Lesson 15.7: Anti-attach, anti-dump and anti-hook
The previous three lessons covered anti-debug, meaning how a program knows it’s being debugged. This lesson covers tricks aimed at three specific things you often do, which are to attach a debugger to a running process, dump memory to a file, and hook APIs. Each one blocks a different tool, so you need to understand each separately to undo it.
Like every lesson in this part, this is from the analyst’s point of view, so understand the mechanism so you can recognize it and get past it in your own samples, not so you can put it into other people’s software.
Anti-attach
Normally there are two ways to get a debugger into a program, either to run it from the debugger from the start (spawn), or to let it run and attach later. Anti-attach targets the second way.
The most classic trick relies on a Windows limitation, that a process can have only one debugger at a time. If the program debugs itself (or spawns a child process and lets the child debug the parent), the debugger slot is already taken. Your real debugger gets refused with an error like “a debugger is already attached”. Self-debugging was covered in Lesson 15.4, here it serves the anti-attach purpose.
The second way is subtler. When Windows attaches a debugger, it calls DbgUiRemoteBreakin in ntdll to create a breakin thread in the target process. The program can patch this function (overwrite the start of it with a call to ExitProcess or a ret that breaks the logic), and then every time someone tries to attach, the process exits instead of stopping for you. Same with DbgBreakPoint.
The third way is simple but annoying, periodic checks. A background thread re-runs all the anti-debug checks from the previous three lessons (BeingDebugged, NtQueryInformationProcess…) every few seconds. You attach cleanly, and a few seconds later it detects you and exits.
The general way around anti-attach is to attach early, or not attach at all. If you can, run the program straight from the debugger (spawn) instead of attaching later, and then the debugger slot is yours before the anti-attach code runs. To disable the periodic check loop, find the thread doing it and patch the check function to return “no debugger”, or use ScyllaHide/TitanHide to hide the debugger entirely (see Lesson 15.9). If DbgUiRemoteBreakin was patched, restore it to its original in memory before attaching.
Anti-dump
When you unpack a sample by running to the OEP and dumping memory (the workflow in Lesson 14.3), a dump tool like Scylla reads the PE header in memory to know where the sections are and how big they are, and rebuilds the file. Anti-dump breaks that header.
A few tricks are common. After the loader has finished loading and no longer needs the header, the program can wipe the MZ and PE signatures by overwriting the two bytes 4D 5A (“MZ”) at the start and the 50 45 (“PE”) signature with zeros or junk, and a dump tool scanning memory no longer sees a valid PE to anchor on. It can also falsify SizeOfImage by changing that field in the Optional Header to a huge or too-small value, so the dump tool trusts it and dumps too little, or overflows into junk regions. Modifying the section count, virtual addresses and raw sizes smears the section table so rebuilding the file gets the layout wrong. Finally, the important code can be kept in dynamically allocated regions (VirtualAlloc) that don’t belong to the main image, so a normal image dump misses it.
Anti-dump isn’t hard to recognize. You dump a file, open it in PE-bear or CFF Explorer and it reports a broken header, or the dumped file doesn’t run even though you’re sure you reached the right OEP.
To get around it, you can rebuild the header by hand. You know the ImageBase (from the Memory Map in the debugger) and you know what the original PE header looks like, so copy back the two MZ bytes and the PE signature, and fix SizeOfImage to the correct value. Scylla has a rebuild option that helps with this. You can also dump earlier. If the header-wiping code runs after the OEP, put a breakpoint right at the OEP and dump before it gets a chance to break things. With some packers the original header is still somewhere in memory before being overwritten, or you can patch the branch that does the wiping (NOP it out) and only then let it continue. PE-sieve also often handles many broken-header cases on its own when dumping an unpacked module.
Anti-hook
When you hook an API with an inline hook (Detours, MinHook), or when Frida or an EDR attaches, the most common way is to overwrite the first few bytes of the function (the prologue) with a jmp instruction that jumps to your code. Anti-hook checks whether the starts of important functions are still intact.
The simplest mechanism is comparing the prologue to the expected value. The program knows which bytes NtProtectVirtualMemory or VirtualProtect normally start with, reads the first few bytes of the function at runtime, and if it sees a strange jmp (E9 ...) or push/ret it knows it’s hooked. A subtler way is comparing to a clean copy on disk, where it reads the ntdll.dll file from disk itself, maps a clean copy, and compares the prologue bytes one by one between the in-memory copy (possibly hooked) and the clean copy. A difference means a hook. Some samples also compare kernel32 calling down into ntdll to detect which layer the hook sits at.
This is how a lot of malware detects EDR, and also how a program detects Frida attached.
To get around it, hook more quietly. Instead of an inline hook overwriting the prologue, use a hardware breakpoint (registers DR0 to DR3) to catch the call without modifying a single byte of code. There’s nothing to compare, so prologue-check anti-hook doesn’t see it. You can also hook deeper than the checked layer. If it only checks the kernel32 prologue, hook at the ntdll layer, or the other way round. Another option is to find the function that compares prologues and patch it to always report “clean”. Restoring the prologue before the check and hooking again after is more complicated and rarely used.
This is why RE people like hardware breakpoints because they leave no trace in the code.
These three often come together
In a serious protector (Themida, VMProtect with full options) you’ll meet all three at once, on top of the anti-debug from the earlier lessons. A reasonable order is to get past the basic anti-debug first so it can run under the debugger (ScyllaHide), then spawn instead of attach to dodge anti-attach, then hook with hardware breakpoints to dodge anti-hook, and finally, at the OEP, dump early and rebuild the header to dodge anti-dump.
The overall strategy for multiple layers is covered in Lesson 15.10.
Lab
The goal is to see a program corrupt its own PE header in memory, then rebuild the header yourself so you can dump it, plus two observation exercises on anti-attach and anti-hook. The tools are x64dbg, Scylla (or PE-sieve), PE-bear and Process Hacker.
antidump.c is a small program that, once its startup is done, blanks the MZ and PE signatures of its own image in memory. It prints the ImageBase and then waits for Enter, which gives you time to work. Build it on Windows with:
1
2
3
cl antidump.c
rem or MinGW:
x86_64-w64-mingw32-gcc antidump.c -o antidump.exe
First, observe the anti-dump. Run antidump.exe and note the ImageBase it prints. Open Process Hacker, find the process and look at the memory region at ImageBase. Before the program prints “Wiped the PE header in memory”, the first two bytes are 4D 5A (“MZ”), and afterwards they become 00 00. Try dumping the image with Scylla or PE-sieve and notice that the tool does not recognize a valid PE or produces a broken file.
Second, rebuild the header. In x64dbg, attach to the process while it waits for Enter and go to the ImageBase region. Restore the first two bytes to 4D 5A, and at the e_lfanew offset (read the dword at ImageBase+0x3C) restore 50 45 (“PE”). Dump again with Scylla. This time the header is valid and the dump can be rebuilt. If you run out of time, increase the wait in the source or set a breakpoint right before wipe_pe_header.
Third, think about anti-attach. Suppose the program also had a background thread that every 3 seconds checks IsDebuggerPresent and calls ExitProcess when it sees a debugger. What happens when you attach in the second exercise, and how could you avoid it? A hint is to spawn instead of attach, or use ScyllaHide.
Fourth, think about anti-hook. Suppose a program reads the first 5 bytes of VirtualProtect in memory and compares them with the first 5 bytes of the same function read from C:\Windows\System32\kernel32.dll on disk. If you inline-hook VirtualProtect with Detours, it detects that immediately. Which kind of hook is not caught by this prologue comparison?
Show solution
The x64dbg and Scylla workflow below is the standard procedure and needs a Windows machine. The C logic of antidump.c follows the PE layout (e_lfanew at offset 0x3C, the MZ and PE signatures), so build and run it on Windows to confirm.
For the anti-dump observation, after the run you see this at ImageBase:
1
2
3
4
5
6
Before: 4D 5A 90 00 ... ("MZ")
...at ImageBase+e_lfanew: 50 45 00 00 ("PE\0\0")
After wipe_pe_header() is called:
00 00 90 00 ... (MZ wiped)
...at the NT headers: 00 00 00 00 (PE wiped)
When Scylla or PE-sieve scans the image at ImageBase, it doesn’t match the PE pattern and reports that no header was found, or dumps a file that PE-bear reports as corrupt.
To rebuild the header in x64dbg, press Ctrl+G to go to ImageBase (the value the program prints, or look in the Memory Map for the main module). In the Dump window, restore the first 2 bytes to 4D 5A. Read the dword at ImageBase+0x3C to get e_lfanew, go to ImageBase + e_lfanew and restore the 4 bytes 50 45 00 00. Then open Scylla, choose the process, run IAT Autosearch if needed, and Dump. This time the header is valid. With a real sample you would also check SizeOfImage in the Optional Header (offset e_lfanew + 0x18 + 0x38 for PE32+) in case it was changed to a nonsensical value, and set it back to the total size of the sections. Scylla’s “Fix Dump” button does most of this work.
For anti-attach, if a thread checks periodically and then calls ExitProcess, attaching in the second exercise makes the process quit by itself after a few seconds and you lose your session. There are three ways around it. You can spawn instead of attach, opening antidump.exe directly in x64dbg from the start. A breakpoint at the entry point gives you control before the anti-attach code runs, and you can patch the check loop too. ScyllaHide hides IsDebuggerPresent and the common checks so the loop no longer sees the debugger. Or you can find that thread (the Threads view in x64dbg), set a breakpoint at the check function and patch it to always return “no debugger”, or suspend the thread.
For anti-hook, comparing the 5 prologue bytes with the clean copy on disk catches inline hooks (Detours, MinHook, Frida inline) because they overwrite the function start with jmp or push+ret. The kind of hook this doesn’t catch is the hardware breakpoint (DR0 to DR3). The CPU stops when execution reaches the address, but not a single byte of code is modified, so the prologue comparison still sees it clean. A hook placed at a different layer than the one being checked also slips through (for example a hook in ntdll when only kernel32 is checked), although it’s still inline and therefore risky if the program checks both layers. So when you meet anti-hook, a hardware breakpoint is the safest choice.
To sum up. Anti-dump doesn’t stop you from reading memory, it only corrupts the metadata so automatic tools give up, and if you understand the PE layout you can rebuild it. Anti-attach loses to spawning. Prologue-check anti-hook loses to the hardware breakpoint.
Key takeaways
Anti-attach blocks attaching after the program runs, by occupying the debug slot itself, patching DbgUiRemoteBreakin, or checking periodically, and you get around it by spawning instead of attaching. Anti-dump breaks the PE header in memory (wiping MZ/PE, wrong SizeOfImage) so the dump becomes garbage, and you get around it by dumping early and rebuilding the header (Scylla/PE-sieve).
Anti-hook compares API prologues against the clean copy on disk to detect inline hooks, EDR, or Frida. Hardware breakpoints work well here, since they modify no bytes and leave no trace in the code. Strong protectors combine all three layers, so handle them in the order anti-debug, anti-attach, anti-hook, anti-dump.
