Lesson 7.2: pycdc and pycdas
In the last lesson you learned what a .pyc file is and how to read its magic number. Now we open it up. The main toolset is Decompyle++ (the repo is called pycdc), made of two programs, where pycdc tries to rebuild the Python source, and pycdas dumps the bytecode in a readable form.
It’s written in C++ and doesn’t depend on a Python runtime. Other decompilers like uncompyle6 run on Python itself and can usually only decompile a .pyc from the same version line as the interpreter running them. pycdc reads the file structure directly, so on a machine with only Python 3.11 you can still try a .pyc from 2.7 or 3.6. The downside is that it has to implement its own knowledge of each bytecode version, so the newest versions (3.12, 3.13) aren’t fully supported. Below are real run results showing both sides.
Build in five minutes
pycdc uses CMake. On Linux/WSL:
1
2
3
cd pycdc-master/pycdc-master
cmake . -DCMAKE_BUILD_TYPE=Release
make -j4
When it’s done you have two executables, pycdc and pycdas, right in the folder. A prebuilt version may exist for your platform, but if it complains about a missing GLIBC/GLIBCXX (built on another machine with an older glibc), rebuild as above and that goes away. On Windows use Visual Studio or MinGW, with a similar CMake process.
pycdc: rebuild the source
The simplest syntax:
1
./pycdc path_to_file.pyc
It prints the rebuilt source straight to stdout. With a clean 3.8 bytecode file from the pycdc test suite, the result is nearly perfect:
1
2
3
4
5
6
7
8
9
10
11
$ ./pycdc tests/compiled/test_calls.3.8.pyc
# Source Generated with Decompyle++
# File: test_calls.3.8.pyc (Python 3.8)
import sys
import os
sys.stdout.write('Test\n')
sys.stdout.write(os.path.join('foo', 'bar'))
print('\n')
print(eval('4 * 13'))
print()
It reads like the original source. That’s the ideal case, a well-supported version and code that isn’t obfuscated.
When pycdc gives up
The pycdc test suite has a file out_sequencer.pyc. Run pycdc:
1
2
3
4
5
6
7
8
$ ./pycdc out_sequencer.pyc
Unsupported opcode: LOAD_FROM_DICT_OR_GLOBALS
# Source Generated with Decompyle++
# File: out_sequencer.pyc (Python 3.13)
if not None + None:
pass
# WARNING: Decompyle incomplete
This file is Python 3.13 (magic f3 0d 0d 0a), and pycdc hit the opcode LOAD_FROM_DICT_OR_GLOBALS which it doesn’t understand yet, so it gave up and printed nonsense (if not None + None). Don’t trust output like this. When you see Unsupported opcode or WARNING: Decompyle incomplete, you can’t rely on the source it printed. Switch to pycdas and read the raw bytecode.
pycdas: dump the bytecode when decompiling fails
pycdas doesn’t try to rebuild source, it just lists everything in the file, including variable names, constants, strings, and bytecode. When pycdc fails, it’s a lifeline because it can almost always read the metadata part.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
$ ./pycdas out_sequencer.pyc
out_sequencer.pyc (Python 3.13)
[Code]
File Name: <genetic_sequencer>
Object Name: <module>
...
[Names]
'base64'
'zlib'
'marshal'
'types'
'encoded_catalyst_strand'
'b85decode'
'compressed_catalyst'
'decompress'
'marshalled_genetic_code'
'loads'
'catalyst_code_object'
'FunctionType'
From the [Names] list you can guess the whole scenario without reading any logic. The file does b85decode on a string, zlib.decompress, then marshal.loads to rebuild a code object and turn it into a function with types.FunctionType. This is a classic self-decoding loader. The outer layer is just a shell, and the real code is compressed and marshaled in a base85 blob (you also see that blob in the [Constants] section of pycdas). To go further, extract the blob and do b85decode + zlib.decompress + marshal.loads yourself in a Python session to get the code object inside, then bring that back into pycdc. The same unwrapping comes up again in the post on unpacking (7.4).
With this 3.13 file, even the [Disassembly] section of pycdas shows skewed opcodes (it assigns wrong opcode names because it hasn’t mapped the 3.13 table correctly). But [Names] and [Constants] are still enough to understand the intent. A tool can be wrong at one level and right at another, so don’t throw away the whole output because one part is broken.
Two header traps
The pycdc project has two more files showing two common errors. ok.pyc is 0 bytes, and whatever you run gives:
1
2
3
$ ./pycdc ok.pyc
Bad MAGIC!
Could not load file ok.pyc
An empty or truncated file has no magic to read. Check the file size before blaming the tool.
apple_collector_game.pyc is more interesting. It also reports Bad MAGIC! but the file isn’t empty at all (nearly 12 KB). Look at the first four bytes:
1
2
$ xxd -l 4 apple_collector_game.pyc
00000000: e300 0000
A valid .pyc must start with a magic number (for example f3 0d 0d 0a for 3.13). The byte e3 here is the marshal opcode for a code object. So this file isn’t a complete .pyc but a raw marshaled code object, with the 16-byte header stripped off. pycdc needs the header to know the version, so it refuses. To handle it, patch the header back on yourself (prepend the correct magic number for the version plus padding), or read it directly with Python’s marshal module. It’s a simple hiding trick, and now you can recognize it from the first four bytes.
My usual rhythm
I run pycdas file.pyc first to learn the version and look at Names/Constants, even when I plan to use pycdc. Then I run pycdc file.pyc to get the source, and if it’s clean, I’m done. If I see Unsupported opcode or WARNING: Decompyle incomplete, I go back to reading bytecode with pycdas, or try another decompiler (7.3). If I see Bad MAGIC!, I check whether the file is empty, raw marshal with the header missing, or encrypted.
Lab
The task is to build Decompyle++ yourself and run it on the sample .pyc files ok.pyc, out_sequencer.pyc and apple_collector_game.pyc, so you see all three common outcomes, a clean decompile, a failed decompile because of a new Python version, and a header error. You need cmake, make and g++ (or Visual Studio on Windows). If a prebuilt copy complains about a missing GLIBC or GLIBCXX, rebuild it:
1
2
3
cd pycdc
cmake . -DCMAKE_BUILD_TYPE=Release
make -j4
Afterwards the folder holds the two programs pycdc and pycdas.
Begin by running ./pycdas and then ./pycdc on a file from tests/compiled/, for example tests/compiled/test_calls.3.8.pyc. This is a clean decompile, so use it as the baseline. Then run ./pycdc ok.pyc and explain the error message by looking at the file size. Run ./pycdc out_sequencer.pyc and note what it reports, which Python version the file is, and why pycdc can’t rebuild the source. For the same file switch to ./pycdas out_sequencer.pyc, read the [Names] and [Constants] sections, and describe the scenario the file carries out (the hint is base64, zlib, marshal). Finally run ./pycdc apple_collector_game.pyc. It reports Bad MAGIC! even though the file isn’t empty, so look at the first 4 bytes with xxd -l 4 apple_collector_game.pyc and explain why.
Two questions to think about. When should you trust the source pycdc prints, and when not? And what does apple_collector_game.pyc lack to be a valid .pyc, and how can you read its contents? Do it yourself before opening the solution.
Show solution
All the output below is real, from a pycdc built from source (CMake + make, g++ on WSL) and run on the sample files.
Task 1: the clean case
1
2
3
4
5
6
7
8
9
10
11
$ ./pycdc tests/compiled/test_calls.3.8.pyc
# Source Generated with Decompyle++
# File: test_calls.3.8.pyc (Python 3.8)
import sys
import os
sys.stdout.write('Test\n')
sys.stdout.write(os.path.join('foo', 'bar'))
print('\n')
print(eval('4 * 13'))
print()
The start of pycdas output:
1
2
3
4
5
6
$ ./pycdas tests/compiled/test_calls.3.8.pyc
test_calls.3.8.pyc (Python 3.8)
[Code]
File Name: tests/input/test_calls.py
Object Name: <module>
...
Python 3.8 is well supported, so the decompile is nearly verbatim. This is the baseline to compare against.
Task 2: ok.pyc
1
2
3
$ ./pycdc ok.pyc
Bad MAGIC!
Could not load file ok.pyc
The file ok.pyc is 0 bytes (check with ls -l). With no magic number it can’t be loaded. On a Bad MAGIC! error, first think of an empty or truncated download.
Task 3: out_sequencer.pyc, where pycdc fails
1
2
3
4
5
6
7
8
$ ./pycdc out_sequencer.pyc
Unsupported opcode: LOAD_FROM_DICT_OR_GLOBALS
# Source Generated with Decompyle++
# File: out_sequencer.pyc (Python 3.13)
if not None + None:
pass
# WARNING: Decompyle incomplete
The version is Python 3.13 (magic f3 0d 0d 0a). pycdc meets the opcode LOAD_FROM_DICT_OR_GLOBALS (new in 3.12/3.13), which it doesn’t implement yet, so it stops and prints nonsense. The lines Unsupported opcode and WARNING: Decompyle incomplete are the signal not to trust the output.
Task 4: out_sequencer.pyc, reading it with pycdas
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
$ ./pycdas out_sequencer.pyc
out_sequencer.pyc (Python 3.13)
[Code]
File Name: <genetic_sequencer>
Object Name: <module>
[Names]
'base64'
'zlib'
'marshal'
'types'
'encoded_catalyst_strand'
'print'
'b85decode'
'compressed_catalyst'
'decompress'
'marshalled_genetic_code'
'loads'
'catalyst_code_object'
'FunctionType'
'globals'
The [Constants] section also holds a long base85 blob and strings like --- Calibrating Genetic Sequencer ---. Reading the Names, the file takes a base85 string (encoded_catalyst_strand), runs base64.b85decode on it, then zlib.decompress, then marshal.loads to get a code object (catalyst_code_object), and finally types.FunctionType turns that into a function and runs it. It’s a self-decrypting loader, so the real logic is compressed and marshaled in the blob, and the outer .pyc layer is just a wrapper.
To go further (not required in this lab), extract the base85 blob and run marshal.loads(zlib.decompress(base64.b85decode(blob))) in a Python session to get the inner code object, then bring it into pycdc. Since it’s 3.13, pycdc may still stumble, and then you read the bytecode with the dis module of Python 3.13. The [Disassembly] part of pycdas on this 3.13 file shows wrong opcodes (it maps the 3.13 opcode table incorrectly), so rely only on Names and Constants.
Task 5: apple_collector_game.pyc
1
2
3
4
5
6
$ ./pycdc apple_collector_game.pyc
Bad MAGIC!
Could not load file apple_collector_game.pyc
$ xxd -l 4 apple_collector_game.pyc
00000000: e300 0000
The file is nearly 12 KB, so it’s not empty. The first four bytes are e3 00 00 00. A valid .pyc must start with a magic number (for example f3 0d 0d 0a). The byte e3 here is the marshal code for a code object (TYPE_CODE), which means this file is a raw marshaled code object with the 16-byte .pyc header stripped off. To read it, prepend a header (the correct magic number for the version plus 12 bytes of padding) and open it with pycdc, or read it directly with marshal.loads(open('apple_collector_game.pyc','rb').read()) in a Python session of the same version that created it.
Answers to the questions
Trust pycdc’s source only when there’s no Unsupported opcode or Decompyle incomplete warning and the code reads meaningfully. With a warning, treat the output as garbage and switch to pycdas or another decompiler. The file apple_collector_game.pyc lacks the .pyc header (magic + flags/timestamp + size). You can read it by prepending a header or by using the marshal module directly.
Key takeaways
pycdc rebuilds source and pycdas dumps bytecode, and neither needs a Python runtime of the exact version. Build with cmake + make in a few minutes if the prebuilt version has library errors. Unsupported opcode or WARNING: Decompyle incomplete means you shouldn’t trust the source pycdc printed, so switch to pycdas. pycdc is weak with Python 3.12/3.13. That’s a real limitation, not something you did wrong.
Bad MAGIC! has three common causes, an empty/truncated file, raw marshal with the header missing, or an encrypted file. Always read the [Names] and [Constants] of pycdas, since they often reveal the whole scenario (a base64/zlib/marshal loader) before you read the logic.
