Lesson 9.2: Rust's String, Vec, iterators and trait objects
Last lesson you learned how to recognize a Rust binary and demangle its function names. Now the harder part, reading the code inside. Rust follows “zero-cost abstraction”, which means the nice things you write in source, iterators, closures, Option, get flattened by the compiler into plain loops and branches with no trace of their original shape. The code runs fast, but the disassembly is hard to read.
This lesson covers a few of Rust’s core data structures, so you can still tell what you’re looking at in a lot of inlined code.
String and str: pointer plus length, not null-terminated
This is the first thing that trips up people used to C. In C a string ends with a 0 byte, so you read until you hit 0. Rust doesn’t do that. A String or &str is a pointer to the data plus a length field, like Go (see Lesson 8.3).
In the data section this means strings are glued together into one long block with no separators. For example you might see "errorinvalid inputpassword" in one run. That’s three strings, "error", "invalid input" and "password", joined together. The boundaries are in the code. Each time a string is used, the compiler loads both the pointer (pointing into the middle of the block) and a length constant. To find where a string stops, look for the length, usually a constant mov right next to the instruction that loads the pointer.
A full String has three fields, namely pointer, length and capacity (the allocated space), 24 bytes on a 64-bit system. A &str is just pointer plus length, 16 bytes, because it only borrows the data.
; load a &str: lea the pointer, then load the length as a constant
lea rax, [rip+0x...] ; pointer to "password" in the string block
mov esi, 8 ; length = 8, this is what tells you how long the string is
A pointer into the string block followed right away by a small constant is almost certainly a &str, and the constant is its length.
Vec
Vec<T> is also three fields, pointer, length and capacity, exactly like the data part of String (String is internally a Vec<u8>). The only difference is the elements aren’t necessarily bytes. Accessing v[i] becomes [ptr + i * sizeof(T)], the same array formula as in Lesson 3.2.
A three-field struct where the second and third fields look like length and capacity (two integers, the latter greater than or equal to the former) is a Vec or String.
Iterators
Here Rust differs from the languages before it. You write nice source like:
1
let sum: u32 = data.iter().map(|x| x * 2).filter(|x| x > &10).sum();
You’d expect the binary to have separate functions for map, filter and sum. It doesn’t. The compiler inlines the whole iterator chain into one flat loop, where each element is doubled, compared to 10 and accumulated in the same loop body. The map/filter/sum structure is gone.
So don’t look for a map or filter function, they don’t exist as separate functions. Read the loop body and work out the steps yourself. Each iteration it doubles (the map), then a branch skips if less than 10 (the filter), then it adds into an accumulator (the sum). The decompiler (Ghidra, Hex-Rays) usually gives a big for loop with many nested ifs, and you translate that back to the original iterator idea.
With Rust you reverse at the level of what the loop does, not which function is called, because there are almost no function calls left.
Option and Result
Rust has no null. It uses Option<T> (Some or None) and Result<T, E> (Ok or Err). In the binary these usually become a small tag (an integer saying which variant it is) plus the data. For types that can be optimized (like Option<&T>), the compiler uses the value 0/null itself as None, so an Option is often just a check whether the pointer equals 0. A panic call after a check branch is usually where unwrap() hit a None or Err.
Trait objects: vtable in a fat pointer
If you read Lesson 4.2 on C++ vtables, Rust’s trait objects are similar with one difference. C++ puts the vtable pointer at the start of the object. Rust keeps it separate. A trait object (&dyn Trait, Box<dyn Trait>) is a fat pointer, two pointers traveling together, one to the data and one to the vtable.
A method call through a trait looks like:
; rax = data pointer, rdx = vtable pointer (travel as a pair)
mov rcx, rax ; pass data as self
call [rdx+0x18] ; call the method at the slot in the vtable
Two pointers always together, with one used for call [reg+offset], is a trait object dispatching dynamically.
Identifying crates through strings and symbols
Even when heavily inlined, a Rust binary still leaks plenty about the libraries (crates) it uses. Path strings in panic messages often show crate names and even source file paths, for example src/main.rs or .cargo/registry/.../serde-1.0.x/src/..., which tells you which crates the code uses. Symbols (if not stripped) contain the crate name in the mangled part, for example _ZN4core, _ZN5alloc, _ZN5serde. Common crates to watch for are std/core/alloc (always present), serde (serialization), tokio (async), reqwest/hyper (HTTP) and clap (argument parsing).
Knowing the crates helps you guess what the program does before you read the code in detail.
When the decompiler gives a mess
This is how I deal with real Rust binaries. Demangle and recover symbols first (Lesson 9.1), so you have function names to hold on to. Read the panic strings to learn the crates and source paths and infer the project structure. For each function, don’t try to map every line back to the source. Work out what it takes, what it returns and how it transforms things, at the loop level. Accept that iterator chains are flat and read the loop by behavior. If you need a concrete value at runtime (for example a decrypted string), switch to dynamic like usual.
Lab
In this lab you see how Rust represents familiar structures in a binary, and why iterator chains disappear. You build a small Rust program that uses String, Vec, an iterator chain and a trait object, then look at it in Ghidra or IDA to see the glued-together strings, the three-field structure of Vec, and the iterator inlined into a flat loop. Install Rust through rustup (https://rustup.rs) and check it with rustc --version. The program is main.rs. Build an optimized copy and a plain copy, and compare them to see the effect of optimization.
1
2
rustc -O main.rs -o rust_demo # optimized build
rustc main.rs -o rust_demo_debug # plain build, easier to read
Open rust_demo in Ghidra and run auto-analysis. In Defined Strings, look for "ReverseEngineer", "Xin chao" and "Hello", and check whether they’re stuck to other strings and whether there’s a terminating 0 byte. Find where "ReverseEngineer" is used and locate the length constant 15 loaded nearby. Then find the function sum_even_doubled. In the -O build, confirm that filter, map and sum aren’t three separate functions but one flat loop, and point out which part of the loop does the even filtering, which does the doubling and which does the accumulation.
Next find the place where greet() is called through the trait object. Identify the data and vtable pointer pair and the call [reg+offset] instruction. Compare rust_demo with rust_demo_debug and decide in which one the iterators are easier to recognize. If there’s a panic path string, find it to see the source path leaking.
Two questions to think about. Why can’t you find a single string ending in a 0 byte for the literals above? And if a large program used the serde crate, where would you look for its traces? Try it yourself before opening the solution.
Show solution
The figures below follow the standard behavior of the Rust compiler (rustc and LLVM). When you build it yourself, the addresses will differ but the patterns are as described.
In Defined Strings, the three literals "ReverseEngineer", "Xin chao" and "Hello" (along with format strings such as "Name: " and ", length: ") live in a read-only section (.rodata on ELF, .rdata on PE). They’re usually glued together into one block with no 0 byte separating them, because Rust stores a string as a pointer plus a length and needs no terminator.
The boundary of "ReverseEngineer" (15 characters) is set in the code, not in the data. Where the String is created you will see this.
lea rax, [rip + OFFSET_to_string] ; pointer
mov edx, 15 ; length, which is the string length
The constant 15 is the clue. Without it you wouldn’t know where the string stops.
In the -O build, sum_even_doubled doesn’t contain calls to filter, map or sum. Everything is a single loop, roughly like this.
1
2
3
4
5
6
7
acc = 0
for i in 0..len:
x = data[i] ; iter()
if (x & 1) != 0: ; filter: skip odd numbers
continue
acc += x * 2 ; map (double) and sum (accumulate) merged
return acc
The three original iterator layers become three operations in the same loop body, namely the parity check (filter), the doubling (map) and the addition to acc (sum). That’s zero-cost abstraction, which is a nice abstraction in the source, zero cost in the binary, and no trace left for the reverser either. For the array [1..8] the even numbers 2, 4, 6, 8 double to 4, 8, 12, 16 and the sum is 40.
Trait objects are fat pointers. Vec<Box<dyn Greeter>> holds fat pointers, each element being two pointers, one to the object data and one to the vtable of the matching impl (Vietnamese or English). The call g.greet() becomes this.
mov rdi, [data_ptr] ; self
call [vtable_ptr + OFFSET] ; dynamic dispatch through the greet slot in the vtable
The difference from C++ is that the vtable pointer isn’t inside the object but travels next to the data pointer as a pair.
The rust_demo_debug build (no -O) keeps more iterator functions as separate calls and inlines less, so the shape of map and filter is easier to spot. The -O build is much faster but flat and harder to read. When you have both, read the debug build to understand the logic and then compare with the optimized one.
If the program has a panic branch (for example an out-of-bounds array access), you’ll see a string like src/main.rs with a line number. For external crates, the path even shows the crate name and version under .cargo/registry/....
On the questions, there’s no string ending in 0 because Rust uses an explicit length rather than a null terminator like C. And traces of serde live in the mangled symbols (_ZN5serde... if the binary isn’t stripped) and in panic or registry paths if present.
Key takeaways
String/str and Vec are pointer plus length (Vec/String add capacity) and not null-terminated. Strings are glued together, and the boundaries are in the length constants in the code. An iterator chain (map/filter/sum) is inlined into a flat loop with no separate functions, so read by behavior and don’t look for function names.
Option/Result become a tag plus data, None is often just null, and a panic after a branch is usually an unwrap. A trait object is a fat pointer, a data pointer and vtable pointer pair, dispatching through call [vtable+offset]. Panic strings expose crate names and source paths, which helps you guess what the program does.
