suspect the binary scans for 0xCC, switch to hardware breakpoints.

The third is targeted patching. Once you’ve located the exact branch of the check (the cmp/je pair leading to the “detected” branch), sometimes the simplest thing is to NOP the jump or flip the condition right there, as lesson 17.1 covers in detail. Use it when you want a permanent patch instead of turning on a plugin every time.

My usual order is to turn on ScyllaHide first to clean up 90%, look at which checks still fire, then handle each with a conditional breakpoint or a patch. For learning you rarely have to climb to the kernel.

Lab

This lab has no source code of its own. It reuses the anti-debug programs you built in the earlier labs of this part, namely the one from Lesson 15.1 (anti-debug through APIs such as IsDebuggerPresent and NtQueryInformationProcess), the one from Lesson 15.2 (reading PEB.BeingDebugged and NtGlobalFlag directly) and the one from Lesson 15.3 (RDTSC timing and the trap). The goal is to use ScyllaHide to get past many checks at once instead of patching each one by hand, and then to deal with one leftover check yourself using a conditional breakpoint.

You need Windows, x64dbg, and the ScyllaHide plugin (copied into the x64dbg plugins folder), plus the anti-debug programs from those three labs.

Start by opening the Lesson 15.1 program in x64dbg and running it normally, without ScyllaHide. Confirm that it prints “debugger detected” (or exits early) and note which check fired. Then turn on ScyllaHide through Plugins > ScyllaHide, choose the default profile for x64dbg, tick the groups (IsDebuggerPresent, PEB, NtQueryInformationProcess, NtSetInformationThread) and apply. Run again and see that the program now behaves as it does with no debugger attached. Match each check from Lessons 15.1 and 15.2 to the corresponding ScyllaHide option.

Repeat with the Lesson 15.2 program (direct PEB access) and the Lesson 15.3 program (timing). Write down which ones ScyllaHide gets past immediately and which need extra options. Timing usually needs the time group turned on.

Next pick one check and deliberately turn off its ScyllaHide option, pretending the plugin doesn’t cover it. Get past it yourself with a conditional breakpoint. Put a breakpoint at the check function, attach a command that fixes the return value (for example forcing rax = 0 after IsDebuggerPresent), and let it continue by itself. Confirm that the program passes the check. Finally set a hardware breakpoint (right-click > Breakpoint > Hardware) instead of a software breakpoint at a function, and explain why this avoids a check that scans for the byte 0xCC.

Two questions to think about. Why is ScyllaHide (user-mode) not enough for every binary, and when should you think of TitanHide? And how does a self-fixing conditional breakpoint differ from patching the file directly, and which situation suits each?

Show solution

The procedure below describes the standard steps on x64dbg with ScyllaHide. The exact options differ a little between ScyllaHide versions.

To confirm detection, run the Lesson 15.1 program under x64dbg with nothing turned on. The program calls IsDebuggerPresent (and other checks), sees the debugger and prints the detection message. This is the “before” state to compare against.

After you apply the default profile, ScyllaHide hooks ntdll inside the process and forces values. IsDebuggerPresent reads PEB.BeingDebugged, and ScyllaHide keeps that byte at 0, so it returns 0. NtQueryInformationProcess(ProcessDebugPort) returns 0 instead of a non-zero value. NtQueryInformationProcess(ProcessDebugFlags) returns 1 (meaning “no debug”). NtSetInformationThread(ThreadHideFromDebugger) is swallowed, so the thread doesn’t hide itself. Run again and the program takes the “no debugger” branch. Every check from Lessons 15.1 and 15.2 has a corresponding option box in ScyllaHide.

For direct PEB access and timing, the Lesson 15.2 program reads gs:[0x60] straight to get the PEB and then checks BeingDebugged and NtGlobalFlag. ScyllaHide keeps these fields clean in the PEB memory itself, so a direct read still sees clean values and it gets through. The Lesson 15.3 program measures time with RDTSC, which often needs extra tuning, so turn on the option group related to time (ScyllaHide intervenes in the system’s time functions). RDTSC is a direct CPU instruction, and ScyllaHide can’t intercept a pure CPU instruction as easily as an API. So for timing based on bare RDTSC, the sure way is to patch the branch that compares the delta, or to run through the measured section without single-stepping (use run-to after the measured section rather than stepping instruction by instruction).

For the self-fixing conditional breakpoint, suppose you turn off ScyllaHide’s IsDebuggerPresent option to handle it yourself. In x64dbg, first run bp IsDebuggerPresent (or put the breakpoint right after the call, at the instruction that uses the result in rax or eax). Then attach a command that runs when the breakpoint hits, to force the result to 0 and continue. For example, put the breakpoint at the test eax, eax right after the call and give it the command eax=0 with the “do not pause” option. Every time the program asks whether there’s a debugger, it receives 0 and takes the clean branch, and you never have to click anything by hand.

A hardware breakpoint avoids the 0xCC scan because a software breakpoint overwrites the first byte of an instruction with 0xCC (INT 3). If the binary scans its own code section for stray 0xCC bytes, it can detect your breakpoint. A hardware breakpoint uses the CPU’s debug registers DR0 to DR3 and the hardware’s address matching, and doesn’t modify a single byte of code, so the 0xCC scan sees nothing unusual. The limits are that there are only 4 slots, and that some checks read the DR registers through GetThreadContext (ScyllaHide can fake that part).

As for when ScyllaHide is not enough and TitanHide is needed, ScyllaHide hooks in user mode, inside the ntdll of the process. A check that calls straight down into the kernel, or that checks the debug state at the level of an operating system object, isn’t touched by a user-mode hook, and then you need TitanHide, a kernel-mode driver that intercepts it inside the kernel.

As for conditional breakpoint versus patching the file, a conditional breakpoint lives only in the debug session and doesn’t touch the file on disk, which is flexible while probing and trying things quickly. A file patch is a permanent fix that runs independently outside the debugger, which suits the moment when you understand things well and want a reusable artifact. While analyzing, use the breakpoint, and when you’re done and need a runnable copy, patch.

Key takeaways

Bypassing anti-debug means making every source of information answer “no debugger”, not deleting the check. ScyllaHide (user-mode) is the first line, and its default profile gets past most checks from lessons 15.1 to 15.4. TitanHide (kernel driver) handles checks that look down into the kernel, and HyperHide (hypervisor) is for protectors that detect even the driver.

Hardware breakpoints (DR0-DR3) don’t write 0xCC into the code, so they dodge breakpoint-scanning checks. A conditional breakpoint that fixes the return value neutralizes a weird check without patching the file. Go from the lower layers up, with user-mode first, kernel next, hypervisor last.
