Lesson 4.4: Exceptions, templates and lambdas

By now you can read classes, vtables, and so on. But real C++ code has three more things that make beginners panic in the decompiler, namely a try/catch block that turns into a mess of tables, a small function that shows up in five or six near-identical copies, and a simple lambda that turns into a whole hidden class. Once you know the mechanism behind them, they’re just noise you know how to skip.

Templates: one source function, many binary functions

This is the easiest one, so I’ll start there. When you write a template:

template <typename T>
T add_one(T x) { return x + (T)1; }

there’s only one function in the source. But the compiler doesn’t generate one shared function for all types. Each time you call it with a new type, it generates a separate function, called an instantiation. Calling add_one<int> and add_one<double> produces two completely different machine functions.

You can see it in the symbol list of the lab program:

int    add_one<int>(int)       -> _Z7add_oneIiET_S0_
double add_one<double>(double) -> _Z7add_oneIdET_S0_

And the asm of the int version (gcc -O0, name demangled):

_Z7add_oneIiET_S0_:        ; add_one<int>
    mov   [rbp-0x4], edi    ; x (parameter, int)
    mov   eax, [rbp-0x4]
    add   eax, 0x1          ; return x + 1
    ret

The double version uses SSE registers (xmm) and the addsd instruction instead of add, since it works on floating point. Same source logic, two different function bodies.

A few consequences when reversing. The binary gets bigger, because a template used with ten types is ten functions, and template-heavy libraries (STL, Boost) push the function count into the thousands. You’ll also see many nearly identical functions, differing only in data size or instruction type. Don’t assume the author copy-pasted, it’s template instantiation. Understanding one version means understanding the whole family. Read add_one<int>, glance at the others to confirm the same logic, and name them consistently like add_one_int, add_one_double so you don’t mix them up.

Lambdas: a hidden class

A lambda looks like a tiny anonymous function, but the compiler turns it into an object. This lambda:

int base = n * 10;
auto make = [base](int k) { return base + k; };
make(7);

gets translated by the compiler into roughly:

struct __lambda {
    int base;                 // capture by value -> field
    int operator()(int k) const { return base + k; }
};
__lambda make{ n * 10 };
make(7);                      // actually calls make.operator()(7)

Each captured variable becomes a field of a hidden struct, and the lambda body becomes the operator() method of that struct. Calling the lambda is calling a method, so it has a this pointer just like lesson 4.1 described.

Here’s the real asm of the operator() of the lambda above (gcc -O0):

main::{lambda(int)#1}::operator()(int) const:
    mov   [rbp-0x8], rdi     ; rdi = this (the lambda object holding the capture)
    mov   [rbp-0xc], esi     ; esi = k (the real parameter)
    mov   rax, [rbp-0x8]     ; rax = this
    mov   edx, [rax]         ; edx = this->base  (the capture is at offset 0)
    mov   eax, [rbp-0xc]     ; eax = k
    add   eax, edx           ; return base + k
    ret

Two things match the model above. The first parameter rdi is this (SysV, on Windows it would be rcx), and [rax] reads the base field right at the start of the object. The capture is now data in the object, not a local variable.

To recognize a lambda when reversing, look for a small struct being built on the spot (the movs writing the capture into an object on the stack), then a method call with that object as this. Its mangled name contains a string like ZZ...EUl... (U for unnamed lambda). IDA/Ghidra usually show a long ugly name, so rename it to lambda_xxx.

Exceptions: the price of try/catch

This is the part that tangles things the most. In the source, try/catch is tidy. In the binary it splits into two parts, the normal running path (happy path) and the machinery that handles an exception, sitting separately, linked through data tables.

The two main ABIs differ quite a bit. On Linux with the Itanium C++ ABI, a throw makes the runtime call __cxa_throw, and then it walks back up the stack (stack unwinding) to find a handler. The information about which handlers this frame has and what needs cleaning up isn’t in the code but in dedicated sections, such as .eh_frame, .gcc_except_table. The place in code that catches the exception is called a landing pad. In the decompiler you see a function that seems to end at ret but still has stray code blocks after it that nobody calls directly. Those are landing pads, which the runtime jumps into during unwinding.

On Windows with MSVC, a different mechanism is used, with funclets (sub-functions for catch blocks) and unwind data in .pdata/.xdata. You’ll see pointers to FuncInfo tables and __CxxFrameHandler, and a related function is _CxxThrowException.

What both have in common, for the reverser, is that try/catch code is cut apart. The try body runs straight, and the catch part sits in a separate block that the main flow doesn’t reach with a normal jmp, so don’t panic when you see orphan code after a function, it’s usually a handler. Also don’t get lost in the unwind tables unless you really need to. In most cases when reversing a crackme or finding the main logic, you only need to know “this spot can throw, that one catches” and move on. The EH tables rarely hide secrets. A __cxa_throw / _CxxThrowException call means there’s an exception exit from here, and __cxa_begin_catch / __CxxFrameHandler means you’re in the handling area.

Putting it together

All three are the compiler generating extra code around the author’s real logic. The strategy is the same, which is to recognize them, label them, then focus on the logic. A template is many copies of one function (understand one, infer the family). A lambda is a hidden class (find operator() and the capture fields). An exception is code cut apart (the happy path is the main thing, the handler comes later). With these three in mind you can read modern C++ without being put off by the number of functions and the odd blocks.

Lab

LAB 4.4Download the source files for this lab

Download all (.zip) src/modern.cpp

The file modern.cpp shows what three pieces of modern C++ turn into at the binary level, so you aren’t thrown off when you meet them in a decompiler later. The task is to build it, then find the two instantiations add_one<int> and add_one<double> in the symbols and compare their asm, find the lambda’s operator() and identify which is this and which is the capture field, and mark out the try/catch block by finding the throw call and the handler that sits apart from it.

On Linux:

g++ -O0 -g -fno-inline -o modern modern.cpp

With MinGW on Windows:

g++ -O0 -g -fno-inline -o modern.exe modern.cpp

With MSVC in a Developer Command Prompt:

cl /EHsc /Zi modern.cpp

-fno-inline keeps the functions separate so they are easy to read, and /EHsc turns on exceptions for MSVC. A test run should print this:

add_one int=2 double=2.5
lambda=17
div=100
caught: divide by zero

Start with the template. List the symbols and look for the two copies of add_one with nm -C modern | grep add_one. How many functions are there, and why does one template in the source produce several machine functions? Then compare the asm of add_one<int> and add_one<double> with objdump -d -M intel -C modern | less. Which instruction does the int version use to add, and which registers and instructions does the double version use instead? Next the lambda. Find its operator() (the name contains {lambda(int)#1}, or the mangled form _ZZ4mainENKUliE_clEi). In its asm, work out what the first parameter (rdi on Linux) is, and what the line mov edx, [rax] is reading, relating it to the captured variable base. In main, find where the lambda object is built. The instructions that write the captured value into an area of the stack before the call are the hidden constructor of the closure.

For the exceptions, find the throw call in main or safe_div. On Linux look for __cxa_throw and __cxa_allocate_exception, and with MSVC look for _CxxThrowException. Work out where the catch block sits. On Linux, watch for blocks of code after the function’s ret that the main flow never jumps to, which are landing pads. With MSVC you can also open the binary in PE-bear and find the .pdata and .xdata sections, which hold the unwind data for exceptions.

Two questions to think about. If a program uses both std::vector<int> and std::vector<std::string>, how many sets of vector functions do you expect in the binary? And why would capture by value and capture by reference give different field layouts in the closure? Do it yourself before opening the solution.

Show solution

All the asm below is real output from g++ -O0 -g -fno-inline on Linux x86-64, demangled and annotated. MSVC differs in the details but the ideas are the same.

Template

$ nm -C modern | grep add_one
000000000000148d W double add_one<double>(double)
000000000000147a W int add_one<int>(int)

There are two functions even though the source has a single template. The compiler generates a separate instantiation for each type that is called (int and double). The W means a weak symbol, so the linker can merge duplicate copies from several files.

add_one<int>:

_Z7add_oneIiET_S0_:
    mov   [rbp-0x4], edi    ; x
    mov   eax, [rbp-0x4]
    add   eax, 0x1          ; integer addition with 'add'
    ret

add_one<double> uses SSE registers and floating-point instructions:

_Z7add_oneIdET_S0_:
    movsd [rbp-0x8], xmm0   ; x (double) passed in xmm0
    movsd xmm1, [rbp-0x8]
    movsd xmm0, [constant 1.0]
    addsd xmm0, xmm1        ; floating-point addition with 'addsd'
    ret

The difference is the data type, since int goes through general-purpose registers and add, while double goes through xmm and addsd. The logic x + 1 is the same, but there are two function bodies.

Lambda

The lambda’s operator():

main::{lambda(int)#1}::operator()(int) const:   ; _ZZ4mainENKUliE_clEi
    mov   [rbp-0x8], rdi    ; rdi = this (the closure object)
    mov   [rbp-0xc], esi    ; esi = k (the real parameter)
    mov   rax, [rbp-0x8]    ; rax = this
    mov   edx, [rax]        ; edx = this->base  (capture at offset 0)
    mov   eax, [rbp-0xc]    ; eax = k
    add   eax, edx          ; return base + k
    ret

The first parameter rdi is this, like in every C++ method (Lesson 4.1). A lambda is callable because it’s really the operator() method of a hidden struct. The line mov edx, [rax] reads the first field of the object, which is the variable base captured by value. The capture isn’t a local variable anymore but data inside an object. In main, before the call, there are instructions that build the object, and they compute base = n*10 and mov it into the closure object’s stack area. That’s the closure’s hidden constructor.

Exceptions

When b == 0, safe_div calls this chain:

safe_div:
    ...
    cmp   [rbp-0x8], 0          ; b == 0 ?
    jne   .divide
    mov   edi, 0x10
    call  __cxa_allocate_exception   ; allocate the exception object
    ...
    call  __cxa_throw                ; throw
.divide:
    mov   eax, [rbp-0x4]
    cdq
    idiv  dword [rbp-0x8]            ; a / b
    ret

__cxa_throw is the point where the exception is thrown. In main the try block runs straight through, while the catch block is compiled into a landing pad, which is a separate stretch of code that begins with __cxa_begin_catch, calls e.what() and then printf, and ends with __cxa_end_catch. The main flow never jmps there, and the runtime jumps in while unwinding the stack. The navigation data for unwinding lives in .eh_frame and .gcc_except_table, not in the code. You can look at it with:

readelf -S modern | grep -E 'eh_frame|except'

On MSVC, opening PE-bear shows .pdata (RUNTIME_FUNCTION) and .xdata (unwind info), along with the _CxxThrowException call and the __CxxFrameHandler handler.

Answers to the questions

std::vector<int> and std::vector<std::string> are two different instantiations, so the binary has two separate sets of vector functions (push_back, allocate, destructor and so on). This is the main reason C++ binaries that use a lot of the STL get so large. Capture by value stores a copy of the variable as a field, like base above. Capture by reference stores a pointer to the original variable as the field, so the field is an address (8 bytes) rather than a value, and operator() has to dereference once more.

Key takeaways

With templates, each type is a separate function in the binary, so many near-identical functions are usually instantiations and not copy-paste. Lambdas become a hidden struct where captures become fields and the body becomes operator() with a this pointer. With exceptions, try/catch is split into the happy path and separate handlers, linked through unwind tables (.eh_frame/.gcc_except_table on Linux, .pdata/.xdata on Windows). The throw tells are __cxa_throw (Linux) and _CxxThrowException (MSVC). Don’t get lost in the EH tables, since most of the time you only need to know “it may throw here, it’s caught there”.
