Lesson 3.5: Lab, solving your first C crackme
By now you have the separate pieces, reading assembly (1.3), the stack and parameters (1.4), recognizing if/loop (1.5), IDA/Ghidra (2.2, 2.3) and x64dbg (2.5). This lesson uses all of them on a small crackme written in C. There’s no new theory, we just sit down and solve it.
The crackme is crackme.c, in the Lab section at the end. I suggest you stop here, try it yourself, and come back to compare. Below I walk through the whole solution, so it’s a spoiler.
The rules
The crackme asks for a password. The right one prints Correct!, a wrong one prints Wrong password.. You have to find the correct password. The password isn’t in the file as plain text, so running strings and copying won’t work. You need to understand how it checks.
Step 1: triage
First I always check what I’m holding. Drag the file into Detect It Easy or run diec:
1
2
$ diec crackme
PE64 / ELF64, compiler GCC (or MSVC), not packed
Not packed, so it’s a normal C binary. We can go straight to reading.
Run strings for clues:
1
2
3
4
5
6
$ strings crackme
Enter password:
Correct! Congratulations.
Wrong password.
check_password
...
Two things here. There’s a function named check_password, which is convenient, that’s where we’re going. And there’s no password in plaintext, so it’s compared indirectly and we have to read the logic.
Step 2: static, from the string to the check function
Open the file in Ghidra (or IDA). After auto-analysis, open the Defined Strings window (Ghidra) or Strings (Shift+F12 in IDA) and look for Wrong password.. Click it and check the xref to see who uses it. It leads to main, which prints the result based on the return value of check_password. Jump into check_password and press F5 to decompile.
The pseudocode looks roughly like this:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
int check_password(char *input) {
if (strlen(input) != 10)
return 0;
int checksum = 0;
for (int i = 0; i < 10; i++) {
unsigned char t = input[i] ^ 0x5A;
if (t != expected[i])
return 0;
checksum += input[i];
}
if (checksum != 0x39C)
return 0;
return 1;
}
There are three checks. The first is the length. The password must be exactly 10 characters, and strlen(input) != 10 returns 0 right away. You saw this pattern in lesson 1.3.
The second is a per-character transform. Each character gets XORed with 0x5A and compared with an element of the expected array. That’s why the password doesn’t show up in strings. The file holds the XORed expected array, not the original password. The third is a checksum. The sum of the ASCII codes must equal 0x39C. It’s there to stop random guessing, but it doesn’t cost us anything. If we get the second check right, the third passes on its own.
The XOR is the important part. Remember from lesson 1.1 that a ^ k ^ k == a. If input[i] ^ 0x5A == expected[i], then input[i] == expected[i] ^ 0x5A. So take the expected array and XOR it with 0x5A to get the password.
Step 3: pull out the expected array
In Ghidra, double-click expected to go to its address and read 10 bytes. In this lab they are:
1
08 3F 2C 3F 28 29 3F 05 6A 6B
XOR each byte with 0x5A. Doing it by hand is slow, so use Python:
1
2
3
exp = [0x08,0x3F,0x2C,0x3F,0x28,0x29,0x3F,0x05,0x6A,0x6B]
print(''.join(chr(b ^ 0x5A) for b in exp))
# Reverse_01
The password is Reverse_01. Enter it and the crackme prints Correct!. We solved it just by reading the code, without running it once.
Step 4: the dynamic route
Maybe you don’t want to compute by hand, or the logic is messier and you want to see the real values. Then I’d use x64dbg.
Open the crackme in x64dbg and set a breakpoint at check_password (or at the cmp in the loop). Enter any 10 characters, for example AAAAAAAAAA. When it stops in the loop, one register holds t = input[i] ^ 0x5A (your input after the XOR). The other operand of cmp is expected[i], visible in a register or in the Dump.
If you look at both sides of the cmp on each iteration, you read the expected array without finding it statically. You still XOR it back as above. So dynamic doesn’t replace static here, it confirms it and gives you the constant array directly.
There’s a faster trick for this kind of crackme too. Set a breakpoint at the checksum or right before return 1, and sometimes you can just patch the jne into je to get past the check. But that only makes it accept any input, it doesn’t give you the real password. For a crackme the goal is usually the password, so XORing back is the better solution. Patching comes in Part 17.
Order of work
Triage first so you don’t waste time on a packed file, static to understand the logic and narrow things down, dynamic to confirm when needed. It’s the loop from lesson 0.4 on a real target. Beginners often jump straight into debugging and step from the start of the program, then spend a whole session lost in the CRT startup. I read statically up to the suspicious spot and then put one breakpoint in the right place.
Lab
The task is to find the correct password of crackme.c. It’s a summary exercise for Parts 1 through 3.4. Build it with one of these commands. On Linux:
1
gcc -O0 -no-pie -fno-stack-protector -o crackme crackme.c
On Windows with MinGW:
1
x86_64-w64-mingw32-gcc -O0 -o crackme.exe crackme.c
On Windows with an MSVC Developer Prompt:
1
cl /Od crackme.c
Work in this order. Triage with Detect It Easy to see which compiler built it and whether it’s packed. Run strings and check whether the password shows up in plaintext, and whether any function name hints at the destination. Open it in Ghidra or IDA and go from the result strings to the checking function by xref. Read the check logic and work out how long the password is and how each character is transformed before the comparison. Take the constant array used in the comparison and compute the password backwards. Enter it and confirm the program prints Correct!. Optionally, open it in x64dbg, put a breakpoint at the comparison loop and watch the two operands of cmp, so you can read the constant array without hunting for it statically.
A hint is that the password isn’t in the file as readable text. It’s transformed, so you have to understand the transformation and undo it. Look at the properties of XOR in Lesson 1.1 if you need a refresher. Do all the steps yourself before opening the solution.
Show solution
The correct password is Reverse_01. Entering it prints Correct! Congratulations., and a wrong input or a wrong length prints Wrong password..
The check_password function does three checks. First, the length must be exactly 10 (strlen(input) != 10). Second, for each character, input[i] ^ 0x5A must equal expected[i]. Third, the sum of the ASCII codes of the password must equal 0x39C. The constant array expected in the binary is:
1
08 3F 2C 3F 28 29 3F 05 6A 6B
Since input[i] ^ 0x5A == expected[i], it follows that input[i] == expected[i] ^ 0x5A:
1
2
3
4
exp = [0x08,0x3F,0x2C,0x3F,0x28,0x29,0x3F,0x05,0x6A,0x6B]
pw = ''.join(chr(b ^ 0x5A) for b in exp)
print(pw) # Reverse_01
print(hex(sum(ord(c) for c in pw))) # 0x39c -> the checksum layer is satisfied on its own
The result is Reverse_01. The ASCII sum equals 0x39C, so the checksum check passes too and needs no separate handling. To verify:
1
2
3
4
5
$ gcc -O0 -o crackme crackme.c
$ echo "Reverse_01" | ./crackme
Enter password: Correct! Congratulations.
$ echo "Reverse_02" | ./crackme
Enter password: Wrong password.
A few notes. The password is XORed, so it never appears in strings, and the way to the real password is to understand the transformation and reverse it. That’s faster and cleaner than patching. The checksum is redundant if you solve the XOR correctly, but it blocks blind guessing, and many real crackmes stack several checks like this. If all you need is for the program to accept any input, you can patch jne into je or NOP the jump, but that doesn’t give you the original password.
Key takeaways
Always triage first, then strings. Function names like check_password help a lot, and the Correct string leads straight to the logic. If the password doesn’t appear in strings, it’s transformed, so you have to read how it’s checked.
XOR goes both ways, which gives input = expected ^ key. A per-byte XOR loop followed by a comparison with a constant array usually means you can XOR back. Solving from static reading is the cleanest, and dynamic is for confirming or for complex logic. Patching the jump makes the check always pass but doesn’t give you the real password.
