Lesson 5.2: ILSpy and dnSpy

After two whole parts of native assembly, opening a .NET file in dnSpy is a pleasant surprise. You click a method, and instead of many mov/call lines, the window shows C# almost exactly as the author wrote it, including class names, method names, local variable names, even a foreach loop. The reason is in lesson 5.1. .NET compiles to IL with full metadata, so the decompiler can rebuild a lot. This lesson covers the two main tools.

Both are free portable downloads, dnSpy.exe and ILSpy.exe, so there’s nothing to install.

ILSpy or dnSpy

I use both, each for its own job.

ILSpy is for reading. It’s light, fast, cross-platform (there’s an Avalonia build for Linux/macOS), and it has a command-line version ilspycmd that exports a whole C# project to disk so you can grep it. When you just need to understand the code, ILSpy is enough. dnSpy (the maintained fork is dnSpyEx) does more. Besides reading, it can debug an assembly with no source, and edit and save it back. Lessons 5.3 and 5.4 use those two abilities. In this lesson dnSpy is mainly for reading and investigating.

The interfaces are nearly the same, so learning one lets you use the other.

Open an assembly and look around

Drag and drop a .NET .exe or .dll into the window, or File > Open. On the left a tree appears:

MyApp.exe
  references        (dependent assemblies)
  MyApp             (root namespace)
    Program         (class)
      Main(string[]) : void       (method)
      CheckLicense(string) : bool
    Resources

The tree follows the .NET structure. An assembly contains namespaces, a namespace contains types (class/struct/enum/interface), a type contains methods and fields. Click a method and the decompiler translates it to C# in the right-hand panel.

A .NET Core apphost .exe (for example dnSpy.exe) is often just a launcher, and the real code sits in the .dll with the same name. If you open the .exe and it looks empty, open the matching .dll. DIE also points this out in lesson 2.1.

View the C#, then flip to IL

By default the decompiler shows C#. Sometimes it translates wrong or hides details (especially with obfuscated code), and then you need the raw IL, which is always accurate.

In ILSpy, use the language dropdown on the toolbar and switch from C# to IL, or choose IL with C# to see them side by side. In dnSpy, use the context menu or the language button to switch between C# and IL.

IL is much easier to read than native assembly. It’s a stack machine with clearly named opcodes (ldarg, call, brtrue, ldstr). When the decompiled C# looks weird, flipping to IL usually clears it up.

Search

Instead of fumbling through the tree, use search (the Search box in ILSpy, Ctrl+Shift+K in dnSpy). You can search by type name, method name, and most usefully by string. It’s the same go-from-strings idea as in lesson 0.4. If the program shows the message “License invalid”, search for that string and it leads to the license-check method.

Analyze

This feature makes .NET RE much faster than native. Right-click a method, field or type and choose Analyze (in dnSpy) or open the Analyze panel (ILSpy). Used By shows which methods call this method, which is the reverse cross-reference, equivalent to the X key in IDA. Uses shows what this method calls. Instantiated By shows where objects of this class are created, and Assigned By / Read By covers fields.

A typical flow is that you suspect a method CheckLicense is the center. Analyze it, look at Used By to see where it’s called from (usually Main or a button click), then trace upward to understand the flow. Or go the other way, from the error message string, and analyze the field holding the string to find where it’s used. Following Used By/Uses lets you rebuild the program’s logic without reading everything.

Export the whole project to grep

When the assembly is big, opening each method in the GUI is slow. ILSpy can export the whole project. In the GUI, right-click the assembly > Save Code, and it writes a .csproj folder with all the .cs files. On the command line, run ilspycmd MyApp.dll -p -o outdir (ilspycmd is a dotnet tool installed separately via dotnet tool install -g ilspycmd).

With the source on disk you can use grep, ripgrep, or your favorite editor for full-text search, which is much faster than clicking around in the GUI.

Lab

The task is to investigate a .NET assembly with ILSpy and dnSpy, and get comfortable with reading, switching to IL, searching and Analyze. You don’t need to download anything special, because the .NET DLLs that ship with ILSpy make good samples. You need ILSpy.exe and dnSpy.exe, and the sample to dissect is ICSharpCode.Decompiler.dll from ILSpy’s folder, a real and fairly large .NET assembly that’s good for practice.

Start by opening the tree. Drag ICSharpCode.Decompiler.dll into ILSpy, expand the tree, find the namespace ICSharpCode.Decompiler, and list any 3 classes along with one method in each. Next decompile and read. Pick a short method and read the C#, then switch the display language to IL (the language box on the toolbar) and compare the two, finding the opcodes ldstr (load a string), call (call a method) and ret. Then search by string. Use the Search box in string/constant mode and type a common English keyword (for example Error, Invalid or version), jump to a result and look at the method that contains it.

For cross-references, right-click any public method, choose Analyze, and open the Used By branch. Note at least two methods that call it, then open Uses to see what it calls. After that, open the same file in dnSpy and repeat the search and Analyze steps (Ctrl+Shift+K to search, right-click then Analyze), and compare it with ILSpy. Optionally, if you have ilspycmd installed (dotnet tool install -g ilspycmd), export the whole project:

ilspycmd ICSharpCode.Decompiler.dll -p -o out_decompiler

and then run grep -r "Invalid" out_decompiler to see full-text search over exported source.

Two questions to think about. Why does decompiling .NET give readable C# right away, while decompiling a native C file doesn’t (think about metadata, see Lesson 5.1)? And if the class and method names were renamed to a, b, c, would the steps above still work, and which of them would? Try it before opening the solution.

Show solution

Do it yourself first. What follows is a direction and sample answers. The specific class and method names may differ depending on your ILSpy version, but the approach is the same.

Opening the tree

Drag ICSharpCode.Decompiler.dll into ILSpy. The namespace ICSharpCode.Decompiler holds a lot of classes. For example you may see CSharpDecompiler (the central class) with its method DecompileWholeModuleAsString(), DecompilerSettings (the configuration) with many bool properties, and, under ICSharpCode.Decompiler.Metadata, the classes that read PE and metadata. The tree follows assembly > namespace > type > method, and every name is intact because this assembly isn’t obfuscated.

Decompile, read, then flip to IL

Pick a short method. The right panel shows C#. Switch the language box to IL and you see the same method as opcodes. A string assignment in C# (x = "abc") becomes ldstr "abc" followed by stloc in IL, a method call becomes call or callvirt, and the method ends with ret. IL is a stack machine, easier to read than native assembly, and it’s where you check when the decompiled C# looks strange.

Search by string

Search for the string Invalid (or Error, version). ILSpy lists the methods and fields containing that string, and clicking a result jumps to the method that uses it. A string works as an anchor that leads to logic.

Analyze and xrefs

Right-click a public method (for example one in CSharpDecompiler), choose Analyze, and open Used By. You get a list of the methods that call it, and each line is clickable. Uses gives the opposite direction, the APIs and methods it calls. Use Used By to trace back from a core function up to an entry point, or Uses to go deeper down. It’s the equivalent of IDA’s X (xref) but for .NET, and more accurate because the metadata is complete.

dnSpy

In dnSpy, Ctrl+Shift+K opens search and right-click then Analyze gives a similar window. The main difference is that dnSpy also has an Edit button (edit C# or IL) and can debug, which ILSpy can’t. For reading alone the two are equivalent.

Exporting the project

ilspycmd ICSharpCode.Decompiler.dll -p -o out_decompiler
grep -rn "Invalid" out_decompiler

You get the whole .cs tree on disk, and a full-text grep finds every mention of a keyword immediately, which beats clicking through the GUI when the assembly is large.

Answers to the questions

.NET decompiles nicely because a .NET file contains IL together with full metadata (type, method, field and parameter names, and types). The decompiler only has to translate IL up to C# and reattach the names that are already there. With a native C file the compiler has thrown away all the names and high-level structure and left only machine code, so everything has to be inferred from scratch. If the names were changed to a/b/c (obfuscation), searching and analyzing by name mostly lose their value. Searching by string still works, because strings are usually not renamed, or if they’re encrypted they give themselves away at the decryption site. The Used By and Uses graphs stay correct as call relationships even when the names are ugly. Removing obfuscation is Lesson 5.5.

Common pitfalls

One is opening the empty apphost .exe instead of the .dll that holds the code, so open the .dll with the same name. Another is trusting the decompiled C# completely, when you should flip to IL to check anything that looks off. Skipping Analyze and trying to read sequentially also costs you, since Used By/Uses saves a lot of time. Finally, obfuscated code (names like a.b.c, encrypted strings) still decompiles but is hard to read. That’s the topic of lesson 5.5.

Key takeaways

ILSpy is for reading (light, cross-platform, ilspycmd exports projects) and dnSpy is for reading, debugging and editing. The tree goes assembly > namespace > type > method, and clicking a method gives you C#. Flip C# to IL when the decompile looks suspicious, and search by string to jump straight to the logic. Analyze (Used By / Uses) is .NET’s cross-reference, so use it to rebuild the flow.
